HD 620-10j / Nen 3620 8.7/15kv 12/20kv 18/30kv Ymz1krvasdlwd-Al LSZH Medium Voltage Water Blocking Aluminium Power Cable

HD 620-10j / Nen 3620 8.7/15kv 12/20kv 18/30kv Ymz1krvasdlwd-Al LSZH Medium Voltage Water Blocking Aluminium Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YMz1Krvasdlwd-AL

Current

AC Cable

Insulation Material

XLPE

Sheath Material

LSZH

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE, VDE

Product Name

Ymz1krvasdlwd-Al Cable

Rated Voltage

12/20kv,8.7/15kv,18/30kv

Armour

Non Armoured

Size

35-630mm2

Cores

1 Core 3 Core

Type

Longitudinal and Radial Water Blocking

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

8.7/15kV 12/20kV 18/30kV YMz1Krvasdlwd-al LSZH Medium Voltage Water Blocking Cable

Application

LSZH Medium Voltage cable with aluminium conductors offering a lightweight alternative to copper conductor alternatives. Suitable for use in conduit and for fixed, protected installation. For installations where fire, smoke emission and toxic fume create a potential risk to life and equipment.

Technical Data

Voltage Rating Uo/U 8.7/15kV,12/20kV,18/30kV
Temperature Rating Fixed: 0°C to +90°C
Maximum Conductor Short-Circuit Temp up to 5 sec: 250°C
Minimum Bending Radius15 x overall diameter

Cable Construction

Conductor Class 2 Stranded Aluminium
Inner Semi-Conductive LayerSemi-Conductive Material
InsulationXLPE (Cross-Linked Polyethylene)
Outer Semi-Conductive Layer
Semi-Conductive Material
Screen Copper wires and tapeTape
Longitudinal and Radial Water Blocking
Outer Sheath LSZH (Low Smoke Zero Halogen) UV Resistant

Standard
Generally to HD 620-10J / NEN 3620 Fire Resistant to IEC/EN 60332-1-2, IEC/EN 60332-3-24 Cat.C

Cable Parameter for Reference

Mantelkleur	Gewicht (kg/km)	Outer diameter approx. (mm)
1 x 150 Alrm + as70 Red	1732	35,5
1 x 150 Alrm + as25 Red	1329	35,5
1 x 240 Alrm + as25 Red	1688	39,2
1 x 240 Alrm + as70 Red	2097	39,2
1 x 240 Alrm + as50 Red	1908	39,2
1 x 240 Alrm + as35 Red	1766	39,2
1 x 300 Alrm + as50 Red	2120	41,4
1 x 400 Alrm + as35 Red	2281	43,8
1 x 400 Alrm + as50 Red	2415	43,8
1 x 630 Alrm + as50 Red	3281	50,4
1 x 630 Alrm + as35 Red	3148	50,4
1 x 800 Alrm + as50 Red	3866	54,1
1 x 1000 Alrm + as50 Red	4556	58,3

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

1.what is our payment term ?

Our payment term is usually T/T 30% advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China HD 620-10j / Nen 3620 8.7/15kv 12/20kv 18/30kv Ymz1krvasdlwd-Al LSZH Medium Voltage Water Blocking Aluminium Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
