(N) Gflcgou Tcwb Screened Rubber Overhead Flat Crane Festoon Elevators Lifting Conveyor Cable
(N) Gflcgou Tcwb Screened Rubber Overhead Flat Crane Festoon Elevators Lifting Conveyor Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
installations where space is at premium and requires smaller bending radius. Copper screens are efficient against
electromagnetic effects. Not suitable for torsional stress.
Standards:
VDE0293-308, DIN VDE 0250-809, DIN VDE 0250-1,
DIN VDE 0298-3, DIN VDE 0472-501, 503, 508,
DIN VDE 0472-401, 402, 602, 303, 615,
DIN VDE 0472-803, 804, VDE 0482-332-1-2,
DIN EN 60332-1-2, IEC 60332-1, HD/EN/IEC 60811-2-1,
DIN VDE 0473-811-2-1
| Number of cores and | Copper | Cond. | Overall | Weight |
| nominal cross section | figure | construction | diameter | |
| (appr. value) | appr. | appr. | ||
| mm2 | kg/km | mm | mm | kg/km |
| 4 x 1,5 | 60,0 | 84 x 0,16 | 6,2 x 17,5 | 200,0 |
| 5 x 1,5 | 75,0 | 84 x 0,16 | 6,2 x 21,5 | 240,0 |
| 7 x 1,5 | 105,0 | 84 x 0,16 | 6,2 x 29,0 | 360,0 |
| 8 x 1,5 | 120,0 | 84 x 0,16 | 6,2 x 31,5 | 370,0 |
| 12 x 1,5 | 180,0 | 84 x 0,16 | 6,5 x 47,0 | 620,0 |
| 24 x 1,5 | 360,0 | 84 x 0,16 | 13,5 x 56,0 | 1.010,0 |
| 4 x 2,5 | 100,0 | 140 x 0,16 | 7,5 x 21,0 | 280,0 |
| 5 x 2,5 | 125,0 | 140 x 0,16 | 7,5 x 27,0 | 400,0 |
| 7 x 2,5 | 175,0 | 140 x 0,16 | 7,5x 35,0 | 520,0 |
| 8 x 2,5 | 200,0 | 140 x 0,16 | 7,5 x 39,0 | 550,0 |
| 12 x 2,5 | 300,0 | 140 x 0,16 | 8,0 x 56,0 | 800,0 |
| 24 x 2,5 | 600,0 | 140 x 0,16 | 17,0 x 72,5 | 1.690,0 |
| 4 x 4 | 160,0 | 224 x 0,16 | 9,0 x 26,0 | 410,0 |
| 4 x 6 | 240,0 | 192 x 0,21 | 9,5 x 29,0 | 600,0 |
| 4 x 10 | 400,0 | 320 x 0,21 | 11,0 x 33,0 | 800,0 |
| 4 x 16 | 640,0 | 512 x 0,21 | 13,0 x 38,0 | 1.150,0 |
| 4 x 25 | 1.000,0 | 800 x 0,21 | 15,0 x 49,5 | 1.700,0 |
| 4 x 35 | 1.400,0 | 280 x 0,41 | 17,0 x 55,0 | 2.200,0 |
| 5 x 4 | 200,0 | 224 x 0,16 | 9,0 x 32,0 | 560,0 |
| 5 x 6 | 300,0 | 192 x 0,21 | 9,5 x 35,0 | 650,0 |
| 5 x 16 | 800,0 | 512 x 0,21 | 13,0 x 50,0 | 1.450,0 |
| 7 x 4 | 280,0 | 224 x 0,16 | 9,0 x 42,0 | 700,0 |
| 7 x 6 | 420,0 | 192 x 0,21 | 9,5 x 44,5 | 850,0 |
| 7 x 10 | 700,0 | 320 x 0,21 | 12,1 x 63,5 | 1.350,0 |
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China (N) Gflcgou Tcwb Screened Rubber Overhead Flat Crane Festoon Elevators Lifting Conveyor Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
