LV Single 1 2 4 5 Core 25mm 70mm 95mm2 185mm Aluminium Aerial Bundled Overhead ABC Power Cable Price List for South Africa
LV Single 1 2 4 5 Core 25mm 70mm 95mm2 185mm Aluminium Aerial Bundled Overhead ABC Power Cable Price List for South Africa image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
ABC
Application
Overhead
Conductor Material
Copper
Sheath Material
XLPE/PE/PVC
Insulation Material
XLPE/PE/PVC
Material Shape
Round Wire
Range of Application
Overhead
Certification
ISO9001, CE, CCC
Brand
Chunbin
Rated Voltage
0.6/1kv
Number of Cores
1/2/3/4/5
Insulation
PVC/PE/XLPE
Packing
Roll
Conductor
Aluminum/Aluminum Alloy
MOQ
500 Meters
Length
Lengths Customize
Product Name
Overhead Cable
Rated Temperature
90′c
Transport Package
Cartons, Wooden Drum, Soft
Trademark
Chunbin
Origin
Luoyang, Henan
Production Capacity
300, 000m/Week
Product Description
Products Description
|
Conductor
|
Aluminum/Aluminum Alloy/ACSR
|
|
Insulation
|
XLPE/PE
|
|
Application
|
Overhead
|
|
Rated Voltage
|
600V-1000V/1KV-35KV
|
|
Number of Cores
|
One Core or Multi-Cores
|
|
MOQ
|
500 Meters
|
OVERHEAD CABLE
ABC cables primarily used for 120 volt overhead service applications such as street lighting.outdoor lighting.and temporary service for construction. To be used at voltage of 600 volts phase- to -phase or less and at conductor temperatures not to exceed 75C for polyethylene insulated conductors or 90’C for crosslinked polyethylene(XLPE) insulated conductors.
Parameter
| Code Name | Phase Conductor | Bare Neutral Messenger | Weight Per 1000ft(lbs) | Rating (Amps) | ||||||
| Size AWG | Strand | Insulation Thickness (mls) | Size AWG | Strand | Breaking Strength(lbs) | XLPE | Poly | XLPE | Poly | |
| AAC NEUTRAL-MESSENGER | ||||||||||
| Clydesdale | 4 | Solid | 45 | 4 | 7 | 881 | 208 | 201.8 | 100 | 80 |
| Pinto | 4 | 7/w | 45 | 4 | 7 | 881 | 223 | 207.9 | 100 | 80 |
| Mustang | 2 | 7/w | 45 | 2 | 7 | 1350 | 333 | 312.6 | 135 | 105 |
| Criollo | 1/0 | 19/w | 60 | 1/0 | 7 | 1990 | 529 | 504.5 | 180 | 140 |
| Percheron | 2/0 | 19/w | 60 | 2/0 | 7 | 2510 | 649 | 620.5 | 205 | 160 |
| Hanoverian | 3/0 | 19/w | 60 | 3/0 | 19 | 3310 | 799 | 765.6 | 235 | 185 |
| Oldenburg | 4/0 | 19/w | 60 | 4/0 | 19 | 4020 | 986 | 946.7 | 275 | 210 |
| Lippizaner | 336.4 | 19/w | 80 | 336.4 | 19 | 6146 | 1546 | 1519.2 | 370 | 280 |
| ACSR NEUTRAL-MESSENGER | ||||||||||
| Morochuca | 6 | Solid | 45 | 6 | 6/1 | 1190 | 152 | 147.4 | 75 | 60 |
| Chola | 6 | 7/w | 45 | 6 | 6/1 | 1190 | 162 | 151.7 | 75 | 60 |
| Morgan | 4 | Solid | 45 | 4 | 6/1 | 1860 | 226 | 220 | 100 | 80 |
| Hackney | 4 | 7/w | 45 | 4 | 6/1 | 1860 | 241 | 226.1 | 100 | 80 |
| Palomino | 2 | 7/w | 45 | 2 | 6/1 | 2850 | 362 | 342.6 | 135 | 105 |
| Costena | 1/0 | 19/w | 60 | 1/0 | 6/1 | 4380 | 575 | 550.6 | 180 | 140 |
| Grullo | 2/0 | 19/w | 60 | 2/0 | 6/1 | 5310 | 707 | 678.7 | 205 | 160 |
| Suffolk | 3/0 | 19/w | 60 | 3/0 | 6/1 | 6620 | 872 | 838.9 | 235 | 185 |
| Appaloosa | 4/0 | 19/w | 60 | 4/0 | 6/1 | 8350 | 1079 | 1039.2 | 275 | 210 |
| Bronco | 336.4 | 19/w | 80 | 336.4 | 18/1 | 8580 | 1613 | 1568.2 | 370 | 280 |
| Gelding | 336.4 | 19/w | 80 | 4/0 | 6/1 | 8350 | 1548 | 1494.3 | 370 | 280 |
| 6201 ALLOY NEUTRAL-MESSENGER | ||||||||||
| Bay | 6 | Solid | 45 | 6 | 7 | 1110 | 145 | 140 | 75 | 60 |
| French Coach | 6 | 7/w | 45 | 6 | 7 | 1110 | 155 | 144.3 | 75 | 60 |
| German Coach | 4 | Solid | 45 | 4 | 7 | 1760 | 215 | 208.3 | 100 | 80 |
| Arabian | 4 | 7/w | 45 | 4 | 7 | 1760 | 229 | 214.4 | 100 | 80 |
| Belgian | 2 | 7/w | 45 | 2 | 7 | 2800 | 344 | 323.1 | 135 | 105 |
| Shetland | 1/0 | 19/w | 60 | 1/0 | 7 | 4460 | 546 | 521.1 | 180 | 140 |
| Thoroughbed | 2/0 | 19/w | 60 | 2/0 | 7 | 5390 | 670 | 641.5 | 205 | 160 |
| Trotter | 3/0 | 19/w | 60 | 3/0 | 7 | 6790 | 825 | 791.8 | 235 | 185 |
| Walking | 4/0 | 19/w | 60 | 4/0 | 7 | 8560 | 1019 | 979.7 | 275 | 210 |
Packing & Delivery
