Hstn Hstcn Neoprene Round Rubber Cable for Elevator Conveyor

Hstn Hstcn Neoprene Round Rubber Cable for Elevator Conveyor image

Get Latest Price Request a quote

Product Details

Model NO.

HSTN HSTCN

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Flexible Copper

Certification

ISO, CCC, CE, VDE

Model

Ycw

Brand

Huadong

Product Name

Qwpk Flexible Rubber Cable

Rated Voltage

450/750V

Cross Section Size

1mm2 1.5mm2,2.5mm2

Cores

Customized

Temperature

-20°c to +70°c

Warranty

100% Qualified

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

HSTN HSTCN Neoprene round cables with carrier element (unscreened and screened)

APPLICATION

HSTN/HSTCN can be used as elevator control cable, control cable on conveyor systems, machine tools or measuring as well as signal cable. The cable is suitable for use in dry, damp and wet areas and even for outdoor applications, especially used where resistance to oils and chemical influences are involved. Elevator control cable suitable for suspension heights up to 80 m in consideration of the tensile load. The cable is suitable for use in potentially ex-areas.

CONSTRUCTION

Conductor: plain copper, finest stranded, class 6 according to EN 60228 VDE 0295 class 6

Insulation: EPR

Core arrangement: cores twisted in layers around textile carrier element

Core identification: up to 5 cores: colored according to HD 308 (DIN VDE 0293-308); from 6 cores: according to

EN 50334

Screening (…C.): mixed braid of tinned copper wires and textile threads, covering approx. 80%

Sheath: extruded neoprene mixed, mixed compound

EM2 acoording to DIN VDE 0207 part 21

Sheath colour: black

CHARACTERISTICS

Maximum temperature for flexible installation:

-30°C up to +70°C

Maximum temperature for fixed operation:

-40°C up to +70°C

in case of 20°C

Nominal voltage: 450/750V

Test voltage: core/core 3.000V core/screen 1.500V

Conductor resistance: according to VDE 0295 class 6

Insulation resistance: > 20 MOhm x km

Bending radius: flexible application: 10 x cable diameter

Free suspended height: up to 80 meters

Oil resistance: according to EN 60811-2-1

Characteristic of combustion: according to DIN EN

60332-1-1 and DIN EN 60332-1-2

Flame resistance: according to DIN EN 60332-1-2

Applied standards: similar to VDE 0250

Cross-section mm2	CU-number kg/km	Outer Dia approx. mm	Weight approx. kg/km	Tensile strength N
3 G 1	31.0	9.0	120	250
7 G 1	72,0	13,5	255	2.500
12 G 1	124.0	19.5	500	2.500
18 G 1	194.0	20.0	570	1.550
24 G 1	261.0	22,5	745	2.500
36 G 1	400,0	27.0	1.060	2.500
54 G 1	654,0	33,0	1.580	2.500
3 G 1,5	46.0	9.5	145	250
4 G 1,5	62.0	11.5	195	350
5 G 1,5	78.0	12.0	220	1.000
7 G 1,5	109,0	13.5	295	2.500
9 G 1,5	140.0	16,5	410	2.500
12 G 1,5	182,0	21.0	575	2.500
18 G 1,5	288,0	22,0	700	2.500
24 G 1,5	374.0	25.0	940	2.000
42 G 1,5	677,0	32,0	1.600	2.500
4 G 2,5	103.0	12,5	265	350
5 G 2,5	135,0	14.5	330	1.200
7 G 2,5	189,0	17.5	460	2.500
12 G 2,5	341.0	21.5	770	2.500
37 G 2,5	1.030,0	36,5	2.250	2.500
4 G 6	244,0	18,0	525	1.000

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.what is our payment term?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time?
The lead time usually is 10 – 30 working days.

3.what is the package of the cable?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.

4.Could we provide the free sample for customer?
Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China Hstn Hstcn Neoprene Round Rubber Cable for Elevator Conveyor manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
