IEC 60502-2 Na2xsh Aluminium XLPE LSZH 12/20kv Cable

IEC 60502-2 Na2xsh Aluminium XLPE LSZH 12/20kv Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NA2XSH

Current

AC Cable

Insulation Material

XLPE

Sheath Material

LSZH

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE, VDE

Model

Brand

Huadong

Product Name

Medium Voltage Power Cable

Rated Voltage

8.7/15kv,12/20kv

Armour

Non Armoured

Size

35-630mm2

Standards

IEC 60502-2

Type

Direct Burial,Underground

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

NA2XSH / NA2XSEH 12/20 (24)kV Cable

Application

Medium voltage power cables for distribution networksand generation units. LSZH outer sheathing makes the cable suitable for internal installation as well as directly inground, outdoors, and in cable ducts. UV Resistant.

Technical Data

Voltage Rating Uo/U (Um)12/20 (24)kV(or others)

Test Voltage 42kV AC 50Hz (5 mins)

Temperature Rating-20°C to +60°C

Permissible Conductor Operating Temperature: +90°C

Permissible Short Circuit Temperature up to 5 sec: 250°C

Minimum Bending Radius15 x overall diameter

Cable Construction:

Conductor Class 2 Stranded Aluminium Conductor

Screen Semi-conductive material

Insulation XLPE (Cross-Linked Polyethylene)

Insulation Screen Semi-conductive material (bonded)

Screen Copper wires and copper tape

Outer Sheath LSZH (Low Smoke Zero Halogen)

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

1.what is our payment term ?

Our payment term is usually T/T 30% advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China IEC 60502-2 Na2xsh Aluminium XLPE LSZH 12/20kv Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
