N2xch Halogen Free Flame Retardant Copper Wire Screened Armoured Power Cable with Concentric Copper Conductor

N2xch Halogen Free Flame Retardant Copper Wire Screened Armoured Power Cable with Concentric Copper Conductor image

Get Latest Price Request a quote

Product Details

Model NO.

N2XCH

Current

DC & AC

Insulation Material

XLPE

Sheath Material

Halogen-Free, Thermoplastic Polyolefin Compound

Material Shape

Round Wire

Wire Core Material

Stranded Tinned Copper

Certification

VDE, IEC

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1 2 3 4 5 Core

Size

1.5-400mm2

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

N2XCH Halogen free flame retardant copper wire screened armoured power cable with concentric copper conductor

Application:
In earth, ducts, on support brackets, in dry and wet conditions etc., where one does expect mechanical damages and the cables are not exposed to the mechanical tensile strain. In urban networks, industrial plants, electric power plants and other electricity consumers and for connection of control devices in industry, traffic etc

Construction:
1 Solid or stranded bare copper
2 Insulation of halogen-free, cross-linked polyethylene compound
3 Covering of a halogen-free compound
4 Anti-twist tape
5 Concentric conductor formed by copper wires with counter helix of copper tape
6 Outer sheath of halogen-free, cross-linked polyethylene compound, black

Standards:
DIN VDE 0276-604 HD 604 S1 part 1 + part 5 G
DIN EN 60228 class 1 and 2 (construction)
HD 308 S2 (core identification)

Cable Parameters

Number of cores and	Copper	Overall	Calorific	Weight
nominal cross section	figure	diameter appr.	potential	appr.
mm2	kg/km	mm	kWh/m	kg/km
2 x 1,5 RE/ 1,5	1 x 1,38	11,5	0,61	177,0
2 x 2,5 RE/ 2,5	1 x 1,78	12,7	0,69	226,0
3 x 1,5 RE/ 1,5	1 x 1,38	11,3	0,68	196,0
3 x 2,5 RE/ 2,5	1 x 1,78	13,2	0,77	253,0
3 x 4 RE/ 4	1 x 2,25	16,0	0,90	336,0
3 x 6 RE/ 6	1 x 2,76	16,0	1,03	441,0
3 x 10 RE/ 10	1 x 3,56	18,5	1,35	659,0
3 x 16 RE/ 16	1 x 4,51	21,3	1,74	979,0
4 x 1,5 RE/ 1,5	1 x 1,38	12,6	0,77	221,0
4 x 2,5 RE/ 2,5	1 x 1,78	14,0	0,88	291,0
4 x 4 RE/ 4	1 x 2,25	15,2	1,04	393,0
4 x 6 RE/ 6	1 x 2,76	17,4	1,27	527,0
4 x 10 RE/ 10	1 x 3,56	19,9	1,62	783,0
4 x 16 RM/ 16	7 x 1,70	23,4	2,19	1.188,0
4 x 25 RM/ 16	7 x 2,13	28,1	3,16	1.716,0
4 x 35 RM/ 16	7 x 2,52	31,1	3,74	2.193,0
4 x 50 SM/ 25	19 x 1,89	33,7	4,57	2.784,0
4 x 70 SM/ 35	19 x 2,17	37,2	5,46	3.675,0
4 x 95 SM/ 50	19 x 2,52	43,0	6,97	5.063,0
4 x 120 SM/ 70	37 x 2,03	47,2	7,84	6.307,0
4 x 150 SM/ 70	37 x 2,27	52,0	9,66	7.617,0
4 x 185 SM/ 95	37 x 2,52	57,3	11,60	9.462,0
4 x 240 SM/120	61 x 2,24	64,3	14,06	12.264,0
7 x 1,5 RE/ 2,5	1 x 1,38	14,4	0,99	314,0
12 x 1,5 RE/ 2,5	1 x 1,38	19,0	1,66	503,0
7 x 2,5 RE/ 2,5	1 x 1,78	16,0	1,21	413,0
12 x 2,5 RE/ 4	1 x 1,78	20,9	1,90	667,0
