Ntscgewou 3.6/6 Kv 6/10 Kv 8.7/15 Kv 12/20 Kv 18/30 Kv Medium Voltage Flexible Mining Drilling Tunnelling Cable

3,6/6 kV 6/10 kV 8,7/15 kV 12/20 kV 18/30 kV NTSCGEWOU Mining Cable

Application:
For the connection of electrical equipment, large material handling machines such as excavators, cranes,dumpers in mining and tunnelling applications. The flexible cable design allows for movement of the equipment during operation.

Construction:
Conductor : Electrolytic, stranded, tinned copper wire DIN VDE 0295 Class 5
Insulation : 3GI3 Type EPR Compound
Electrical Field Control : Inner and Outer Semiconductive layer of semiconductive rubber
Protective-Earth Conductor : Tinned Copper conductor with semiconductive layer
Lay Up : Three main conductors laid-up with three control cores in the outer interstice
Inner Sheath : GM1b Type EPR Compound
Reinforcement : Embedded braid made of anti torsion synthetic threads
Outer Sheath : 5GM5 Type elastomer compound
Colour : Red

Characteristics
Rated Voltage : 3,6/6 kV 6/10 kV 8,7/15 kV 12/20 kV 18/30 kV
AC Test Voltage : 11 kV 17 kV 24 kV 29 kV 43 kV
Max. Permissible
Operating Voltage AC : 4,2/7,2 kV 6,9/12 kV 10,4/18 kV 13,9/24 kV 20,8/36 kV
Min Bending Radius : Acc. to DIN VDE 0298 part 3
Current Carrying Capacity : According to DIN VDE 0298, Part 4
Working Temperature :
Fixed : -40ºC … +80ºC
Mobile : -25ºC … +80ºC
Max. Tensile Load of cable : 15 N/mm²
Max. Torsion : 25º/m
Travel Speed for tunnelling app. : max. 30 m/min.
Minimum distarce for change of direction : 20 X D
