Medium Voltage Power Mv90, Mv105 Industrial Mv-90 UL1072 Certificate Cable

Medium Voltage Power Mv90, Mv105 Industrial Mv-90 UL1072 Certificate Cable image

Get Latest Price Request a quote

Product Details

Model NO.

MEDIUM VOLTAGE POWER CABLE MV90, MV105

Current

DC & AC, LLDPE, MDPE, PVC

Insulation Material

XLPE

Material Shape

Round Wire, Aluminum, Bare Copper Wire

Certification

ISO, CCC, RoHS, Rneda

Products Name

Medium Voltage Power Cable, Mv90, Mv105

UL Listed Type

Mv90, Mv105

Standard

UL1072, Icea S-93-639

Rated Voltage

5kv, 8kv, 15kv, 25kv, 35kv

Insulation

Tr-XLPE, Epr

Sheath

LLDPE, PVC

Working Temperture

Max 90 Degree or 105degre

Sheath with Strip

Red Strip

Insulation Level

100% or 133%

Sample Available

Yes

Transport Package

Reel as Your Requirements

Specification

8AWG TO 1000MCM

Trademark

RENDA

Origin

China

HS Code

8544492100

Production Capacity

10000000FT/Month

Product Description

Medium Voltage Industrial 15kv 35kv Xlp Epr Urd Mv-90 & Mv-105 Power Cable UL Type 1072 Icea 94 649 Electric Aluminum Conductor Underground Distribution Wire

Applications

For use in power circuits up to 35 kV when installed in the open air, conduit, duct, or direct buried, for wet and dry locations. Used for power applications in chemical plants, refineries, steel mills, industrial plants, utility substations and generating stations

Standards & References
Primary UD TRXLP Cable meets or exceeds the following ASTM specifications:
• B3 Soft Annealed Copper Wire
• B8 Concentric-Lay-Stranded Copper Conductors, Hard, Medium-Hard or Soft
• B230 Aluminum, 1350-H19 Wire for Electrical Purposes
• B231 Aluminum 1350 Conductors, Concentric-Lay-Stranded
• B609 Aluminum 1350 Round Wire, Annealed and Intermediate Tempers, for Electrical Purposes

UD TRXLP Cable is manufactured to the latest edition of the following specifications, and
in case of specification conflicts, in the order listed:
• ANSI/ICEA S-94-649
• AEIC CS-8
• UL1072, When Specified

Construction
Conductors: Bare, annealed copper per ASTM B-3, aluminum compact conductor.
Internal semiconductor: Screen over the conductor, made of thermosetting semiconductor material.
Insulation: Cross-linked polyethylene (XLPE)/Ethylene propylene rubber (EPR), in dry atmosphere catenary tube, through a triple layer extrusion process.
External semiconductor: Screen over the insulation, made of thermosetting and strippable semiconductor material.
Metallic screen: Screen of copper wires.
External sheath: PVC, red or black color.LLDPE

Temperature Range: -40°C to +90/105°C
Voltage Rating: 5KV 8KV 15KV 25KV 35KV

Phase Conductor		Neutral		Thickness Per Cond. (mils)			Diameter (mils)				Weight 1000 feet (lbs.)	Allowable Ampacities+
Size (AWG or kcmil)	Strand-ing	No. of Wires	Size (AWG)	Nominal Insul.	Insul. Shield min. Point	Approx. Jkt.	Bare Phase Cond.	Over Insul.	Over Insul. Shield	Comp. Cable	Comp. Cable	Direct Burial	In Ducts
ALUMINUM CONDUCTOR – 100% INSULATION LEVEL
2	Solid	10	14	175	30	50	258	653	733	961	453	168*	119*
2	7	10	14	175	30	50	283	678	758	986	470	168*	119*
1	Solid	13	14	175	30	50	289	685	765	993	520	193*	137*
1	19	13	14	175	30	50	322	718	798	1026	539	193*	137*
1/0	Solid	16	14	175	30	50	325	720	800	1028	591	218*	155*
1/0	19	16	14	175	30	50	352	748	828	1056	609	218*	155*
2/0	19	20	14	175	30	50	395	790	870	1098	703	248*	177*
3/0	19	25	14	175	30	50	443	838	918	1146	817	284*	201*
4/0	19	20	12	175	30	50	498	893	973	1234	993	324*	230*
250	37	16	10	175	30	50	558	963	1043	1346	1213	360*	257*
350	37	18	14	175	40	50	661	1068	1168	1396	1055	389**	319**
500	37	25	14	175	40	50	789	1193	1293	1521	1349	468**	384**
750	61	24	12	175	40	80	968	1383	1483	1798	1946	569**	468**
1000	61	20	10	175	40	80	1117	1530	1630	1988	2473	642**	542**
1250	91	25	10	220	55	80	1250	1765	1895	2253	3142	688**	604**
1500	91	30	10	220	55	80	1370	1885	2015	2373	3616	726**	637**

We are China Medium Voltage Power Mv90, Mv105 Industrial Mv-90 UL1072 Certificate Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
