Medium Voltage Mv Cu/Trxlpe/Cws (1/0AWG) /PVC/Aia/PVC Teck 90 5kv 15kv Power Cable

Medium Voltage Mv Cu/Trxlpe/Cws (1/0AWG) /PVC/Aia/PVC Teck 90 5kv 15kv Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Teck90 power cable

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

RoHS

Brand

Huadong

Rated Voltage

5kv 15kv

Size

14 16 18 AWG Ect

Standard

CSA Std. C22.2

Sample

Available

Pairs

1 3 Cores

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Teck 90 5KV 1C 3C Shielded Single Three 1 3 Conductor 115 90 MIL 100% 133% Aluminum XLPE AIA Interlocked Armour power cable

APPLICATIONS:
Suitable for use in ventilated, non-ventilated and ladder cable trays, direct earth burial or raceways, and for exposed or concealed wiring in wet, damp or dry locationsSuitable for use in wet or dry locations when installed in accordance with the NEC
Suitable for use in all hazardous locations when used with certified HL cable glands

CONSTRUCTION:
Conductor: Bare copper Class B compact or compressed stranded
Conductor Shield: Extruded thermoset semi-conducting shield
Insulation: Tree-Retardant Cross-Linked Polyethylene (TR-XLPE)
Insulation Shield: Extruded thermosetting semi-conducting shield
Metallic Shield: Helically applied 15% gapped copper tape
Ground (Bonding) Conductor: Stranded bare copper conductor
Inner Jacket: Flame-retardant and moisture resistant Polyvinyl Chloride (PVC)
Armour: Aluminum Interlocked Armour (AIA)
Outer Jacket: Low-temperature, moisture and sunlight resistant Polyvinyl Chloride (PVC), orange or customized
Options: Galvanized Steel Interlocked Armour (GSIA) / Other coloured outer jacket and constructions available upon request / Helically applied 20% overlapped copper tape shield

CABLE PARAMETERS:

Cond. Size	Bonding Wire Size	Insul. Tickness Inches (mm)	Inner Jacket Thickness Inches (mm)	Inner Jacket Diameter Inches (mm)	Armour Diameter	Outer Jacket Diameter Inches (mm)
6	8	0.09 (2.29)	0.08 (2.04)	1.051 (26.69)	1.326 (33.68)	1.435 (36.45)
4	8	0.09 (2.29)	0.08 (2.04)	1.146 (29.11)	1.421 (36.09)	1.530 (38.86)
2	6	0.09 (2.29)	0.08 (2.04)	1.266 (32.15)	1.541 (39.14)	1.670 (42.42)
1	6	0.09 (2.29)	0.08 (2.04)	1.335 (33.91)	1.610 (40.89)	1.739 (44.17)
1/0	6	0.09 (2.29)	0.08 (2.04)	1.415 (35.95)	1.690 (42.93)	1.819 (46.20)
2/0	6	0.09 (2.29)	0.08 (2.04)	1.500 (38.10)	1.775 (45.09)	1.904 (48.36)
3/0	4	0.09 (2.29)	0.08 (2.04)	1.606 (40.80)	1.956 (49.68)	2.09 (53.09)
4/0	4	0.09 (2.29)	0.08 (2.04)	1.724 (43.79)	2.074 (52.68)	2.208 (56.08)
250	4	0.09 (2.29)	0.11 (2.80)	1.882 (47.80)	2.232 (56.69)	2.366 (60.10)
350	3	0.09 (2.29)	0.11 (2.80)	2.094 (53.19)	2.444 (62.08)	2.578 (65.48)
500	3	0.09 (2.29)	0.11 (2.80)	2.355 (59.81)	2.705 (68.71)	2.839 (72.11)
750	3	0.09 (2.29)	0.11 (2.80)	2.914 (74.01)	3.164 (80.36)	3.318 (84.288)

For other sizes,pls contact us!
