High Quality Construction Industrial Low Voltage Electrical XLPE Aluminum Conductor Cable

High Quality Construction Industrial Low Voltage Electrical XLPE Aluminum Conductor Cable image

Get Latest Price Request a quote

Product Details

Model NO.

customized

Current

DC & AC

Insulation Material

PVC or XLPE

Sheath Material

PVC

Material Shape

Round Wire or Flat Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, RoHS, VDE

Model

Yjlv/Vlv

Brand

Guowang

Rated Temperature

70ºC

Length

Customized

Transport Package

by Wooden Drum or Others

Specification

1.5-300MM2

Trademark

Guowang

Origin

China

HS Code

8544601290

Production Capacity

500km/Mouth

Packaging & Delivery

Package Size

1000.00cm * 600.00cm * 1000.00cm

Package Gross Weight

1500.000kg

Product Description

0.6/1kv Aluminum Donductor XLPE/PVC Insulation PVC Sheath Power Cable

1. Standard

IEC 60502, 60228, 60332, 60331

DIN VDE 0276-620

HD 620 S1: 1996

2. Application

This cable is used for fixed installations, such as distrubution networks or industrial installations. It can be installed in

cable duct, trench or directly buried in earth.

3. Product Description

1) Rated Voltage: 0.6/1KV 3.6/6KV 6.5/11KV, 11KV, 33KV, 66KV, 132KV

2) Maxworking temperature: 75 °c OR 90°c

3) Maxtemperature during short circuit (≤5S): 250 °c

4) Conductor: class 1, 2 copper or aluminum

5) Sectional area: 1.5 – 800mm2

6) Insulation:PVC/XLPE

7) No. of cores: 1, 2, 3, 4, 5

8) Armor: steel wire or steel tape for 3 core cables and non-magnetic material for single core

9) Oversheath: PVC

10) Minbeding radius: 15 times cable radius for single-core cables and 12 times for multi-core ones

