Nsgafcmou 3.6/6kv EMC Screening Flexible Stranded Copper Rubber Cable

Nsgafcmou 3.6/6kv EMC Screening Flexible Stranded Copper Rubber Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NSGAFCMOU

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Tinned Wire

Certification

VDE

Model

Nsgafcmou

Brand

Huadong

Rated Voltage

3.6/6kv

Core

Single Core

Temperature

-40 Deg to 80 Deg C

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NSGAFCMOU 3.6/6kV EMC Screening Flexible Stranded Copper Rubber Cable

Application:
(N)SGAFCMÖU Cable with EMC screening for short circuit and grounding connections requiring 3.6/6kV. They are suited to use in rail vehicles, buses, switch cabinets and continuously operating installations. Installation can be in pipes and pipe work ducts as well as in dry interiors, both indoor and outdoors, as well as dry, humid, wet or oily
environments.

Construction:
Conductor Class 5 flexible stranded Copper
Conductor Screen Semi-conductive layer over conductor
Insulation EPDM (Ethylene Propylene Diene Monomer) 3GI3 Type
Screen TCWB (Tinned copper wires braid)
Sheath Rubber 5GM3 Type

Information:
Voltage Rating 3.6/6 kV
Temperature Rating
Fixed: -40°C to +80°C
Mobile: -25°C to +80°C

Standards:
DIN VDE 0250-1, DIN VDE 0250-602, DIN VDE 0295, DIN
VDE 0298-3/4, IEC/EN 60228, BS 6360, DIN VDE
0472-501/502/503, DIN VDE 0472-303/401/402/602/ 615, HD 383, UV/Ozone resistant to IEC/EN 60811-2-1
Flame Retardant to IEC/EN 60332-1-2

NUMBER OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL OUTER DIAMETER mm	NOMINAL CABLE WEIGHT kg/km
1	185	39	3050
