Low Voltage 0.6/1KV YJV22 4 Core Copper CU XLPE PVC STA Steel Tape Armored Underground Power Cable
Conductor: Stranded Copper
Insulation/Jacket: XLPE/PVC
Armoured: STA(Steel Tape Armoured)
Cores: 2, 3, 4, 5, 3+1, 4+1, 3+2
Section Area: 1.5mm2-800mm2
Standard: IEC 60502, BS 7870, GB/T12706 or other.
Packaging: Iron Or Wooden Drum
Application: Building, Engineered, Railway, Plant construction, Shool, Hospital, Underground and so on.We can customize
the size according to your requirement
|
HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR
Copper or aluminium stranded(Class 2) conductors according to lEC 60228
|
|
|
HIGH RESISTANCE PVC/XLPE INSULATION
Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
|
|
|
UV RESISTANCE & FLAME RETARDANT PVC JACKET
Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
|
|
|
CUSTOMIZED DESIGNS
Available in Armoured/Non-armoured and Shielded/Non-shielded constructions
|
| No.x mm2 | Cores | Cross Section Area | Conductor structure | Approx Overall Diameter | Approx Weight |
|
4×1.5
|
4
|
1.5
|
7/0.53
|
15.1
|
319.1
|
|
4×2.5
|
4
|
2.5
|
7/0.67
|
16.1
|
379.0
|
|
4×4
|
4
|
4
|
7/0.86
|
17.6
|
470.3
|
|
4×6
|
4
|
6
|
7/1.05
|
19.0
|
576.9
|
|
4×10
|
4
|
10
|
7/1.35
|
21.6
|
781.2
|
|
4×16
|
4
|
16
|
7/1.71
|
24.2
|
1068.8
|
|
4×25
|
4
|
25
|
7/2.14
|
27.4
|
1491.4
|
|
4×35
|
4
|
35
|
7/2.55
|
29.9
|
1907.9
|
|
4×50
|
4
|
50
|
10/2.55
|
33.5
|
2457.4
|
|
4×70
|
4
|
70
|
14/2.55
|
39.6
|
3738.1
|
|
4×95
|
4
|
95
|
19/2.55
|
44.5
|
4934.1
|
|
4×120
|
4
|
120
|
24/2.55
|
49.1
|
6026.5
|
|
4×150
|
4
|
150
|
30/2.55
|
54.1
|
7345.1
|
|
4×185
|
4
|
185
|
37/2.55
|
59.4
|
9031.1
|
|
4×240
|
4
|
240
|
48/2.55
|
66.9
|
11456.5
|
|
4×300
|
4
|
300
|
61/2.55
|
72.5
|
14010.8
|
|
4×400
|
4
|
400
|
60/2.97
|
81.8
|
18115.2
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.
We are China Low Voltage 0.6/1kv Yjv22 4 Core Copper Cu XLPE PVC Sta Steel Tape Armored Underground Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
