NYY NYY-J NYY-O 0.6/1KV Copper Conductor PVC Insulated PVC Sheath Power Cable
ApplicationThis power cable is suitable for fixed installations, preferably in cable ducts, indoors, outdoors, in water
or underground if no mechanical damage is to be expected.
Construction:
2 Core insulation of polyvinylchloride (PVC)
3 PVC core covering or taping
4 Outer sheath of polyvinylchloride (PVC), black
Information: short circuit temperature on core (max. 5 sec.)
<=300mm² –> 160°C
>300mm² –> 140°C
According to: DIN VDE 0276-603 HD 603 S1:1994 + A2:2003
DIN EN 60228 class 1 and 2 (construction) HD 308 S2 (core identification)
| Number of cores and nominal cross section | Copper | Overall diameter | Weight | Current carrying | Current carrying |
| figure | |||||
| / | appr. | appr. | capacity ground | capacity air | |
| mm2 | kg/km | mm | kg/km | A | A |
| 1 x 16 RE | 160,0 | 11 | 233,0 | 107 | 84 |
| 1 x 25 RM | 250,0 | 12 | 370,0 | 138 | 114 |
| 1 x 35 RM | 350,0 | 14 | 480,0 | 164 | 139 |
| 1 x 50 RM | 500,0 | 16 | 640,0 | 195 | 169 |
| 1 x 70 RM | 700,0 | 17 | 850,0 | 238 | 213 |
| 1 x 95 RM | 950,0 | 19 | 1.120,0 | 286 | 264 |
| 1 x 120 RM | 1.200,0 | 21 | 1.375,0 | 325 | 307 |
| 1 x 150 RM | 1.500,0 | 23 | 1.660,0 | 365 | 352 |
| 1 x 185 RM | 1.850,0 | 25 | 2.050,0 | 413 | 406 |
| 1 x 240 RM | 2.400,0 | 28 | 2.634,0 | 479 | 483 |
| 1 x 300 RM | 3.000,0 | 30 | 3.295,0 | 541 | 557 |
| 1 x 400 RM | 4.000,0 | 32 | 4.231,0 | 614 | 646 |
| 1 x 500 RM | 5.000,0 | 34 | 5.284,0 | 693 | 747 |
| 1 x 630 RM | 6.300,0 | 42 | 6.850,0 | 777 | 858 |
| 2 x 1,5 RE | 30,0 | 11 | 220,0 | 27 | 20 |
| 2 x 2,5 RE | 50,0 | 12 | 267,0 | 36 | 25 |
| 2 x 4 RE | 80,0 | 14 | 342,0 | 47 | 34 |
| 2 x 6 RE | 120,0 | 15 | 412,0 | 59 | 43 |
| 2 x 10 RE | 200,0 | 16 | 510,0 | 79 | 59 |
| 2 x 16 RM | 320,0 | 18 | 670,0 | 102 | 79 |
| 3 x 1,5 RE | 45,0 | 13 | 244,0 | 27 | 20 |
| 3 x 2,5 RE | 75,0 | 14 | 294,0 | 36 | 25 |
| 3 x 4 RE | 120,0 | 16 | 393,0 | 47 | 34 |
| 3 x 6 RE | 180,0 | 17 | 481,0 | 59 | 43 |
| 3 x 10 RE | 300,0 | 18 | 645,0 | 79 | 59 |
| 3 x 16 RE | 480,0 | 20 | 872,0 | 102 | 79 |
| 3 x 16 RM | 480,0 | 20 | 872,0 | 102 | 79 |
| 3 x 25 RM | 750,0 | 25 | 1.350,0 | 133 | 106 |
| 3 x 35 SM | 1.050,0 | 25 | 1.460,0 | 159 | 129 |
| 3 x 50 SM | 1.500,0 | 29 | 1.750,0 | 188 | 157 |
| 3 x 70 SM | 2.100,0 | 32 | 2.400,0 | 232 | 199 |
| 3 x 95 SM | 2.850,0 | 35 | 3.560,0 | 280 | 246 |
| 3 x 120 SM | 3.600,0 | 38 | 4.310,0 | 318 | 285 |
| 3 x 150 SM | 4.500,0 | 42 | 5.310,0 | 359 | 326 |
| 4 x 1,5 RE | 60,0 | 14 | 278,0 | 27 | 20 |
| 4 x 2,5 RE | 100,0 | 15 | 340,0 | 36 | 25 |
| 4 x 4 RE | 160,0 | 17 | 460,0 | 47 | 34 |
| 4 x 6 RE | 240,0 | 18 | 570,0 | 59 | 43 |
| 4 x 10 RE | 400,0 | 20 | 775,0 | 79 | 59 |
| 4 x 10 RM | 400,0 | 20 | 775,0 | 79 | 59 |
| 4 x 16 RE | 640,0 | 22 | 1.072,0 | 102 | 79 |
| 4 x 16 RM | 640,0 | 22 | 1.072,0 | 102 | 79 |
| 4 x 25 RM | 1.000,0 | 27 | 1.632,0 | 133 | 106 |
| 4 x 35 SM | 1.400,0 | 27 | 1.959,0 | 159 | 129 |
| 4 x 50 SM | 2.000,0 | 32 | 2.595,0 | 188 | 157 |
| 4 x 70 SM | 2.800,0 | 36 | 3.488,0 | 232 | 199 |
| 4 x 95 SM | 3.800,0 | 41 | 4.637,0 | 280 | 246 |
| 4 x 120 SM | 4.800,0 | 43 | 5.689,0 | 318 | 285 |
| 4 x 150 SM | 6.000,0 | 49 | 6.973,0 | 359 | 326 |
| 4 x 185 SM | 7.400,0 | 54 | 8.663,0 | 406 | 374 |
| 4 x 240 SM | 9.600,0 | 60 | 11.140,0 | 473 | 445 |
| 5 x 1,5 RE | 75,0 | 15 | 317,0 | / | / |
| 5 x 2,5 RE | 125,0 | 16 | 391,0 | / | / |
| 5 x 4 RE | 200,0 | 18 | 537,0 | / | / |
| 5 x 6 RE | 300,0 | 19 | 672,0 | / | / |
| 5 x 10 RE | 500,0 | 21 | 921,0 | / | / |
| 5 x 10 RM | 500,0 | 21 | 921,0 | / | / |
| 5 x 16 RE | 800,0 | 24 | 1.294,0 | / | / |
| 5 x 16 RM | 800,0 | 24 | 1.294,0 | / | / |
| 5 x 25 RM | 1.250,0 | 29 | 2.004,0 | / | / |
| 5 x 35 RM | 1.750,0 | 30 | 2.575,0 | / | / |
| 5 x 50 RM | 2.500,0 | 36 | 3.193,0 | / | / |
| 5 x 70 RM | 3.500,0 | 40 | 4.722,0 | / | / |
| 5 x 95 RM | 4.750,0 | 46 | 6.393,0 | / | / |
| 5 x 120 RM | 6.000,0 | 50 | 7.095,0 | / | / |
| 5 x 150 RM | 7.500,0 | 59 | 8.240,0 | / | / |
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.
We are China Nyy Nyy-J Nyy-O 0.6/1kv Copper Conductor PVC Insulated PVC Sheath Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
