High Quality 18 16 AWG Multi Triad Instrument Power Cable
High Quality 18 16 AWG Multi Triad Instrument Power Cable image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
Triads instrumentation Cable
Insulation Material
Polyolefin
Sheath Material
Thermosetting Compound
Material Shape
Round Wire
Wire Core Material
Copper
Certification
ISO, CCC, CE, VDE
Model
Triads Instrumentation Cable
Brand
Huadong
Product Name
Shielded Triad Instrumentation Cable
Rated Voltage
0.6/1kv
Size
18 16 AWG
Rated Temperature
110 Degrees C
Warranty
100% Qualified
Sample
Available
Feature
Flexible, Flame Retardant, Oil, Abrasion Resistant
Price
Get Within 12 Hours
Transport Package
Wooden Drum or Steel Wooden Drum or Coil.
Specification
by meters
Trademark
huadong
Origin
China
HS Code
8544492100
Production Capacity
100 Kilometer/Kilometers Per Month
Product Description
high quality 18 16 AWG multi triad instrument power cable
Conductor : Tinned Copper (Class 5)
Insulation : Flame Retardant Polyolefin
Inner Sheath : Chemical And Sunlight Resistant Thermosetting Compound
Armor(Optional) : Tinned Copper Basket Weave Wire
Sheath(Optional) : Chemical And Sunlight Resistant Thermosetting Compound
Inner Sheath : Chemical And Sunlight Resistant Thermosetting Compound
Armor(Optional) : Tinned Copper Basket Weave Wire
Sheath(Optional) : Chemical And Sunlight Resistant Thermosetting Compound
Application : Designed and Constructed for the Demanding Environments of Offshore Drilling and Petroleum Facilities Located Throughout the World
Features : Super Flexible,Higher Insulation Resistance,Excellent Moisture Resistance,Flame Retardant
Features : Super Flexible,Higher Insulation Resistance,Excellent Moisture Resistance,Flame Retardant
|
Shielded Triads Instrumentation Cable
|
|||||||
|
Size AWG
|
Number of Pairs
|
Nominal Diameter (inches)
|
Weight (lbs/MFt.)
|
Nominal Diameter (inches)
|
Wei
ght (lbs/MFt.) |
Nominal Diameter (inches)
|
Weight (lbs/MFt.)
|
|
18
|
1
|
0.354
|
69
|
0.404
|
160
|
0.557
|
167
|
|
18
|
2
|
0.649
|
204
|
0.702
|
303
|
0.876
|
430
|
|
18
|
3
|
0.703
|
236
|
0.753
|
345
|
0.927
|
477
|
|
18
|
4
|
0.775
|
316
|
0.825
|
398
|
0.975
|
594
|
|
18
|
5
|
0.889
|
353
|
0.939
|
497
|
1.113
|
658
|
|
18
|
7
|
0.957
|
461
|
1.007
|
614
|
1.202
|
785
|
|
18
|
8
|
1.025
|
589
|
1.075
|
735
|
1.14
|
900
|
|
18
|
12
|
1.221
|
792
|
1.271
|
990
|
1.642
|
1195
|
|
16
|
1
|
0.376
|
81
|
0.426
|
206
|
0.579
|
265
|
|
16
|
3
|
0.76
|
366
|
0.81
|
411
|
1.018
|
571
|
|
16
|
4
|
0.82
|
410
|
0.87
|
457
|
1.001
|
646
|
|
16
|
6
|
0.95
|
628
|
1
|
791
|
1.198
|
1024
|
|
16
|
7
|
1.029
|
524
|
1.079
|
688
|
1.248
|
1026
|
|
16
|
8
|
1.108
|
684
|
1.158
|
793
|
1.312
|
1101
|
We are China High Quality 18 16 AWG Multi Triad Instrument Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
