(N) Tscgewou Ntscgewou 3.6/6kv 6/10kv 8.7/15kv 12/20kv Mv Flexible Mine Power Distribution Lines Cable

(N) Tscgewou Ntscgewou 3.6/6kv 6/10kv 8.7/15kv 12/20kv Mv Flexible Mine Power Distribution Lines Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NTSCGEWOU

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CE, VDE

Brand

Huadong

Product Name

Ntscgewou Mining Cable

Rated Voltage

3,6/6 Kv 6/10 Kv 8,7/15 Kv 12/20 Kv 18/30 Kv

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NTSCGEWOU 3.6/6kV, 6/10kV, 8.7/15kV, 12/20kV Cable

APPLICATION
Flexible cable for fixed distribution lines in mines and alongside material handling equipment. Suitable for indoor and outdoor applications.

CHARACTERISTICS
Voltage Rating (Uo/U)
3.6/6kV; 6/10kV, 8.7/15kV, 12/20kV
Maximum Short Circuit Temperature: 250C
Mobile Condition: -25C to+ 80C
Static Condition: -40C to+ 80C
Minimum Fixed: 6 x overall Bending diameter Radius

STANDARDS
VDE 0295, IEC 60228, VDE 0207 Part 20 & 21, VDE 0250
Part 813, VDE 0298 Part 3, IEC 60811-2-1, EN 60228
Flame Retardant according to IEC/EN 60332-1-2

CONSTRUCTION

Phase Conductor Class 5 flexible stranded tinned copper

Insulation Rubber compound

Semi-Conductive Layers Semi-conductive Semi-conductive rubber tape over layer the on conductor the insulation and inner and outer

Earth Conductor Class 5 tinned copper conductor

Central Filler Semi-conductive compound on a textile polyester support

Inner Sheath Rubber compound

Anti-Torsion Braid Polyester

Outer Sheath Rubber Compound

VOLTAGE kV	NO.OFCORES (PHASE + EARTH)	NOMINAL CROSS SECTIONALAREA mm		CONDUCTOR DIAMETER mm	NOMINAL OVERALL DAMETER mm	MAXIMUM TENSILE LOAD N	NOMINAL WEIGHT kg/km
VOLTAGE kV	NO.OFCORES (PHASE + EARTH)	Phase Conductor	Earth Conductor	CONDUCTOR DIAMETER mm	NOMINAL OVERALL DAMETER mm	MAXIMUM TENSILE LOAD N	NOMINAL WEIGHT kg/km

3.6/6	3+3	25	25/3	6.9	39.7	1500	2380
3.6/6	3+3	35	25/3	7.8	43.7	2100	2920
3.6/6	3+3	50	25/3	9.3	46.8	3000	3520
36/6	3+3	70	35/3	11.1	50.7	4200	4430
3.6/6	3+3	95	50/3	12.7	56.7	5700	5580
3.6/6	3+3	120	70/3	14.5	60.5	7200	6770
3.6/6	3+3	150	70/3	16.7	67.15	9000	8260
3.6/6	3+3	185	95/3	17.6	69	11100	9400
6/10	3+3	25	25/3	6.9	39.7	1500	2380
6/10	3+3	35	25/3	7.8	43.7	2100	2920
6/10	3+3	50	25/3	9.3	46.8	3000	3520
6/10	3+3	70	35/3	11.1	50.7	4200	4430
6/10	3+3	95	50/3	12.7	56.7	5700	5640
6/10	3+3	120	70/3	14.5	60.5	7200	6830
6/10	3+3	150	70/3	16.7	70.3	9000	8320
6/10	3+3	185	95/3	17.6	69	11100	9500
8.7/15	3+3	25	25/3	6.9	45.5	1500	2860
8.7/15	3+3	35	25/3	78	47	2100	3210
8.7/15	3+3	50	25/3	9.3	50.3	3000	3830
8.7/15	3+3	70	35/3	11.1	55.9	4200	5000
8.7/15	3+3	95	50/3	12.7	59.3	5700	5870
8.7/15	3+3	120	70/3	14.5	65	7200	7370
8.7/15	3+3	150	70/3	16.7	69.7	9000	8590
8.7/15	3+3	185	96/3	17.6	71.8	11100	9750
12/20	3+3	25	25/3	6.9	47.2	1500	3080
12/20	3+3	35	25/3	78	52.6	2100	3460
12/20	3+3	50	25/3	9.3	54.6	3000	4310
12/20	3+3	70	35/3	11.1	58.4	4200	5310
12/20	3+3	95	50/3	12.7	61.9	5700	6180
12/20	3+3	120	70/3	14.5	67.5	7200	7730
12/20	3+3	150	70/3	16.7	72.2	9000	8970
