Multi-Function and High Practicality Instrumentation Cable Individual and Overall Shielded Cable

Multi-Function and High Practicality Instrumentation Cable Individual and Overall Shielded Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Type P Instrumentation Cable

Insulation Material

Polyolefin

Sheath Material

Thermosetting Compound

Material Shape

Round Wire

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

Type P Instrumentation Cable

Brand

Huadong

Product Name

Instrumentation Cable

Rated Voltage

0.6/1kv

Size

18 16 14 AWG

Rated Temperature

110 Degrees C

Warranty

100% Qualified

Sample

Available

Feature

Flexible, Flame Retardant, Oil, Abrasion Resistant

Price

Get Within 12 Hours

Transport Package

Wooden Drum or Steel Wooden Drum or Coil.

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

100 Kilometer/Kilometers Per Month

Product Description

Multi-function and high practicality Instrumentation Cable individual and overall shielded cable

Conductor : Tinned Copper (Class 5)

Insulation : Flame Retardant Polyolefin
Inner Sheath : Chemical And Sunlight Resistant Thermosetting Compound
Armor(Optional) : Tinned Copper Basket Weave Wire
Sheath(Optional) : Chemical And Sunlight Resistant Thermosetting Compound

Application : Designed and Constructed for the Demanding Environments of Offshore Drilling and Petroleum Facilities Located Throughout the World
Features : Super Flexible,Higher Insulation Resistance,Excellent Moisture Resistance,Flame Retardant

Individually Shielded Pairs Flexible Instrumentation Cable
Size AWG	Number of Pairs	Nominal Diameter (inches)	Weight (lbs/MFt.)	Nominal Diameter (inches)	Wei	Nominal Diameter (inches)	Weight (lbs/MFt.)
Size AWG	Number of Pairs	Nominal Diameter (inches)	Weight (lbs/MFt.)	Nominal Diameter (inches)	ght (lbs/MFt.)	Nominal Diameter (inches)	Weight (lbs/MFt.)
18	1	0.336	57	0.386	149	0.535	151
18	2	0.518	140	0.568	223	0.72	294
18	3	0.581	177	0.631	270	0.78	497
18	4	0.625	212	0.675	405	0.82	558
18	5	0.665	257	0.715	359	0.889	505
18	7	0.76	306	0.81	431	1.017	592
18	8	0.782	342	0.832	468	1.027	607
18	10	0.965	468	1.015	625	1.215	1020
18	12	0.99	533	1.04	692	1.261	1089
18	16	1.093	661	1.143	843	1.338	1325
18	18	1.23	776	1.28	973	1.488	1216
18	24	1.442	958	1.492	1194	1.758	1564
16	1	0.356	68	0.406	165	0.56	166
16	2	0.584	190	0.634	282	0.787	501
16	3	0.63	220	0.68	320	0.875	558
16	4	0.648	248	0.698	346	0.893	671
16	5	0.715	299	0.765	420	0.932	541
16	7	0.81	365	0.86	494	1.034	638
16	8	0.885	448	0.935	589	1.114	724
16	10	1.03	763	1.08	736	1.289	1222
16	12	1.065	631	1.115	808	1.31	1014
16	16	1.175	806	1.225	1049	1.396	1237
16	18	1.259	901	1.309	1112	1.504	1317
16	20	1.315	1011	1.365	1222	1.582	1461
16	24	1.472	1120	1.522	1361	1.755	1685
14	1	0.386	87	0.436	149	0.589	193
14	2	0.634	264	0.684	365	0.879	543
14	3	0.67	348	0.72	375	0.811	448
14	4	0.736	324	0.786	440	0.991	799
14	5	0.772	392	0.822	515	1.031	678
14	7	0.929	528	0.979	676	1.187	866
14	8	0.956	548	1.006	736	1.18	911
14	10	1.117	706	1.167	886	1.35	1077
14	12	1.205	851	1.255	1037	1.45	1275

We are China Multi-Function and High Practicality Instrumentation Cable Individual and Overall Shielded Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
