Mv-105 Mv-10 5kv 8kv 15kv 25kv 35kv Tr-XLPE Wire Shielded Insulated Medium Voltage Urd Cable

Mv-105 Mv-10 5kv 8kv 15kv 25kv 35kv Tr-XLPE Wire Shielded Insulated Medium Voltage Urd Cable image

Get Latest Price Request a quote

Product Details

Model NO.

TR-XLPE cable

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

YJV

Brand

Huadong

Product Name

Tr-XLPE Medium Voltage Cable

Rated Voltage

5kv 8kv 15kv 25kv 35kv

Cross Section Size

6 4 2 1 1/0 2/0 3/0 4/0 AWG

Cores

Single Core

Temperature

-40 to 90 Centigrade

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

MV-105 MV-10 5kV 8kV 15kV 25kV 35kV TR-XLPE Wire Shielded Insulated Medium Voltage URD Cable

Primary power and distribution circuits in industrial and commercial installations, power circuits in generating plants where line to ground fault current are within shield capabilities.

Type MV cables may be used in wet or dry locations, indoors or outdoors, installed in any raceway, open air,aerial messenger supported, underground duct, or directly buried if installed with a grounding conductor in close proximity complying with NEC Section 250.4(A)(5).

Features
UL listed as MV-105. Jacket is rated as Sunlight Resistance and Oil Resistance I.True Triple extrusion system and closed handling raw materials system, to eliminate any contact with ambient, until extrusion process ends.On request, two abration resistant ripcords placed longitudinally 180° appart for easy jacket removale line to ground fault current are within shield capabilities.

1. Conductor: Soft annealed uncoated copper compacted Class B per ASTM B496 or hard drawn Aluminum-1350 compacted Class B per ASTM B400.
2. Conductor Shield: Semi conducting cross-linked polyethylene (XLPE) .
3. Insulation: Thermoset tree retardant cross-linked polyethylene (TR-XLPE).
4. Insulation Shield: Semi conducting cross-linked polyethylene (XLPE).
5. Metallic Shield: Solid soft annealed uncoated copper wires per ASTM B3, helically applied and uniformly spaced. On request options: copper tape shield and ripcords.
6. Binder Tape: A suitable tape, as required.
7. Jacket: Black sunlight resistance and flame retardant polyvinyl chloride (PVC) compound.

Size AWG or kcmil	Number of Strands	100% Insulation Level (175 mil)					133% Insulation Level (220 mil)
		Nominal Diameter		Approximate Outside Diameter	Approximate Net Weight		Nominal Diameter		Approximate Outside Diameter	Approximate Net Weight
		Over Insulation	Jacket Thickness		Approximate Net Weight		Over Insulation	Jacket Thickness		Approximate Net Weight
		Over Insulation	Jacket Thickness		Copper	Aluminum	Over Insulation	Jacket Thickness		Copper	Aluminum
/		in	mil	in	lb/kft		in	mil	in	lb/kft
2	7	0.65	80	0.94	524	382	0.74	80	1.03	583	441
1	19	0.68	80	0.97	591	412	0.77	80	1.06	652	472
1/0	19	0.72	80	1.01	677	450	0.81	80	1.1	740	513
2/0	19	0.76	80	1.05	781	495	0.85	80	1.14	847	561
3/0	19	0.81	80	1.1	912	551	0.9	80	1.19	980	619
4/0	19	0.86	80	1.15	1073	618	0.95	80	1.24	1144	689
250	37	0.92	80	1.2	1226	689	1.01	80	1.32	1323	785
300	37	0.97	80	1.25	1405	760	1.06	80	1.37	1505	861
350	37	1.01	80	1.32	1606	852	1.1	80	1.41	1687	933
400	37	1.05	80	1.37	1782	922	1.14	80	1.46	1865	1005
500	37	1.13	80	1.44	2130	1055	1.22	80	1.53	2218	1142
600	61	1.22	80	1.53	2491	1201	1.31	80	1.62	2584	1293
750	61	1.31	80	1.62	3003	1390	1.4	110	1.78	3205	1592
1000	61	1.47	110	1.84	3960	1810	1.56	110	1.96	4118	1968

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables

1.You are manufacturer or trader ?
Huadong cable is a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for yo

We are China Mv-105 Mv-10 5kv 8kv 15kv 25kv 35kv Tr-XLPE Wire Shielded Insulated Medium Voltage Urd Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
