Manufacturer Directly Sale UL1569 Mc Cable Thhn Xhhw 12/2 12/3 12/4 AWG

Manufacturer Directly Sale UL1569 Mc Cable Thhn Xhhw 12/2 12/3 12/4 AWG image

Get Latest Price Request a quote

Product Details

Model NO.

12/2 12/3 12/4 10/2 10/3 8/2 8/3

Application

Building, House, Comercial,Industrial

Conductor Material

Copper or Aluminum

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Commercial Buildings and Industrial Environment

Certification

ISO9001, CCC, RoHS

Brand

Rneda

Product Name

Mc Cable

Certificate

UL1569

Rated Voltage

Low Voltage 600V

Cross Section

14AWG-1000kcmil Metal-Clad Cable Mc Cable

Jacket

Aluminum Alloy AA8000

Insulation

PVC or XLPE UL83 or UL44

Related Cables

Nm-B Building Wire, Tc Cable, Soow Cables

Transport Package

Standard Export Drums

Specification

12/2 12/3 14/2 14/3 8/2 10/3

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000000meter Per Month

Product Description

Manufacturer Directly Sale UL1569 MC Cable THHN XHHW 12/2 12/3 12/4 AWG

The metal-clad cable may be used as a general-purpose control cable in the mining, petroleum, pulp, paper, and chemical industries. It is also commonly used in commercial buildings and other industrial environments. It is suitable for use in direct burial applications, or on walls or beams. It may also be used as exposed or concealed wiring (dry or wet),or in ventilated, non-ventilated,or ladder-type tray cable (dry or wet).

Description of purpose

MC cable is suitable for use as bellow:

1. Branch, feeder and service power distribution

2. Power, lighting, control and signal circuit.

3. Fished or embedded in plaster

Construction

Conductor: Copper
Insulation: XLPE
Wrap: Polyester
Armor: Aluminum or Steel Interlocked Armor
Outer Jacket: PVC

Technical Specifications

Detailed products description:

1, UL standard: UL1569

2.MC cable(Metal clad)

3.specification:14awg-4/0awg

4.voltage rate:600v

MC cable, USA, UL & NEC standard, armored cable, metal-clad cable, AC cable, BX cable, TECK cable, interlocked armored cable

Armor	Interlocked Aluminum Strip
Inner Conductor	Solid/ Stranded Copper
Conductor Insulation	THHN/ THWN OR XHHW-2
Assembly Covering	Polypropylene Tape
Temperature Rating	≤ 90 (dry); ≤ 75 (wet)
Grounding	Insulated Green Grounding Conductor
Voltage Rating	600V

The largest UL cable manufacturer in China

Top 10 Cable manufactuer in China.

Largest Rubber cable manufacturer in China.
Leading ESP cable manufacturer.
Professional OEM manufacturer.
With UL,TUV,KEMA,CE,BV,PSB,SABS,MSHA,GL,NKK,KR,DNV,CCS certifications.
With TUV TYPE TESTING REPORT.

With ISO9001,ISO14001,ISO45001 syetem certifications.
ISO 17025 standard and CNAS approval laboratory.

Our service:
1. 30 years production experience and 22 years export experience .

2.Products certification :UL, CUL,CSA,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

We are China Manufacturer Directly Sale UL1569 Mc Cable Thhn Xhhw 12/2 12/3 12/4 AWG manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
