Low Voltage Cu/XLPE/PVC 1X10 10mm Single Core Copper Power Cable
Low Voltage Cu/XLPE/PVC 1X10 10mm Single Core Copper Power Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Low Voltage YJV Copper Conductor XLPE Insulation PVC Sheath Single Core Power Cable
Application
Single core power cables are indicated for the transport and distribution of low voltage electricity. Recommended for industrial connections, service connections, internal distribution and outdoor connections. It can be used in underground networks and permanent installations.
1. Conductor: Stranded Copper, Class 2
2. Insulation: Cross-Linked Polyethylene (XLPE)
3. Sheath:PVC
4.Armour:Unarmored Copper Cable
|
0.6/1KV CU XLPE Insulation PVC Single Core Power Cable Parameter
|
||||
|
Nominal cross-sectional area
|
Insulation thickness
|
Sheath thickness
|
Approx.overall
dimaeter of cable |
Approx. weight
of cable(kg/km) |
|
mm2
|
mm
|
mm
|
mm
|
|
|
1×1.5
|
0.7
|
1.4
|
5.9
|
43.2
|
|
1×2.5
|
0.7
|
1.4
|
6.3
|
54.6
|
|
1×4
|
0.7
|
1.4
|
6.9
|
71.7
|
|
1×6
|
0.7
|
1.4
|
7.5
|
92.9
|
|
1×10
|
0.7
|
1.4
|
8.4
|
133.6
|
|
1×16
|
0.7
|
1.4
|
9.4
|
194.4
|
|
1×25
|
0.9
|
1.4
|
10.7
|
286
|
|
1×35
|
0.9
|
1.4
|
11.7
|
379
|
|
1×50
|
1
|
1.4
|
13
|
492.9
|
|
1×70
|
1.1
|
1.4
|
14.9
|
692.1
|
|
1×95
|
1.1
|
1.5
|
16.9
|
950.3
|
|
1×120
|
1.2
|
1.5
|
18.6
|
1175
|
|
1×150
|
1.4
|
1.6
|
20.6
|
1455.4
|
|
1×185
|
1.6
|
1.6
|
22.6
|
1816.4
|
|
1×240
|
1.7
|
1.7
|
25.5
|
2332
|
|
1×300
|
1.8
|
1.8
|
27.8
|
2906.9
|
|
1×400
|
2
|
1.9
|
31.3
|
3797.9
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.
1.Are yuo a manufacturer?
Yes,we are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China Low Voltage Cu/XLPE/PVC 1X10 10mm Single Core Copper Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
