IEEE 1580 Type P Single Two Three Four Five Conductor Offshore Marine Oil Rig Well Power Cables

IEEE 1580 Type P Single Two Three Four Five Conductor Offshore Marine Oil Rig Well Power Cables image

Get Latest Price Request a quote

Product Details

Model NO.

Type p power cable

Insulation Material

Polyolefin

Sheath Material

Thermosetting Compound

Material Shape

Round Wire

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

Type P Power Cable

Brand

Huadong

Product Name

Type P Oil Drilling Power Cable

Rated Voltage

0.6/1kv or 2kv

Size

18 16 14 10 1/0 4/0 646 777 AWG

Rated Temperature

110 Degrees C

Warranty

100% Qualified

Sample

Available

Feature

Flexible, Flame Retardant, Oil, Abrasion Resistant

Price

Get Within 12 Hours

Transport Package

Wooden Drum or Steel Wooden Drum or Coil.

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

100 Kilometer/Kilometers Per Month

Product Description

IEEE 1580 TYPE P POWER CABLE

Product Description
0.6/1kv Or 2kv Flexible Conductor Marine/Offshore Power Cable
125°C Temperature Rating
Oil, Abrasion, Moisture, Petrochemical And Sunlight Resistant
Abs, Dnv Approved Etl, Ul Listed

Application:
Designed and constructed for the demanding environments of offshore drilling and petroleum facilities located throughout the world

Cable Construction:

1. Conductor : Flexible Stranded Tinned Annealed Copper Wire
2. Insulation : Cross‐Linked Flame Retardant Polyolefin (Xlpo) Color Code: Ieee 1580 Table 22
3. Armor(optional) : Bronze Wire Braid Per Ieee 1580
4. Jacket : Thermosetting Neoprene (Type N) Black Color

0.6/1KV Three Conductor Power Cable Parameter
Size AWG/kcmil	mm2	Nominal Diameter (inches)	Weight (lbs/ MFt.)	Nominal Diameter (inches)	Weight (lbs/ MFt.)	Nominal Dia (inches)	Weight (lbs/ MFt.)	AC Resistance 110°C, (Ohms/1000 ft.)	Ampacity 110°C
16	1.3	0.369	80	0.419	138	0.572	246	6.121	17
14	2.1	0.401	103	0.451	167	0.599	228	3.859	27
12	3.3	0.445	138	0.495	209	0.648	275	2.424	33
10	5.2	0.488	185	0.538	262	0.69	334	1.53	44
8	7.6	0.64	316	0.69	397	0.82	533	0.94	56
6	12.5	0.735	449	0.785	546	0.96	734	0.59	75
4	21	0.95	754	1	862	1.185	1108	0.399	99
2	34	1.1	1079	1.15	1209	1.345	1489	0.244	131
1	43	1.23	1375	1.28	1516	1.455	1810	0.195	153
1/0	54	1.335	1667	1.385	1814	1.571	2160	0.156	176
2/0	70	1.485	2062	1.535	2278	1.685	2532	0.125	201
3/0	86	1.56	2458	1.61	2869	1.825	2909	0.1	234
4/0	109	1.764	3197	1.814	3194	2.068	4034	0.08	270
262	132	2.005	3896	2.055	4233	2.26	4824	0.067	315
313	159	2.1	4269	2.15	4481	2.373	5061	0.056	344
373	189	2.25	4903	2.3	5265	2.55	6327	0.047	387
444	227	2.378	6219	2.428	6089	2.682	7344	0.041	440
535	273	2.7	7279	2.75	7717	3.045	8299	0.035	498
646	326	2.88	8101	2.938	8873	3.295	9838	0.03	553
777	394	3.175	10077	3.225	10590	3.554	11549	0.026	602

We are China IEEE 1580 Type P Single Two Three Four Five Conductor Offshore Marine Oil Rig Well Power Cables manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
