Insulated Sy Yy Cy 12 Core Flexible Cables Wire PVC Control Cable

Insulated Sy Yy Cy 12 Core Flexible Cables Wire PVC Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YCY

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Certification

IEC 60228

Brand

Huadong

Rated Voltage

0.6/1kv

Amour

Non Armour

Core

2-48 Cores or Customize

Standard

IEC 60228/ En 50363-3

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Flexible control cable with Cu cores, with PVC insulation and sheath, number coded

Application
As control and supply cables for control units in metal working machines, transportation equipment, production lines, as well as for control and measuring systems at rated voltage Uo/U 300/500 V . The cables are suitable for flexible applications for free, non-continuous returning movement, without tensile load as well as for fixed laying. They are oil and chemical resistant under normal operation conditions and are suitable for use in dry, damp or wet interiors. These cables may only be laid outdoors with UV-protection and in observance of the temperature range.

Construction

Copper conductors class 5 according to IEC 60228

Insulation: PVC compound type TI2 according to EN 50363-3

Sheath: PVC compound type TM2 according to EN 50363-4-1 Sheath colour: black RAL 9005

Cable Parameter:

Number of Conductors	Radial Thickness of		Approximate Diameters			Approximative net weight
	Insulation	Outer Sheath	Conductor	Insulation	Overall	Conductor	Cable
	mm	mm	mm	mm	mm	kg/km	kg/km
Conductor:1.5mm2
5	0.8	1.8	1.38	2. 98	13	66	212
7	0. 8	1.8	1.38	2. 98	14	92	244
8	0.8	1.8	1.38	2.98	15	105	281
10	0.8	1.8	1. 38	2. 98	17	131	332
12	0.8	1.8	1. 38	2.98	17	157	378
14	0. 8	1.8	1. 38	2.98	18	184	428
19	0. 8	1.8	1. 38	2.98	20	249	545
24	0.8	1.8	1. 38	2.98	23	314	680
30	0. 8	1.8	1.38	2.98	24	393	815
37	0.8	1.8	1.38	2. 98	26	484	975
40	0.8	1.8	1.38	2.98	27	524	1050
48	0.8	1.9	1.38	2. 98	29	628	1250
Conductor:2.5mm2
5	0.8	1.8	1. 78	3. 38	14	109	277
7	0.8	1.8	1. 78	3.38	15	153	325
8	0.8	1.8	1. 78	3.38	16	175	375
10	0.8	1.8	1. 78	3. 38	18	218	448
12	0.8	1.8	1. 78	3. 38	19	262	515
14	0.8	1.8	1. 78	3. 38	20	305	585
19	0.8	1.8	1. 78	3. 38	22	414	755
24	0.8	1.8	1. 78	3. 38	25	523	940
30	0.8	1.8	1. 78	3. 38	26	653	1140
37	0.8	1. 9	1. 78	3. 38	29	806	1390
40	0.8	1. 9	1. 78	3.38	30	871	1500
48	0.8	2. 0	1. 78	3.38	33	1045	1790