Package: Generally, pack in rolls or wooden drums. Accept customized service for free.
Rolls, Wooden Drums, Steel Drums, Reels
Delivery: Both 20GP container and 40GP container are supplied.
Air transportation, Sea transportation, Express delivery.
Air transportation, Sea transportation, Express delivery.
Our Factory
00:0
Chunbin Cable Group Co.,Ltd. was founded in 1989.it has five core subsidiaries,including copper processing,PVC cable pellets production and more than 50 cooperative enterprises,With more than 600 sales outlets nationwide.It is a specialized company integrating R&D manufacturing and sales.
Chunbin Cable Group Co.,Ltd. was founded in 1989.it has five core subsidiaries,including copper processing,PVC cable pellets production and more than 50 cooperative enterprises,With more than 600 sales outlets nationwide.It is a specialized company integrating R&D manufacturing and sales.
Our company mainly produces:mineral insulated cable,photovoltaic cablecharging pile cable,OPLC rail transit cable, optical fiber composite cable, medium and low voltage XLPE insulated power cable, pvc insulated power cable,aluminum alloy cable,fire resistant cable,flame retardant cable,control cable. overhead insulated cable, low-smoke halogen-free cable,rubbercable,mining cable,aluminum stranded wire and steel core aluminum stranded wire,PVC insulated wire and cord,shielded monitoring line, protection More than 50 varieties, more than 1000 specifications,such as line,agricultural land embedding, anti-aging line, coaxial cable. At the same time, it can also produce British standard American standard and German standard wire and cable, and customize special type wire and cable for customers.
Certifications
Our company strictly controls the quality of products. The products have passed the inspections of the national , provincial and municipal quality supervision departments for many years, and successfully passed the Chinese state. These certifications includes compulsory product certification, coal mine safety certification, national industrial product production license and ISO9001 international quality management system certification. It has obtained the national certificate of use of flame retardant products and is qualified as a foreign trade operator.
FAQ
1.Are you a factory or trade company ?
We are a professional cable manufacturer with 31 years experience. The factory is located in Luoyang, Henan province, China.
2.Whether these products quality assured ?
Most of cables are certificated. Also, we have strict QC, all products are tested before delivery. Quality is assured.
3.When I want customized products, how to do?
Contacting our customers survice, we have a professional R&D team and quality inspection team that can customize products according to customer’s needs.
4.Can you send a sample for us to test?
If we have inventory, you can get 1-5meters sample for free, but freight cost need to be paid by your compony. If need a lot of samples , sample and freight cost have to be paid by your esteemed company. We will return the sample cost to you when we receiving your initial order.
5.If we want to purchase, how to pay ?
Generally we do T/T in 30% deposit before production, 70% balance against copy of B/L . Also payment terms are negotiable depending on customer’s request.
6.When you arrange delivery after we place an order ?
Normally,we will arrange delivery in 7-15 days after order , and negotiation is allowed according to your quantity.
7.After I pay, what about shipping method?
Goods can be delivered by air, by express or by sea; International Express as FEDEX, UPS, DHL, TNT; You can choose the best way as you wish.
We are China LV Single 1 2 4 5 Core 25mm 70mm 95mm2 185mm Aluminium Aerial Bundled Overhead ABC Power Cable Price List for South Africa manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
