(N) Tscgewtoeus Ntscgewtoeus 6/10kv Reel Motor Cable (RTS) Flexible Reeling Trailing Cable with Fiber Optical Cores

(N) Tscgewtoeus Ntscgewtoeus 6/10kv Reel Motor Cable (RTS) Flexible Reeling Trailing Cable with Fiber Optical Cores image

Get Latest Price Request a quote

Product Details

Model NO.

NTSCGEWTOEUS

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CE, VDE

Model

Ycw

Brand

Huadong

Product Name

(N)Tscgewtoeus Reeling Cable

Core

Single Core

Standard

VDE

Rated Voltage

1.8/3 (3.6)Kv to 18/30 (36)Kv

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

(N)TSCGEWTOEUS 6/10kV REEL MOTOR CABLE (RTS) Flexible Reeling Trailing Flexible Cable with Fiber Optical Cores

Applications

Flexible reeling cable for energy supply. Especially for high and extreme mechanical stress, e.g. torsional stress and high

reeling speed. For deflection into different planes. Also usable for festoon systems, open-cast and underground mining.

Main applications: Ship to Shore Cranes (STS), Rail Mounted Gantry Cranes (RMG), Ship Unloader, Stacker Reclaimer and other heavy mobile equipment.

Cable Construction
1. Conductor Flexible, plain copper, “FSC” better than IEC 60228 class 5

2. Insulation Inner semi-conductive layer New special insulation compound “RHEYCLEAN” based on EPDM, better than DIN VDE 207 part 20.Outer semi-conductive layer,”RHEYSTRIP”, easy strip design

3. Protective earth conductor Flexible, plain copper, “FSC” better than IEC 60228 class 5

4.Semi-conductive layer

5. Inner sheath Special synthetic rubber,better than GM1b6. Reinforcement Synthetic threads with very high tensile strength as a protection against twist stress and pressure loads

7. Outer sheath New special sandwich construction for an optimum of flexibility, abrasion resistance and heavy load, special rubber compound

Colour:Red

Dimensions and Weight

Number of cores and	Outer diameter		Weight approx.	Tensile strength
nominal cross-section	Outer diameter		Weight approx.	Tensile strength
(mm2)	Min. (mm)	Max. (mm)	(kg/km)	(N)
1.8/3 (3.6) kV
3 x 25 + 3 x 25/3	31	34	1,850	3,000
3 x 35 + 3 x 25/3	34	37	2,320	3,000
3 x 50 + 3 x 25/3	38	41	2,900	3,000
3 x 70 + 3 x 35/3	43	46	3,900	4,200
3 x 95 + 3 x 50/3	49	51	4,900	5,700
3 x 120 + 3 x 70/3	54	57	6,120	7,200
3 x 150 + 3 x 70/3	57	60	7,180	9,000
3 x 185 + 3 x 95/3	62	65	8,600	11,100
3 x 240 + 3 x 120/3	69	72	10,800	14,400
3 x 300 + 3 x 150/3	76	79	13,250	18,000
3.6/6 (7.2) kV
3 x 25 + 3 x 25/3*	39	42	2,350	3,000
3 x 35 + 3 x 25/3*	42	45	2,900	3,000
3 x 50 + 3 x 25/3	46	49	3,550	3,000
3 x 70 + 3 x 35/3	49	52	4,460	4,200
3 x 95 + 3 x 50/3	55	58	5,500	5,700
3 x 120 + 3 x 70/3	58	61	6,600	7,200
3 x 150 + 3 x 70/3	64	67	8,000	9,000
3 x 185 + 3 x 95/3	68	71	9,300	11,100
3 x 240 + 3 x 120/3	73	76	11,350	14,400
3 x 300 + 3 x 150/3	80	84	13,750	18,000
6/10 (12) kV
3 x 25 + 3 x 25/3*	39	42	2,350	3,000
3 x 35 + 3 x 25/3*	42	45	2,900	3,000
3 x 50 + 3 x 25/3	46	49	3,550	3,000
3 x 70 + 3 x 35/3	49	52	4,460	4,200
3 x 95 + 3 x 50/3	55	58	5,500	5,700
3 x 120 + 3 x 70/3	58	61	6,600	7,200
3 x 150 + 3 x 70/3	64	67	8,000	9,000
3 x 185 + 3 x 95/3	68	71	9,300	11,100
3 x 240 + 3 x 120/3	73	76	11,350	14,400
3 x 300 + 3 x 150/3	80	84	13,750	18,000
8.7/15 (18) kV
3 x 25 + 3 x 25/3*	39	42	2,350	3,000
3 x 35 + 3 x 25/3*	42	45	2,900	3,000
3 x 50 + 3 x 25/3	46	49	3,550	3,000
3 x 70 + 3 x 35/3	49	52	4,460	4,200
3 x 95 + 3 x 50/3	55	58	5,500	5,700
3 x 120 + 3 x 70/3	58	61	6,600	7,200
3 x 150 + 3 x 70/3	64	67	8,000	9,000
3 x 185 + 3 x 95/3	68	71	9,300	11,100
3 x 240 + 3 x 120/3	73	76	11,350	14,400
3 x 300 + 3 x 150/3	80	84	13,750	18,000
12/20 (24) kV
3 x 25 + 3 x 25/3	46	49	3,000	3,000
3 x 35 + 3 x 25/3	48	51	3,400	3,000
3 x 50 + 3 x 25/3	50	53	3,900	3,000
3 x 70 + 3 x 35/3	55	58	5,050	4,200
3 x 95 + 3 x 50/3	58	61	5,900	5,700
3 x 120 + 3 x 70/3	61	64	6,950	7,200
3 x 150 + 3 x 70/3	66	69	8,210	9,000
3 x 185 + 3 x 95/3	70	73	9,550	11,100
3 x 240 + 3 x 120/3	77	80	12,200	14,400
3 x 300 + 3 x 150/3	82	85	14,100	18,000
14/25 (30) kV
3 x 35 + 3 x 25/3	53	56	3,950	3,000
3 x 50 + 3 x 25/3	55	58	4,480	3,000
3 x 70 + 3 x 35/3	58	61	5,460	4,200
3 x 95 + 3 x 50/3	62	65	6,400	5,700
3 x 120 + 3 x 70/3	64	67	7,300	7,200
3 x 150 + 3 x 70/3	69	72	8,710	9,000
3 x 185 + 3 x 95/3	73	76	10,200	11,100
3 x 240 + 3 x 120/3	79	82	12,400	14,400
3 x 300 + 3 x 150/3	84	87	14,600	18,000
18/30 (36) kV
3 x 35 + 3 x 25/3	60	63	4,830	3,000
3 x 50 + 3 x 25/3	62	65	5,310	3,000
3 x 70 + 3 x 35/3	64	67	6,150	4,200
3 x 95 + 3 x 50/3	66	69	7,000	5,700
3 x 120 + 3 x 70/3	69	72	8,050	7,200
3 x 150 + 3 x 70/3	75	78	9,510	9,000
3 x 185 + 3 x 95/3	77	80	10,800	11,100
3 x 240 + 3 x 120/3	85	88	13,300	14,400
3 x 300 + 3 x 150/3	89	93	15,500	18,000
