Mining Induatry Industrial 61A 63 61b Non-Reeling Low Mass Type 622 Cables Reeling Cable

Mining Induatry Industrial 61A 63 61b Non-Reeling Low Mass Type 622 Cables Reeling Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Type 63

Current

DC & AC

Insulation Material

Epr Rubber

Sheath Material

CR Rubber

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CE, VDE

Brand

Huadong

Product Name

Trailing Cable

Core

3+3 Core

Size

25-240mm

Rated Voltage

640/1100V

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

SANS Type 63 TYPE 61A 1.9/3.3 kV 1900/3300v Reeling Mining Cable

Construction:

6 core cables with three screened power cores laid up around a semiconducting cradle centre (25 to 95 mm2) or dummy centre (120 to 240 mm²) and three unscreened pilot cores, one in each interstice.Reinforced CR sheath (or equiva-ent)

Typical uses:

Sef propelled electrically driven machines,movaoe electric apparatus in hazardous areas (Minerals Act, 1991), typically stackers, reclaimers, shearers and Conveyor systems.

Cable type	Type 63 1,9/3,3 kV to SANS 1520-1
Conductors	Flexible class 5 comply to SANS 1411 – 1 from tinned annealed copper wires left lay
Insulation	Ethylene propylene thermosetting compound type RD 3 comply to SANS 1411-3
Insulation screen	The braid of tinned copper wires .
Cable assembly	Three tinned copper braided screened power cores and three unscreened pilot cores one in each interstice laid up in the right hand lay around semi-conductive cradle centre .
Internal sheath	Poly-chloroprene thermosetting compound type RS 6 comply to SANS 1411-3 .
Reinforcing braid	An open nylon braid . Minimum 16 of nylon strings .