Rated voltage	No,of CORES	core ×cross secticn (MM)	CONDUCTOR	CORE DIANETER (MM2)	INSULATION THCKNESS (MM)	BELT (MM)	JACKET THICKNESS (MM)	Reference outer diameter (MM)	Reference weight (kg/km)	DC RESISTANCE (Ω/KM)
0.6/1KV	1	1×10	7/1.35	4.1	0.7	20×0.20	1.4	8.9	89.7	3.08
	1	1×16	7/1.66	5.0	0.7	20×0.20	1.4	9.9	112.9	1.91
	1	1×25	7/2.14	6.4	0.9	20×0.20	1.4	11.6	159.9	1.2
	1	1×35	7/2.52	7.6	0.9	25×0.20	1.4	12.8	198.2	0.868
	1	1×50	10/2.52	8.4	1.0	25×0.20	1.4	13.8	245	0.641
	1	1×70	14/2.52	10.0	1.1	30×0.20	1.4	15.6	318.2	0.443
	1	1×95	19/2.52	11.6	1.1	35×0.20	1.5	17.4	411.6	0.32
	1	1×120	24/2.52	13.0	1.2	40×0.20	1.5	19	498.9	0.253
	1	1×150	30/2.52	14.6	1.4	45×0.20	1.6	21.2	617.2	0.206
	1	1×185	37/2.52	16.2	1.6	50×0.20	1.6	23.2	743.4	0.164
	1	1×240	48/2.52	18.5	1.7	55×0.20	1.7	25.9	937.6	0.125
	1	1×300	61/2.52	20.6	1.8	60×0.20	1.8	28.4	1159.2	0.1
	1	1×400	61/2.94	23.3	2.0	60×0.20	1.9	32.2	1480.7	0.0778
	1	1×500	60/3.29	26.6	2.2	60×0.20	2.0	35.6	1864.6	0.0605
	1	1×630	60/3.69	29.6	2.4	60×0.20	2.2	39.4	2322	0.0469
	2	2×10	7/1.35	4.1	0.7	30×0.20	1.8	15.2	225.3	3.08
	2	2×16	7/1.66	5.0	0.7	35×0.20	1.8	17.2	287.9	1.91
	2	2×25	7/2.14	6.4	0.9	40×0.20	1.8	20.6	414.2	1.2
	2	2×35	7/2.52	7.6	0.9	50×0.20	1.8	23	517.4	0.868
	2	2×50	10/2.52	5.7×13.5	1.0	40×0.20	1.8	19.6	483.4	0.641
	2	2×70	14/2.52	7.0×15.6	1.1	45×0.20	1.8	22.6	633.4	0.443
	2	2×95	19/2.52	8.3×18.0	1.1	55×0.20	1.9	25.4	818.8	0.32
	2	2×120	24/2.52	8.9×20.8	1.2	60×0.20	2.0	27.2	1000.4	0.253
	2	2×150	30/2.52	10.0×23.1	1.4	60×0.20	2.2	30.6	1248.9	0.206
	2	2×185	37/2.52	11.1×25.7	1.6	60×0.20	2.3	33.8	1523.3	0.164
	2	2×240	48/2.52	12.5×29.1	1.7	60×0.20	2.5	37.4	1924.2	0.125
	2	2×300	61/2.52	15.0×32.2	1.8	60×0.20	2.6	43	2395.1	0.1
	3	3×10	7/1.35	4.1	0.7	30×0.20	1.8	16.1	266.1	3.08
	3	3×16	7/1.66	5.0	0.7	35×0.20	1.8	18.2	343	1.91
	3	3×25	7/2.14	6.4	0.9	45×0.20	1.8	21.9	503.3	1.2
	3	3×35	7/2.52	7.6	0.9	50×0.20	1.8	24.5	634.9	0.868
	3	3×50	10/2.52	7.0×11.5	1.0	50×0.20	1.8	23.2	678.2	0.641
	3	3×70	14/2.52	8.0×13.7	1.1	55×0.20	1.9	25.9	897.5	0.443
	3	3×95	19/2.52	9.5×15.8	1.1	60×0.20	2.0	29.3	1166.6	0.32
	3	3×120	24/2.52	10.8×18.6	1.2	60×0.20	2.1	32.7	1444.3	0.253
	3	3×150	30/2.52	12.5×20.5	1.4	60×0.20	2.3	37.5	1810.3	0.206
	3	3×185	37/2.52	14.3×23.3	1.6	60×0.20	2.4	42.3	2221.3	0.164
	3	3×240	48/2.52	16.3×26.2	1.7	60×0.20	2.6	47.4	2815.6	0.125
	3	3×300	61/2.52	18.0×29.8	1.8	60×0.20	2.7	51.6	3467.5	0.1
	4	4×10	7/1.35	4.1	0.7	35×0.20	1.8	17.5	318.9	3.08
	4	4×16	7/1.66	5.0	0.7	40×0.20	1.8	19.9	416.4	1.91
	4	4×25	7/2.14	6.4	0.9	50×0.20	1.8	24	617.1	1.2
	4	4×35	7/2.52	7.6	0.9	60×0.20	1.8	26.9	783.2	0.868
	4	4×50	10/2.52	7.5×10.5	1.0	55×0.20	1.8	25.1	857.7	0.641
	4	4×70	14/2.52	9.1×12.5	1.1	60×0.20	2.0	29.5	1167.5	0.443
