N2XH Cu conductors XLPE insulated and LSZH Compound Sheathed Power cable
Application
In earth, ducts, on support brackets, in dry and wet conditions etc., where one does not expect mechanical damages and the cables are not exposed to the mechanical tensile strain. In urban networks, industrial plants, electric power plants and other electricity consumers and for connection of control devices in industry, traffic etc., where fire prevention safety measures are requested, for eleveted electricity and thermic strains.
Construction
Conductors: Cu, class 1 or 2 according to EN 60228
Insulation: XLPE compound, type 2XI1
Bedding: Extruded elastomere or plastomere LSZH compound or plactic tape
Sheath: LSZH compound, type HM4
Country: Austria, Croatia, Germany, Poland, Serbia
Industry: Building & Construction, Data Centres, Transmission, Distribution & Power Networks
Standard: HD 604 S1, IEC 60502-1, VDE 0276-604
Cable Parameters
| Number of cores and nominal cross section |
Copper figure |
Overall | Calorific potential |
Weight |
| diameter | ||||
| appr. | appr. | |||
| mm2 | kg/km | mm | kWh/m | kg/km |
| 1 x 6 RE | 60,0 | 7,8 | 0,33 | 112,0 |
| 1 x 16 RM | 160,0 | 9,8 | 0,46 | 226,0 |
| 1 x 25 RM | 250,0 | 11,4 | 0,62 | 327,0 |
| 1 x 35 RM | 350,0 | 12,6 | 0,71 | 429,0 |
| 1 x 50 RM | 500,0 | 13,8 | 0,82 | 555,0 |
| 1 x 70 RM | 700,0 | 15,7 | 1,00 | 765,0 |
| 1 x 95 RM | 950,0 | 17,4 | 1,14 | 1.024,0 |
| 1 x 120 RM | 1.200,0 | 19,0 | 1,32 | 1.263,0 |
| 1 x 150 RM | 1.500,0 | 20,9 | 1,59 | 1.542,0 |
| 1 x 185 RM | 1.850,0 | 23,1 | 1,91 | 1.918,0 |
| 1 x 240 RM | 2.400,0 | 25,6 | 2,24 | 2.466,0 |
| 1 x 300 RM | 3.000,0 | 28,1 | 2,58 | 3.065,0 |
| 2 x 1,5 RE | 30,0 | 9,3 | 0,45 | 125,0 |
| 2 x 2,5 RE | 50,0 | 10,1 | 0,52 | 158,0 |
| 3 x 1,5 RE | 45,0 | 9,7 | 0,51 | 142,0 |
| 3 x 2,5 RE | 75,0 | 10,6 | 0,59 | 184,0 |
| 3 x 4 RE | 120,0 | 11,7 | 0,70 | 247,0 |
| 3 x 6 RE | 180,0 | 12,8 | 0,80 | 322,0 |
| 3 x 10 RE | 300,0 | 14,9 | 1,02 | 480,0 |
| 3 x 16 RM | 480,0 | 17,7 | 1,36 | 732,0 |
| 3 x 25 RM | 750,0 | 24,0 | 2,25 | 1.200,0 |
| 3 x 35 RM | 1.050,0 | 27,0 | 2,56 | 1.600,0 |
| 3 x 50 RM | 1.500,0 | 29,0 | 3,19 | 1.800,0 |
| 3 x 50/25 SM/RM | 1.750,0 | 32,0 | 3,53 | 2.200,0 |
| 3 x 70/35 SM/RM | 2.450,0 | 37,0 | 4,31 | 2.950,0 |
| 3 x 95/50 SM | 3.216,0 | 41,0 | 5,58 | 3.900,0 |
| 3 x 120/70 RM | 4.300,0 | 45,0 | 6,58 | 4.800,0 |
| 3 x 150/70 RM | 5.200,0 | 49,0 | 7,64 | 5.750,0 |
| 3 x 185/95 RM | 6.500,0 | 55,0 | 9,42 | 7.200,0 |
| 3 x 240/120RM | 8.400,0 | 62,0 | 12,22 | 9.150,0 |
| 4 x 1,5 RE | 60,0 | 10,4 | 0,60 | 166,0 |
| 4 x 2,5 RE | 100,0 | 11,4 | 0,69 | 220,0 |
| 4 x 4 RE | 160,0 | 12,6 | 0,84 | 298,0 |
| 4 x 6 RE | 240,0 | 13,8 | 0,95 | 391,0 |
| 4 x 10 RE | 400,0 | 16,3 | 1,26 | 599,0 |
| 4 x 16 RM | 640,0 | 19,2 | 1,63 | 908,0 |
| 4 x 25 RM | 1.000,0 | 23,9 | 2,48 | 1.413,0 |
| 4 x 35 RM | 1.400,0 | 26,7 | 2,93 | 1.863,0 |
| 4 x 50 SM | 2.000,0 | 29,1 | 3,76 | 2.362,0 |
| 4 x 70 SM | 2.800,0 | 32,2 | 4,55 | 3.151,0 |
| 4 x 95 SM | 3.800,0 | 37,2 | 5,72 | 4.339,0 |
| 4 x 120 SM | 4.800,0 | 40,8 | 6,36 | 5.332,0 |
| 4 x 150 SM | 6.000,0 | 50,0 | 7,14 | 6.350,0 |
| 5 x 1,5 RE | 75,0 | 11,2 | 0,71 | 195,0 |
| 5 x 2,5 RE | 125,0 | 12,3 | 0,84 | 260,0 |
| 5 x 4 RE | 200,0 | 13,7 | 1,00 | 357,0 |
| 5 x 6 RE | 300,0 | 15,4 | 1,21 | 486,0 |
| 5 x 10 RE | 500,0 | 17,8 | 1,52 | 723,0 |
| 5 x 16 RE | 800,0 | 21,6 | 2,07 | 1.138,0 |
| 5 x 16 RM | 800,0 | 21,6 | 2,17 | 1.138,0 |
| 5 x 25 RM | 1.250,0 | 27,0 | 3,14 | 1.420,0 |
| 5 x 35 RM | 1.750,0 | 37,0 | 3,95 | 2.400,0 |
| 7 x 1,5 RE | 105,0 | 12,0 | 0,80 | 239,0 |
| 12 x 1,5 RE | 180,0 | 16,0 | 1,29 | 395,0 |
| 19 x 1,5 RE | 285,0 | 18,6 | 1,80 | 557,0 |
| 24 x 1,5 RE | 360,0 | 22,2 | 2,35 | 736,0 |
| 30 x 1,5 RE | 450,0 | 24,0 | 2,72 | 900,0 |
| 7 x 2,5 RE | 175,0 | 15,0 | 1,31 | 400,0 |
| 12 x 2,5 RE | 300,0 | 19,0 | 2,00 | 600,0 |
| 19 x 2,5 RE | 475,0 | 22,0 | 2,69 | 840,0 |
| 24 x 2,5 RE | 600,0 | 25,0 | 3,28 | 1.050,0 |
| 7 x 4 RE | 280,0 | 14,9 | 1,48 | 457,0 |
