H07zz-F En 50525-3-21 Halogen-Free LSZH Rubber Flexible Cable

H07zz-F En 50525-3-21 Halogen-Free LSZH Rubber Flexible Cable image

Get Latest Price Request a quote

Product Details

Model NO.

H07ZZ-F

Current

DC & AC

Insulation Material

Epr/EPDM

Sheath Material

LSZH

Material Shape

Round Wire

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

Ycw

Brand

Huadong

Product Name

Flexible LSZH Rubber Cable

Rated Voltage

450/750V

Cross Section Size

1.5-300mm2

Cores

1-5 Cores

Standards

En 50525-3-21, HD 22-13, Cei 20-19 Part 13, En 602

Temperature

-20 C to +90 C

Warranty

100% Qualified

Sample

Available

Color

Blue, Black, Brown, Green/Yellow

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

H07ZZ-F EN 50525-3-21 LSZH Rubber Flexible Cable
The H07ZZ-F cable, renowned for its Low Smoke Zero Halogen (LSZH) composition, serves as a reliable alternative to the H07RN-F Rubber Flexible cable. It offers comparable flexibility for power distribution while addressing fire safety concerns.

APPLICATION
For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Examples of use include supplying mobile power units, UPS installations, stage lighting and audio visual equipment. This cable will withstand medium mechanical stresses and is suitable for both installation indoors and outdoors

CHARACTERISTICS
Voltage Rating Uo/U 450/750V
Temperature Rating
Fixed: -20°C to +90°C
Flexed: -5°C to +50°C
Minimum Bending Radius
Fixed: 4 x overall diameter
Flexed: 6 x overall diameter

CONSTRUCTION

Conductor Class 5 flexible copper conductor
Insulation LSZH (Low Smoke Zero Halogen) cross-linked compound
Sheath LSZH (Low Smoke Zero Halogen) cross-linked compound

STANDARDS
EN 50525-3-21, HD 22-13, CEI 20-19 Part 13, EN 60228
Flame Retardant according to IEC/EN 60332-3-10

Cross Section (mm²)	Nominal Overall Diameter (mm)	Approximate Weight	Min.Bending Radius	Max. Resistance of Conductors
Cross Section (mm²)	Nominal Overall Diameter (mm)	(kg / km)	(free movement) (mm)	at 20°C (ohm / km)
1×1,5	6,20	56	25	13,30
1×2,5	6,80	71	27	7,98
1×4	7,70	97	31	4,95
1×6	8,40	123	34	3,30
1×10	10,30	191	41	1,91
1×16	11,50	260	46	1,21
1×25	14,20	388	71	0,78
1×35	15,50	502	78	0,554
1×50	17,80	680	89	0,386
1×70	20,10	927	121	0,272
1×95	22,50	1.185	135	0,206
1×120	24,60	1.470	148	0,161
1×150	26,80	1.797	161	0,129
1×185	29,50	2.167	177	0,106
1×240	33,00	2833	198	0,0801
1×300	36,00	3442	216	0,0641
1×400	41,30	4459	248	0,0486
1×500	44,60	5748	268	0,0384
1×630	47,80	7178	287	0,0287
2×1	8,40	100	34	19,50
2×1,5	9,40	128	38	13,30
2×2,5	11,00	181	44	7,98
2×4	12,60	248	63	4,95
2×6	14,00	318	70	3,30
2×10	19,60	601	98	1,91
2×16	22,00	799	132	1,21
2×25	26,80	1.184	161	0,78
3×1	9,10	121	36	19,50
3×1,5	10,10	153	40	13,30
3×2,5	11,80	217	47	7,98
3×4	13,50	300	68	4,95
3×6	15,00	390	75	3,30
3×10	21,10	731	127	1,91
3×16	23,60	980	142	1,21
3×25	29,20	1.483	175	0,78
3×35	31,70	1.873	190	0,554
3×50	36,60	2.546	220	0,386
3×70	41,30	3.429	248	0,272
3×95	46,60	4.413	280	0,206
3×120	50,90	5.430	305	0,161
3×150	55,50	6.614	333	0,129
3×185	61,30	8.021	368	0,106
3×240	69,80	10627	419	0,0801
3×300	77,10	13055	463	0,0641
4×1	10,10	150	40	19,50
4×1,5	11,20	191	45	13,30
4×2,5	13,00	269	65	7,98
4×4	14,90	374	75	4,95
4×6	16,70	493	84	3,30
4×10	23,00	894	138	1,91
4×16	25,80	1.211	155	1,21
4×25	32,40	1.867	194	0,78
4×35	35,10	2.361	211	0,554
4×50	40,50	3.206	243	0,386
4×70	45,90	4.352	275	0,272
4×95	51,80	5.646	311	0,206
4×120	56,50	6.888	339	0,161
4×150	61,80	8.424	371	0,129
4×185	68,40	10.231	410	0,106
4×240	77,80	13535	467	0,0801
4×300	86,00	16633	516	0,0641
5×1	11,10	182	44	19,50
5×1,5	12,40	235	62	13,30
5×2,5	14,40	331	72	7,98
5×4	16,70	469	84	4,95
5×6	19,00	622	95	3,30
5×10	25,30	1.091	152	1,91
5×16	28,60	1496	172	1,21
5×25	25,90	2302	155	0,78
6×1,5	14,60	317	73	13,30
6×2,5	16,80	438	84	7,98
6×4	19,30	609	97	4,95
7×1,5	14,60	327	73	13,30
7×2,5	16,80	454	84	7,98
7×4	19,30	635	97	4,95
12×1,5	19,20	531	96	13,30
12×2,5	22,10	739	133	7,98
12×4	25,80	1.061	155	4,95
18×1,5	22,40	742	134	13,30
18×2,5	26,00	1.050	156	7,98
18×4	30,30	1507	182	4,95
24×1,5	26,20	967	157	13,30
24×2,5	30,60	1.382	184	7,98
36×1,5	30,00	1.344	180	13,30
36×2,5	35,20	1.944	211	7,98

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables

1.You are manufacturer or trader ?
Huadong cable is a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for yo

We are China H07zz-F En 50525-3-21 Halogen-Free LSZH Rubber Flexible Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.

Get Latest Price Request a quote

Tags: Halogen-Free Cable, Henan Huadong Cable Co., Ltd., Rubber Cable

H07zz-F En 50525-3-21 Halogen-Free LSZH Rubber Flexible Cable

You May Like

Aluminum Conductor Steel Reinforced Overhead Cables ACSR Conductor

0.5mm2 0.75mm2 300/300V Power Cable PVC Insulated Sheathed Cable H03vvf

Copper Conductors PVC Insulation Nylon Jacket Nmd90 Cables

6/10kv Single Core Mv Aluminum Conductor XLPE Insulation PVC Sheath Power Cable

Copper Conductor XLPE Insulated LSZH Sheath Flexible Cable Cu/XLPE/LSZH 0.6/1kv

Electric Wire Low Voltage XLPE Insulation and PVC Sheath Exported to Asia Yjv22 Cable

Construction 185mm Copper Conductor Electrical Mv Medium Voltage 500mm XLPE Single Core Cable