	4	4×95	19/2.52	11.0×13.3	1.1	60×0.20	2.1	33.8	1524.2	0.32
	4	4×120	24/2.52	12.0×17.0	1.2	60×0.20	2.3	36.9	1894.4	0.253
	4	4×150	30/2.52	13.9×19.7	1.4	60×0.20	2.4	42.1	2351	0.206
	4	4×185	37/2.52	15.2×21.2	1.6	60×0.20	2.6	46.3	2891.3	0.164
	4	4×240	48/2.52	17.3×24.3	1.7	60×0.20	2.8	51.7	3662.7	0.125
	4	4×300	61/2.52	19.5×27.9	1.8	60×0.20	3.0	57.4	4558	0.1
	5	5×10	7/1.35	4.1	0.7	40×0.20	1.8	19.1	378.5	3.08
	5	5×16	7/1.66	5.0	0.7	45×0.20	1.8	21.8	498.1	1.91
	5	5×25	7/2.14	6.4	0.9	55×0.20	1.8	26.3	741.7	1.2
	5	5×35	7/2.52	7.6	0.9	60×0.20	1.8	29.6	947.8	0.868
	5	5×50	10/2.52	4.8×14.2	1.0	60×0.20	1.9	27.4	1049.1	0.641
	5	5×50	10/2.52	8.4	1.0	60×0.20	1.9	27.4	1049.1	0.641
	5	5×70	14/2.52	5.7×16.8	1.1	60×0.20	2.1	31.7	1422.9	0.443
	5	5×70	14/2.52	10.0	1.1	60×0.20	2.1	31.7	1422.9	0.443
	5	5×95	19/2.52	6.7×19.6	1.1	60×0.20	2.2	35.5	1851.5	0.32
	5	5×95	19/2.52	11.6	1.1	60×0.20	2.2	35.5	1851.5	0.32
	5	5×120	24/2.52	7.9×21.9	1.2	60×0.20	2.4	40.2	2319.2	0.253
	5	5×120	24/2.52	13.0	1.2	60×0.20	2.4	40.2	2319.2	0.253
	5	5×150	30/2.52	8.5×24.6	1.4	60×0.20	2.6	44.4	2880.2	0.206
14.6	5	5×150	30/2.52	1.4		60×0.20	2.6	44.4	2880.2	0.206
5	5×185	37/2.52	9.4×27.2	1.6	60×0.20	2.8	49.2	3545.6	0.164
5	5×185	37/2.52	16.2	1.6	60×0.20	2.8	49.2	3545.6	0.164
5	5×240	48/2.52	10.8×31.0	1.7	60×0.20	3.0	55.2	4496.4	0.125
5	5×240	48/2.52	18.5	1.7	60×0.20	3.0	55.2	4496.4	0.125
5	5×300	61/2.52	12.2×34.4	1.8	60×0.20	3.2	61	5591.6	0.1
5	5×300	61/2.52	20.6	1.8	60×0.20	3.2	61	5591.6	0.1
4	3×16+1×10	7/1.66	5.0	0.7	40×0.20	1.8	19.3	392	1.91
4	3×16+1×10	7/1.35	4.1	0.7	40×0.20	1.8	19.3	392	1.91
5	3×16+2×10	7/1.66	5.0	0.7	40×0.20	1.8	20.7	449.4	1.91
		7/1.35	4.1	0.7
		7/1.35	4.1	0.7
4	3×25+1×16	7/2.14	6.4	0.9	50×0.20	1.8	23	566.9	1.2
4	3×25+1×16	7/1.66	5.0	0.7	50×0.20	1.8	23	566.9	1.2
5	3×25+2×16	7/2.14	6.4	0.9	50×0.20	1.8	24.5	642.6	1.2
		7/1.66	5.0	0.7
		7/1.66	5.0	0.7
4	3×35+1×16	7/2.52	7.6	0.9	55×0.20	1.8	25.2	689.5	0.868
4	3×35+1×16	7/1.66	5.0	0.7	55×0.20	1.8	25.2	689.5	0.868
5	3×35+2×16	7/2.52	7.6	0.9	55×0.20	1.8	26.4	759.1	0.868
		7/1.66	5.0	0.7
		7/1.66	5.0	0.7
4	3×50+1×25	10/2.52	7.2×10.8	1.0	55×0.20	1.8	25.5	785.2	0.641
4	3×50+1×25	7/2.16	6.0	0.9	55×0.20	1.8	25.5	785.2	0.641
5	3×50+2×25	10/2.52	5.0×14.3	1.0	55×0.20	1.8	25.1	868	0.641
		7/2.16	6.0	0.9
		7/2.16	6.0	0.9
4	3×70+1×35	14/2.52	9.0×13.0	1.1	60×0.20	1.9	30.3	1052.4	0.443
4	3×70+1×35	7/2.52	7.0	0.9	60×0.20	1.9	30.3	1052.4	0.443
5	3×70+2×35	14/2.52	6.0×16.8	1.1	60×0.20	2.0	28.9	1164.4	0.443
		7/2.52	7.0	0.9
		7/2.52	7.0	0.9
4	3×95+1×50	19/2.52	10.7×14.5	1.1	60×0.20	2.1	34.6	1393.1	0.32
4	3×95+1×50	10/2.52	8.4	1.0	60×0.20	2.1	34.6	1393.1	0.32
5	3×95+2×50	19/2.52	7.2×19.7	1.1	60×0.20	2.1	33	1536.2	0.32
