Portuguese market XHIOV XHIV XHIOE MV CU XLPE PVC copper medium voltage cables
Portuguese referenced Medium Voltage cable for power distribution and power supply stations used in Utility and
Industrial applications, for rated voltages from 3.6/6kV to 18/30kV. Suitable for fixed installations, indoor or outdoor, in open air on cable trays, or underground in ducts or directly buried.
Voltage Rating Uo/U (Um)
3.6/6 (7.2)kV,
6/10 (12)kV,
8.7/15 (17.5)kV,
12/20 (24)kV,
18/30 (36)kV
Temperature Range Fixed: -20°C to +90°C
Minimum Bending Radius 15 x overall diameter
CONSTRUCTION
Conductor Stranded copper conductor
Conductor Screen Semi-conductive XLPE (Cross-Linked Polyethylene)
Insulation XLPE (Cross-Linked Polyethylene)
Insulation Screen Semi-conductive XLPE (Cross-Linked Polyethylene) and tape Metallic Screen Copper wires
Outer Sheath PVC (Polyvinyl Chloride) Sheath or PE (Polyethylene)
Colour Black
|
XHIOV DIMENSIONS 8.7/15 (17.5)kV
|
||||
|
NO. OF
|
CONDUCTOR NOMINAL
|
NOMINAL DIAMETER
|
NOMINAL
|
NOMINAL
|
|
CORES
|
CROSS SECTIONAL AREA
|
OVER INSULATION
|
OVERALL DIAMETER
|
WEIGHT
|
|
/
|
mm2
|
mm
|
mm
|
kg/km
|
|
1
|
25
|
17
|
24.5
|
820
|
|
1
|
35
|
18
|
25.5
|
930
|
|
1
|
50
|
19
|
26.5
|
1075
|
|
1
|
70
|
21
|
28.5
|
1320
|
|
1
|
95
|
22.5
|
30.5
|
1595
|
|
1
|
120
|
24.5
|
32
|
1880
|
|
1
|
150
|
25.5
|
33.5
|
2145
|
|
1
|
185
|
26.5
|
35
|
2535
|
|
1
|
240
|
29.5
|
37.5
|
3130
|
|
1
|
300
|
32
|
40.5
|
3775
|
|
1
|
400
|
35
|
43.5
|
4720
|
|
1
|
500
|
38
|
47
|
5685
|
|
1
|
630
|
44
|
50.5
|
7315
|
|
3
|
25
|
17
|
49
|
3125
|
|
3
|
35
|
18
|
51.5
|
3540
|
|
3
|
50
|
19
|
54.5
|
4135
|
|
3
|
70
|
21
|
58
|
4965
|
