Nmwu 3c14 3c12 3c10 3c8 CSA Canada Wire and Cables 300V Underground Direct Burial Wire

Nmwu 3c14 3c12 3c10 3c8 CSA Canada Wire and Cables 300V Underground Direct Burial Wire image

Get Latest Price Request a quote

Product Details

Model NO.

nmwu

Application

Heating

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Flat Wire

Certification

ISO9001, CE, CCC, RoHS, VDE

Voltage

600V

Certifictaion

cUL CSA

Package

Roll/Drum

Usage

Building Wire

Transport Package

Coils and Drums

Specification

14AWG

Trademark

HT CABLES

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

NMWU CABLE
Non-metallic Sheathed Cable, 300V, CU, PVC or XLPE, PVC

Application:

NWMU cables may be used for underground installations, including direct burial. It may also be used

for environments exposed to the weather in dry and wet locations. The maximum allowable conductor

temperature is 60°C. The minimum recommended installation temperature is -40°C for two-conductor

cables (sizes AWG 14 to AWG 6) and -25°C for all other sizes. Material should be properly stored above

0°C for 24 hours prior to installation.

Structure:

1.Conductor: Annealed copper conductors with compressed standing for stranded

conductors

2.Grounding Conductor: Annealed bare copper conductors

3.Insulation: Cross-linked Polyethylene (XLPE) or Polyvinyl chloride (PVC)

4.Jacket: Polyvinyl Chloride (PVC), black

5.Conductor Colors: White and black (for 2 conductor cables); white, black and red

(for 3 conductor cables)

Standard: CSA C22.2 No. 48 (non-metallic sheathed cable)

cUL File No.: E487898 CSA file No.: 271587 Voltage:300V

Working temperature: –40ºC/ -25ºC MIN, 60ºC MAX

Performance: FT-1 Flame retardant; Sun Res (SR)

Printing: HT CABLES CSA 271587 ***AWG ***C AL ACM NMWU NYLON CABLE FT1 300V (-25ºC) YEAR ****m

Technical data:

Conductor				Grounding Wire		Jacket Thickness	Cable Dimensions	Weight	Max. DC resistance at 20C
Size AWG	NO.	No. of strands	Insulation Thickness	Size ( AWG)	No. of Strands
			mm			mm	mm	kg/km	(Ω/km)
14	2	1	1.52	14	1	0.76	6.3 × 12.7	142	8.62
12	2	1	1.52	14	1	0.76	6.8 × 13.6	173	5.43
10	2	1	1.52	12	1	0.76	7.3 × 15.1	234	3.41
8	2	7	1.90	10	1	1.14	9.9 × 20.0	402	2.14
6	2	7	2.29	8	7	1.14	11.6 × 23.5	565	1.35
14	3	1	1.52	14	1	0.76	11.9	181	8.62
12	3	1	1.52	14	1	0.76	12.8	227	5.43
10	3	1	1.52	12	1	0.76	13.9	306	3.41
8	3	7	1.90	10	1	1.14	18.6	523	2.14
6	3	7	2.29	10	7	1.14	22.3	752	1.35

All dimensions are nominal and subject to normal manufacturing tolerances
