Product Details
Model NO.
NMD90
Application
Indoor Wire
Conductor Material
Copper
Sheath Material
PVC
Insulation Material
PVC+Nylon
Material Shape
Round Wire
Range of Application
Building Wire
Certification
cUL Certificate
Brand
Ren Da
Production Name
Nmd90 Cable
Certificate
CSA
Voltage
300V
Size
14/2 14/3 12/2 12/3 10/2 10/3 8/2 8/3
Core
2+1, 3+1
Cable Type
Round and Flat
Insulated Material
PVC+Nylon
Sheathed Material
PVC
Market
Canada
Package
75m/Reel or 150m/Reel
Standard
CSA C22.2 No. 48
Name
Non-Metallic Sheathed Cable
Transport Package
Standard Export Drum
Specification
14awg 12awg 10awg 8awg 6awg
Trademark
RNE DA
Origin
Tangshan, Hebei Province
HS Code
8544492100
Production Capacity
300km/Month
Product Description
300V 14/2 12/2 14/3 12/2 NMD90 wire cable with CSA certificate
Application:
NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or
damp locations.The maximum allowable conductor temperature is 90°C. The minimum
recommended installation temperature is -25°C or -40°C for two-conductor cables and -25°C for
three-conductor cables (with suitable handling procedures). Material should be properly stored
above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended
applications is 300 volts. Consult the Canadian Electrical Code1 for further information related to
applications.
Structure:
1. Conductor: Copper conductor with Copper grounding wire 14AWG to 2AWG
or aluminium alloy 8000series
ACM with AL groundig wire Grey 6AWG to 2AWG.
2. Insulation: Polyvinyl chloride (PVC)
3. Protective covering: nylon
4. Jacket: PVC, Heat and moisture-resistant, flame retardant FT1.
5. Number of conductor: 2 parell laid or 3 and 4 round laid
Standard:
CSA C22.2 No. 48 (non-metallic sheathed cable)
UL File No.: E487898
Voltage: 300V
Working temperature:
in dry locations only at temperature not to exceed 90°C
specification.
| Size (AWG) | Number of Strands |
Ground Wire Size |
Insulation Thickness (in) |
Allowable Ampacity (Amps)* |
Outside Diameter (in) |
Approximate Net Weight (lbs/1000 ft) |
|
| PVC | Nylon | ||||||
| 14/2 G | Solid | 14 | 0.015 | 0.004 | 15 | 0.170 x 0.390 | 56 |
| 12/2 G | Solid | 12 | 0.015 | 0.004 | 20 | 0.160 x 0.450 | 82 |
| 10/2 G | Solid | 10 | 0.020 | 0.004 | 30 | 0.210 x 0.493 | 123 |
| 8/2 G | 7 | 10 | 0.030 | 0.005 | 40 | 0.290 x 0.580 | 185 |
| 6/2 G | 7 | 10 | 0.030 | 0.005 | 55 | 0.330 x 0.695 | 256 |
| 14/3 G | Solid | 14 | 0.015 | 0.004 | 15 | 0.170 x 0.450 | 74 |
| 12/3 G | Solid | 12 | 0.015 | 0.004 | 20 | 0.345 | 107 |
| 10/3 G | Solid | 10 | 0.020 | 0.004 | 30 | 0.430 | 165 |
| 8/3 G | 7 | 10 | 0.030 | 0.005 | 40 | 0.555 | 251 |
| 6/3 G | 7 | 10 | 0.030 | 0.005 | 55 | 0.612 | 352 |
| 4/3 G | 7 | 8 | 0.040 | 0.006 | 70 | 0.820 | 565 |
| 2/3 G | 7 | 8 | 0.040 | 0.006 | 95 | 0.945 | 841 |
| **14/4 G & 14/2-2 G | Solid | 14 | 0.015 | 0.004 | 12 | 0.345 | 90 |
| **12/4 G & 12/2-2 G | Solid | 12 | 0.015 | 0.004 | 16 | 0.385 | 132 |
| **10/4 G | Solid | 10 | 0.020 | 0.004 | 30 | 0.540 | 205 |