		10/2.52	8.4	1.0
		10/2.52	7.1×11.5	1.0
4	3×120+1×70	24/2.52	11.5×17.3	1.2	60×0.20	2.2	37.1	1726	0.253
4	3×120+1×70	14/2.52	10.0	1.1	60×0.20	2.2	37.1	1726	0.253
5	3×120+2×70	24/2.52	8.0×22.1	1.2	60×0.20	2.3	37.1	1962	0.253
		14/2.52	10.0	1.1
		14/2.52	7.8×13.1	1.1
4	3×150+1×70	30/2.52	13.2×19.4	1.4	60×0.20	2.3	42.2	2084.2	0.206
4	3×150+1×70	14/2.52	10.0	1.1	60×0.20	2.3	42.2	2084.2	0.206
5	3×150+2×70	30/2.52	9.1×24.3	1.4	60×0.20	2.4	40.3	2300.1	0.206
		14/2.52	10.0	1.1
		14/2.52	7.8×13.1	1.1
4	3×185+1×95	37/2.52	15.0×22.3	1.6	60×0.20	2.5	47.6	2598.8	0.164
4	3×185+1×95	19/2.52	11.6	1.1	60×0.20	2.5	47.6	2598.8	0.164
5	3×185+2×95	37/2.52	10.2×27.2	1.6	60×0.20	2.5	45.1	2863.3	0.164
		19/2.52	11.6	1.1
		19/2.52	9.2×14.7	1.1
4	3×240+1×120	48/2.52	17.7×23.7	1.7	60×0.20	2.6	54.5	3276.8	0.125
4	3×240+1×120	24/2.52	13.0	1.2	60×0.20	2.6	54.5	3276.8	0.125
5	3×240+2×120	48/2.52	11.5×29.2	1.7	60×0.20	2.7	50	3611.4	0.125
		24/2.52	13.0	1.2
		24/2.52	9.9×16.4	1.2
4	3×300+1×150	61/2.52	19.2×28.3	1.8	60×0.20	2.8	58.9	4054	0.1
4	3×300+1×150	30/2.52	14.6	1.4	60×0.20	2.8	58.9	4054	0.1
5	3×300+2×150	61/2.52	13.0×33.2	1.8	60×0.20	2.9	55.6	4497.4	0.1
		30/2.52	14.6	1.4
		30/2.52	10.6×17.9	1.4
5	4×16+1×10	7/1.66	5.0	0.7	45×0.20	1.8	21.2	472.7	1.91
5	4×16+1×10	7/1.35	4.1	0.7	45×0.20	1.8	21.2	472.7	1.91
5	4×25+1×16	7/2.14	6.4	0.9	55×0.20	1.8	25.4	692.5	1.2
5	4×25+1×16	7/1.66	5.0	0.7	55×0.20	1.8	25.4	692.5	1.2
5	4×35+1×16	7/2.52	7.6	0.9	60×0.20	1.8	28	853.1	0.868
5	4×35+1×16	7/1.66	5.0	0.7	60×0.20	1.8	28	853.1	0.868
5	4×50+1×25	10/2.52	5.5×13.4	1.0	55×0.20	1.9	26.3	965.4	0.641
5	4×50+1×25	7/2.16	6.0	0.9	55×0.20	1.9	26.3	965.4	0.641
5	4×70+1×35	14/2.52	6.7×15.8	1.1	60×0.20	2.0	30.3	1288.9	0.443
5	4×70+1×35	7/2.52	7.0	0.9	60×0.20	2.0	30.3	1288.9	0.443
5	4×95+1×50	19/2.52	7.7×18.3	1.1	60×0.20	2.2	34.2	1702.1	0.32
5	4×95+1×50	10/2.52	8.4	1.0	60×0.20	2.2	34.2	1702.1	0.32
5	4×120+1×70	24/2.52	9.5×20.8	1.2	60×0.20	2.3	40.1	2151.3	0.253
5	4×120+1×70	14/2.52	10.0	1.1	60×0.20	2.3	40.1	2151.3	0.253
5	4×150+1×70	30/2.52	10.0×22.9	1.4	60×0.20	2.5	42.3	2591.6	0.206
5	4×150+1×70	14/2.52	10.0	1.1	60×0.20	2.5	42.3	2591.6	0.206
5	4×185+1×95	37/2.52	10.8×25.6	1.6	60×0.20	2.6	46.7	3191.5	0.164
5	4×185+1×95	19/2.52	11.6	1.1	60×0.20	2.6	46.7	3191.5	0.164
5	4×240+1×120	48/2.52	12.6×28.9	1.7	60×0.20	2.9	52.6	4067.9	0.125
5	4×240+1×120	24/2.52	13.0	1.2	60×0.20	2.9	52.6	4067.9	0.125
5	4×300+1×150	61/2.52	13.8×32.2	1.8	60×0.20	3.1	57.6	5050.2	0.1
5	4×300+1×150	30/2.52	14.6	1.4	60×0.20	3.1	57.6	5050.2	0.1

We are China High Quality Construction Industrial Low Voltage Electrical XLPE Aluminum Conductor Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
