Na2xs (F) 2y 12/20 Kv 1630RM/35 1240RM/25 Medium Voltage Longitudinally Water Tight Aluminium Power Cable

Na2xs (F) 2y 12/20 Kv 1*630RM/35 1*240RM/25 Medium Voltage Longitudinally Water Tight Aluminium Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NA2XS(F)2Y

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Stranded Aluminium

Certification

HD 620 10 F, Sfs 5636

Brand

Huadong

Rated Voltage

12/20 (24)Kv

Cores

Single Core

Type

Flame Retardancy

Size

35-630mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NA2XS(F)2Y Medium Voltage Aluminium Power Cable with XLPE Insulation

Medium voltage single core cable 6/10 kV, 12/20 kV, 18/30 kV, XLPE insulated, PVC/PE sheathed, with screen of CU/AL conductor, with longitudinally watertight or not.

Application:
Medium voltage cables for distribution networks; also for connection to generation units and plant and process connection. To be laid directly in ground, outdoors, indoors and in cable ducts.

Standards:
DIN VDE 0276-620, HD 620 S1, IEC 60502-2 DIN VDE 0276 part 620

Construction:
Conductor:Aluminium Conductor

Core insulation: Cross-linked Polyethylen (XLPE)

Screen made of copper wires with one or two copper bond counter spiral longitudinally water-tight wrapping

Outer sheath: PE, black

Technical Data

Conductor stranding: Multi-wire

Minimum bending radius:

Fixed installation: 15 x outer diameter

Nominal voltage:

U0 /U: 6/10 (12) kV, 12/20 (24) kV, 18/30 (36) kV

Test voltage:
Depending on nominal voltage:

6/10 kV: 15 kV

12/20 kV: 30 kV

18/30 kV: 45 kV

Temperature range:

During installation: -40°C to +70°C

Fixed installation: -40°C to +90°C

12/20KV Cable Parameter

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China Na2xs (F) 2y 12/20 Kv 1*630RM/35 1*240RM/25 Medium Voltage Longitudinally Water Tight Aluminium Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
