Product Details

Current

DC & AC

Insulation Material

Epr

Sheath Material

EPDM

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, GB/T 16750, IEEE1017, IEEE1018, IEEE1019

Model

Esp Cable

Brand

Ren Da

Transport Package

Standard Export Drum

Specification

1AWG 2AWG 4AWG 5AWG 6AWG 7AWG

Trademark

RNE DA

Origin

Tangshan, Hebei

HS Code

8544601290

Production Capacity

300km/Month

Product Description

Constructure:

Product Name: ESP Cable
Temperature Rating: 90ºC,120ºC,150ºC,180ºC,204ºC,232ºC,260ºC
Voltage Range: 3kV,4kV,5kV,6kV,8kV
Standards: GB/T 16750,IEEE1017,IEEE1018,IEEE1019,API RP 11S5,API RP 11S6
Main Type: QYPN,QYPNY,QYEQ,QYEQNY,QYYEQ,QYYEQEY,QYYFF,QYYEE
Armor Materials: Galvanized Steel Tape,Stainless Steel Tape,Monel Steel Tape
Main Materials: Copper,NBR,EPDM,PI Film,Lead Sheath,PP,Fluoroplastic,Steel Tape etc.

Date Sheet:

Type	Shape	Conductor	Cond.Size	Insulation	Jacket	Temp.	Voltage	Standard
QYPN	Flat	Copper	AWG 1#	PP	NBR	96ºC	3KV	IEEE1017
QYLPN	Flat	Al-Alloy	AWG2#	PP	NBR	96ºC	4KV	IEEE1018
QYPN Shielded	Flat	Copper	AWG3#	PP	NBR	96ºC	5KV	IEEE1019
QYPF	Flat	Copper	AWG4#	PP	PVC	96ºC	6KV	APIRP 11S5
QYPQ	Flat	Copper	AWG5#	PP	Lead Sheath	110ºC	8KV	APIRP 11S6
QYEN	Flat	Copper	AWG6#	EPDM	NBR	120ºC		GOST
QYYFN	Flat	Copper	AWG7#	Polyimide film & Fluoroplastic	NBR	120ºC-150ºC		GB/T16750
QYEQ	Flat	Copper	AWG8#	EPDM	Lead Sheath	120ºC-232ºC
QYEE	Flat	Copper		EPDM	EPDM	120ºC-232ºC
QYYEE	Flat	Copper		Polyimide film & EPDM	EPDM	120ºC-232ºC
QYYEQ	Flat	Copper		Polyimide film & EPDM	Lead Sheath	232ºC
QYYFF	Flat	Copper		Polyimide film & Fluoroplastic	Fluoroplastic	250ºC
QYPNY	Round	Copper		PP	NBR	96ºC
QYPFY	Round	Copper		PP	PVC	96ºC
QYPQY	Round	Copper		PP	Lead Sheath	96ºC
QYENY	Round	Copper		EPDM	NBR	120ºC
QYEQNY	Round	Copper		EPDM	Lead & NBR	120ºC
QYYEQNY	Round	Copper		Polyimide film & EPDM	Lead & NBR	120ºC
QYYENY	Round	Copper		Polyimide film & EPDM	NBR	120ºC
QYEEY	Round	Copper		EPDM	EPDM	120ºC-232ºC
QYEQEY	Round	Copper		EPDM	Lead & EPDM	120ºC-232ºC
QYYEQEY	Round	Copper		Polyimide film & EPDM	Lead & EPDM	120ºC-232ºC
QYYEEY	Round	Copper		Polyimide film & EPDM	EPDM	150ºC-232ºC

‘
