Marine Line Flex Yzp Yzafp X-Fr X-Frsw 0.6/1 Kv Stranded Copper XLPE Insulated Low Voltage Marine Power Cable

Marine Line Flex Yzp Yzafp X-Fr X-Frsw 0.6/1 Kv Stranded Copper XLPE Insulated Low Voltage Marine Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YZp

Current

DC & AC

Insulation Material

XLPE

Sheath Material

Flame Retardant Halogen Free Polyolefin Compound

Material Shape

Round Wire

Wire Core Material

Stranded Tinned Copper

Certification

ISO, CE, VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Cores

1-5 Cores Ect

Size

1.5-300mm2

Standard

IEC 60092-350/-360/-353

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Marine Line Flex YZp YZafp X-FR X-FRSW 0.6/1 kV Stranded Copper XLPE Insulated Low Voltage Marine Power Cable

Application:

Lightweight, unarmoured, reduced diameter low voltage power cables for power and lighting applications in all ship areas.

Characteristics:
• Class 2 conductors
• Lightweight, reduced diameter
• Halogen-free and low smoke, flame retardant
• Excellent abrasion resistance
• Different color outer sheaths, other than black, available on request
• DC voltage: 0,9/1,5 kV (if voltage to earth does not exceed 0,9 kV)

Cable Parameters

Certified for shipboard application   Yes

Standardization   IEC 60092-350/-360/-353

Conductor material   Copper

Conductor surface   Bare

Standardization conductor material   IEC 60228

Shape of conductor   Round

Conductor category   Class 2 = stranded

Material core insulation   Crosslinked polyethylene (XLPE)

Conductor coding in accordance with HD 308 S2   Yes

Material outer sheath   Flame Retardant Halogen Free Polyolefin Compound

Colour outer sheath   Black

Flame retardant   IEC 60332-1 / IEC 60332-3-22 Cat. A

Halogen free   IEC 60754-1/2

Low smoke   IEC 61034-2

UV resistant   Yes

UV protection   NEN EN 50289-4-17A

UV rating   Very good / Test duration >= 6000 h

Max. conductor temperature   90 °C

Transportation and storage temperature   -40 / 50 °C

Permitted cable outer temperature during assembling/handling   -20 / 50 °C

Permitted cable outer temperature after assembling without vibration   -40 / 70 °C

Construction	Net weight (kg/m)	Outer diameter approx. (mm)	Min. bending radius during installation (mm)	Min. bending radius after installation (mm)	Colour insulated wires
2 x 1,0 mm² Black	0.053	7	56	28	Blue – Brown
1 x 1,5 mm² Black	0.036	4.8	33	19	Black
2 x 1,5 mm² Black	0.066	7.6	54	31	Blue – Brown
3 x 1,5 mm² Black	0.086	8	65	32	Brown – Black – Grey
3 G 1,5 mm² Black	0.086	8	56	32	Green/Yellow – Blue- Brown
4 G 1,5 mm² Black	0.112	8.9	63	36	Green/Yellow – Brown – Black – Grey
4 x 1,5 mm² Black	0.112	8.9	63	36	Blue – Brown – Black – Grey
5 G 1,5 mm² Black	0.141	9.8	69	40	Green/Yellow – Blue- Brown – Black – Grey
5 x 1,5 mm² Black	0.141	9.8	79	40	Blue – Brown – Black – Grey – Black
6 x 1,5 mm² Black	0.17	10.6	75	43	Black, with white printed numbers
7 G 1,5 mm² Black	0.177	10.6	75	43	Green/Yellow – Black, with white printed numbers
7 x 1,5 mm² Black	0.176	10.6	75	43	Black, with white printed numbers
8 x 1,5 mm² Black	0.235	12.7	89	51	Black, with white printed numbers
10 x 1,5 mm² Black	0.256	13.6	96	55	Black, with white printed numbers
12 x 1,5 mm² Black	0.297	14.3	100	58	Black, with white printed numbers
14 x 1,5 mm² Black	0.339	15.2	105	60	Black, with white printed numbers
16 x 1,5 mm² Black	0.385	16	112	64	Black, with white printed numbers
19 x 1,5 mm² Black	0.45	17.4	122	70	Black, with white printed numbers
20 x 1,5 mm² Black	0.471	17.8	125	72	Black, with white printed numbers
24 x 1,5 mm² Black	0.564	19.4	136	78	Black, with white printed numbers
27 x 1,5 mm² Black	0.621	20.4	143	82	Black, with white printed numbers
30 x 1,5 mm² Black	0.703	21.8	155	85	Black, with white printed numbers
1 x 2,5 mm² Black	0.048	5.5	44	22	Black
2 x 2,5 mm² Black	0.092	8.7	61	35	Blue – Brown
3 x 2,5 mm² Black	0.121	9.2	65	37	Brown – Black – Grey
3 G 2,5 mm² Black	0.122	9.2	77	37	Green/Yellow – Blue- Brown
4 G 2,5 mm² Black	0.153	10	80	40	Green/Yellow – Brown – Black – Grey
4 x 2,5 mm² Black	0.151	10	70	40	Blue – Brown – Black – Grey
5 x 2,5 mm² Black	0.197	11.2	80	45	Blue – Brown – Black – Grey – Black
5 G 2,5 mm² Black	0.197	11.2	79	45	Green/Yellow – Blue- Brown – Black – Grey
6 x 2,5 mm² Black	0.236	12.2	86	49	Black, with white printed numbers
7 x 2,5 mm² Black	0.248	12.2	86	49	Black, with white printed numbers
7 G 2,5 mm² Black	0.249	12.2	86	49	Green/Yellow – Black, with white printed numbers
12 x 2,5 mm² Black	0.425	16.2	115	65	Black, with white printed numbers
19 x 2,5 mm² Black	0.66	20	140	80	Black, with white printed numbers
27 x 2,5 mm² Black	0.915	23.3	165	95	Black, with white printed numbers
1 x 4 mm² Black	0.064	5.9	42	24	Black
2 x 4 mm² Black	0.125	9.6	68	39	Blue – Brown
3 G 4 mm² Black	0.169	10.2	72	41	Green/Yellow – Blue- Brown
3 x 4 mm² Black	0.169	10.2	72	41	Brown – Black – Grey
4 G 4 mm² Black	0.222	11.4	80	46	Green/Yellow – Brown – Black – Grey
4 x 4 mm² Black	0.223	11.4	80	46	Blue – Brown – Black – Grey
5 G 4 mm² Black	0.279	12.5	88	50	Green/Yellow – Blue- Brown – Black – Grey
5 x 4 mm² Black	0.279	12.5	88	50	Blue – Brown – Black – Grey – Black
