Low Voltage Aluminium Conductor 10mm 4 Core Un-Armoured Custom Cable

Low Voltage Aluminium Conductor 10mm 4 Core Un-Armoured Custom Cable image

Get Latest Price Request a quote

Product Details

Model NO.

LV-AL

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE, VDE

Model

Yjlv, Yjlv32, Yjlv22

Brand

Huadong

Product Name

Low Voltage Aluminium Cable

Rated Voltage

0.6/1kv

Armour

Swa, Sta or Non Armoured

Size

1.5mm-1000mm2

Cores

1 2 3 4 5 Cores

Standards

Ieca, BS, DIN, GB Ect

MOQ

100m

Warranty

100% Qualified

Sample

Available

Color

Black/Blue or Others

Price

Get Within 12 Hours

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Low Voltage LV 0.6/1kv Single 1 2 3 4 5 Core XLPE PVC SWA Armored Underground Aluminium Power Wire Cable
Conductor: Aluminium
Insulation/Jacket: XLPE/PVC
Armoured: SWA(Steel Wire Armoured) / STA(Steel Tape Armoured) or Non-Armoured
Cores: 1, 2, 3, 4, 5, 3+1, 4+1, 3+2
Section Area: 1.5mm2-1000mm2
Standard: IEC 60502, BS 7870, GB/T12706 or other.
Packaging: Iron Or Wooden Drum
Application: Building, Engineered, Railway, Plant construction, School, Hospital, Underground and so on.We can customize
the size according to your requirement.

HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR Copper or aluminium stranded(Class 2) conductors according to lEC 60228
	HIGH RESISTANCE PVC/XLPE INSULATION Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
UV RESISTANCE & FLAME RETARDANT PVC JACKET Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
	CUSTOMIZED DESIGNS Available in Armoured/Non-armoured and Shielded/Non-shielded constructions

Cross Section	Stranding	Approx Weight	Approx Overall Diameter	Current Rating Laid Direct
mm²	mm	kg/km	mm	amp
4 x 2.5	7/0.53	351	12.88	32
4 x 2.5	7/0.67	429	14.43	42
4 x 6.0	7/1.04	670	17.87	69
4 x 10	7/1.35	998	20.1	92
4 x 16	7/1.70	1,272	22.4	119
4 x 25	7/2.14	1,940	27	152
4 x 35	7/2.52	2,390	30.1	182
4 x 50	19/1.78	2,925	31.5	217
4 x 70	19/2.14	4,200	37.4	266
4 x 95	19/2.52	5,335	40.9	319
4 x 120	37/2.03	6,925	46.6	363
4 x 150	37/2.25	8,200	50.2	406
4 x 185	37/2.52	9,975	55.8	458
4 x 240	61/2.52	12,700	62.5	529
4 x 300	61/2.85	15,275	67.4	592
4 x 400	61/3.20	19,875	77	667

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?
The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China Low Voltage Aluminium Conductor 10mm 4 Core Un-Armoured Custom Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
