RW90/RWU90
AL/CU SINGLE CORE BUILDING WIRE 600V
Application:
For open wiring and raceways (except cable troughs and ventilated flexible cable way) in dry or
wet locations.For exposed wiring where exposed to weather with sunlight-resistant insulation.
Approved for use with ceiling fixtures.
Structure:
- Conductor: Annealed bare copper wires or compact aluminum 8000 series wires, class B.
- Insulation: Cross-Linked Polyethylene (XLPE)
Colour Coding: Black; other colors available upon request.
Standard: CSA Standard C22.2 No.38
Working temperature: -40ºC Min, 90ºC Max
Voltage: 600V ,1000V or 2000V
c(UL) file No: E466693 CSA File No.: 271587
Printing :
CU conductor: HT CABLES CSA 271587 TYPE RW90 XLPE ***AWG -40C SR 600V ****M
AL conductor: HT CABLES CSA 271587 TYPE RW90 AL XLPE ***AWG–40C SR 600V ****M
Technical data:
RW90 600V
| Conductor | Insulation thickness | Approx. OD (mm) | ||
| AWG/KCMIL | Nos of strands(CU) | Nos of strands(AL) | (mm) | CU |
| 14 | 1 or 7 | 1 | 0.76 | 3.4 |
| 12 | 1 or 7 | 1 | 0.76 | 3.9 |
| 10 | 1 or 7 | 1 | 0.76 | 4.5 |
| 8 | 19 | 19 | 1.14 | 6.0 |
| 6 | 19 | 19 | 1.14 | 7.0 |
| 4 | 19 | 19 | 1.14 | 8.2 |
| 2 | 19 | 19 | 1.14 | 9.8 |
| 1 | 19 | 19 | 1.4 | 10.9 |
| 1/0 | 19 | 19 | 1.4 | 11.9 |
| 2/0 | 19 | 18 | 1.4 | 12.9 |
| 3/0 | 19 | 19 | 1.4 | 14.2 |
| 4/0 | 19 | 19 | 1.4 | 15.6 |
| 250 | 37 | 37 | 1.65 | 17.2 |
| 350 | 37 | 37 | 1.65 | 19.8 |
| 400 | 37 | 37 | 1.65 | 20.9 |
| 500 | 37 | 37 | 1.65 | 23.1 |
| 750 | 61 | 61 | 2.03 | 28.3 |
| 1000 | 61 | 61 | 2.03 | 32.1 |
All dimensions are nominal and subject to normal manufacturing tolerances
RW90 1000V
| Conductor | Insulation thickness | Approx. OD | ||
| AWG/KCMIL | Nos of strands(CU) | Nos of strands(AL) | (mm) | (mm) |
| 14 | 1 or 7 | / | 1.14 | 4.1 |
| 12 | 1 or 7 | / | 1.14 | 4.6 |
| 10 | 1 or 7 | / | 1.14 | 5.2 |
| 8 | 19 | 19 | 1.14 | 6.0 |
| 6 | 19 | 19 | 1.52 | 7.8 |
| 4 | 19 | 19 | 1.52 | 9.0 |
| 2 | 19 | 19 | 1.52 | 10.5 |
| 1/0 | 19 | 19 | 2.03 | 13.2 |
| 2/0 | 19 | 19 | 2.03 | 14.2 |
| 3/0 | 19 | 19 | 2.03 | 15.5 |
| 4/0 | 19 | 19 | 2.03 | 16.9 |
| 250 | 37 | 37 | 2.28 | 18.5 |
| 350 | 37 | 37 | 2.28 | 21.1 |
| 400 | 37 | 37 | 2.28 | 22.2 |
| 500 | 37 | 37 | 2.28 | 24.4 |
| 750 | 61 | 61 | 2.28 | 28.8 |
| 1000 | 61 | 61 | 2.28 | 32.6 |
All dimensions are nominal and subject to normal manufacturing tolerances
