High Temperature Resistant Silicone Rubber Cable 0.6/1kv Flame Retardant Power Cable with Silicone Insulation Electric Wires

High Temperature Resistant Silicone Rubber Cable 0.6/1kv Flame Retardant Power Cable with Silicone Insulation Electric Wires image

Get Latest Price Request a quote

Product Details

Model NO.

YGC, GG, GG2G, GG3G

Application

Power Systems, Power Transmission

Conductor Material

Tinned Copper

Sheath Material

Silicone Rubber

Insulation Material

Silicone Rubber

Material Shape

Round Wire

Range of Application

Power Systems, Power Transmission

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Tianhuan

Temperature

-60ºC~+180ºC

Keywords

Silicone Rubber Temperature Resistant Cable

Certificate

ISO9001/CCC

Cores

2,3,4,5,3+2,3+1,4+1

Transport Package

as Customer′s Request

Specification

1.5~500 for single core, 1.5~240 for mult-core

Trademark

Tianhuan

Origin

Hebei, China

HS Code

8544492100

Packaging & Delivery

Package Size

30.00cm * 30.00cm * 15.00cm

Package Gross Weight

25.000kg

Product Description

Model number :GG (YGC)
Brand name:Tianhuan
Conductor Material: tinned copper
Insulation: Silicone rubber
Rated voltage: 450/750v 0.6/1kv
Color:Black,Red
Core:1,2,3,4,5,6,etc.
Wire size:1.5mm²–500mm²(for single core)
1.5mm²-240mm²(for multi-core)
Rated temperature:-60ºC~+180ºC

(Flame retardant) Power cable with silicon insulation

It is used as power transmission cable of electric equipment
of rated voltage 0.6/1 kV or lower in bad environment or that with high temperature.
It has good features of high temperature resistance,flame resistance,radiation resistance,
aging resistance,ozone resistance,water proof, freezing resistance, weather resistance etc.

Operational performance

1.Rated voltage 0.6/1kv

2.Working temperature allowed by cable is -60ºC~+180ºC.

3.Max temperature of cable conductor is no more than 350ºC during short circuit

(the longest lasting time is no more than 5 s )

4.Temperature for installing is no less than -20ºC.

5.Bending radius of cable with armouring or shielding structure is no less than 12 times of cable outer diameter, for cable

without armouring or shielding structure, bending radius is no less than 6 times of cable outer diameter.

Type and Description

Type	Description
GG(YGC)	Power cable with silicon rubber insulation and sheath
GG2G	Power cable with silicon rubber insulation and sheath, steel tape armor
GG3G	Power cable with silicon rubber insulation and sheath, fine wire armor
Note: 1.The flame retardant type should be added’ZA,ZB,ZC,ZD” before the type in the table 2.Single core cablesshall be made of non-magnetic materials

Technical parameter

1.DC resistance of finished cable conductor at 20ºC shall meet the requirement of GB/T3956 standard.

2.Finished cable shall bear A.C voltage test of 3500 V under power frequency for s minutes without puncture of insulation.

Specication

Type	Core number	Nominal cross section area(mm2)	Type of conductor
GG(YGC)	2, 3, 4, 5, 3+2, 3+1, 4+1	1.5~500 for single core 1.5~240 for multi-core	category 5 conductor
GG2G,GG3G

Silicone Rubber Cable

HOT SALE

Our company, Tianhuan Cable Group Co., Ltd., has successfully approved LVD legislation
and CPR legislation of CE certifications,as well as holding product certificates from

TUV,SAA and CCC. Furthermore, we have also passed a series of management system certifications by ISO.

A)Are you trading company or manufacturer?

we are manufacturer. if you did not find your needed in this page. Just contact us and welcome to visit us.

B)How about the delivery time?

Usualy it is 5-10 days if the goods are in stock, or it is 15-20 days if the goods are not in stock,it depends on your quantity.

C)What’s the package of products?

The package is usually wooden drums ,steel-wooden drums or according to requirement .

D)What is your MOQ for the cable and wire ?

Please contact us for more details, MOQ depends on the sort of cable.

E)Can I get a discount?

It depends on your quantity, we can make a discount and afford the freight. so contact us.

We are China High Temperature Resistant Silicone Rubber Cable 0.6/1kv Flame Retardant Power Cable with Silicone Insulation Electric Wires manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
