H07V-U H07V-K H07V-R 450/750V 2.5mm2 4mm2 6mm2 10mm2 16mm² Single Core Copper Wire PVC Electrical Wire Flexible Wire and Cable Building Wire

H07V-U H07V-K H07V-R 450/750V 2.5mm2 4mm2 6mm2 10mm2 16mm² Single Core Copper Wire PVC Electrical Wire Flexible Wire and Cable Building Wire image

Get Latest Price Request a quote

Product Details

Model NO.

Wire

Application

Heating, Underground

Conductor Material

Copper

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

household

Certification

ISO9001, CE, CCC

Standard

IEC BS ASTM

Material

Hard Drawn Copper Wire

Size

4mm2

No of Wires

Conductor Shape

Round

HS Code Number

8544492100

Origin Country

China

Color

White, Red, Black, Green, Yellow, Blue

Transport Package

in Coil

Specification

4mm2

Trademark

Qifan

Origin

China

Production Capacity

30000km/Month

Product Description

H07V-U H07V-K H07V-R 450/750V 2.5mm2 4mm2 6mm2 10mm2 16mm² Single Core Copper Wire PVC Electrical Wire Flexible Wire and Cable Building Wire

H07V-U

Code	:	BV, H07V-U, NYA
Standards	:	227IEC01, BS 6004, VDE0281-3
Construction	:	1- Solid Copper Conductor
		2- PVC insulation
Application	:	Preferably for installation indoors, in cable ducts and in industrial plants or switching stations,
		under ground installation.
Technical Data	:	Max. operating temperature 70 ºC
		Short circuit temperature 160 ºC

Nominal Cross Section	Wire Diameter	Thickness of insulation	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
mm²	No. ×mm	mm	min	max	Ù/km	kg/km	Pip A	Air A
1.5	1.35	0.7	2.6	3.2	12.1	19	16	24
2.5	1.73	0.8	3.2	3.9	7.41	29	20	32
4	2.19	0.8	3.6	4.4	4.61	42	26	42
6	2.68	0.8	4.1	5.0	3.08	62	35	55
10	3.50	1.0	5.3	6.4	1.83	110	46	75

H07V-R

450/750V

Code	:	H07V-R, NYA
Standard	:	IEC 227, BS 6004,VDE 0281
Construction	:	1- Stranded Copper Conductor
		2- PVC Insulation
Application	:	Preferably for installation indoors. in cable ducts and in industrial plants or
		switching stations. under ground installation.
Technical Data	:	Max. operating temperature 70ºC
		Short circuit temperature 160ºC

Nominal Cross Section	Number of wires and Dia.	Thickness of insulation	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
mm²	No. ×mm	mm	min	max	Ù/km	Kg/km	Pip A	Air A
1.5	7×0.51	0.7	2.7	3.3	12.1	22.0	16	25
2.5	7×0.66	0.8	3.3	4.0	7.41	36.0	20	34
4	7×0.83	0.8	3.8	4.6	4.61	52.0	26	45
6	7×1.02	0.8	4.3	5.2	3.08	74.0	35	57
10	7×1.32	1.0	5.6	6.7	1.83	110	46	75
16	7×1.68	1.0	6.4	7.8	1.15	170	62	100
25	7×2.20	1.2	8.1	9.7	0.727	265	82	130
35	7×2.55	1.2	9.0	10.9	0.524	360	100	160
50	7×3.00	1.4	10.6	12.8	0.387	501	120	200

H07V-K

450/750V

Code	:	RV,H07V-K, NYAF
Standard	:	IEC 227, VDE 0281, BS 6004
Construction	:	1- Flexible Copper Conductor
		2- PVC Insulation
Application	:	For protected installation in equipment and lighting fitting.
		Also for in conduit, on and under plaster
Technical Data	:	Max. operating temperature 70ºC
		Short circuit temperature 160ºC

Nominal Cross Section	Number of wires and Dia.	Thickness of insulation	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
mm²	No. ×mm	mm	min	max	Ù/km	Kg/km	Pip A	Air A
1.5	27×0.25	0.7	2.8	3.4	13.3	21.0	15	24
2.5	45×0.25	0.8	3.4	4.1	7.98	32.0	20	32
4	50×0.30	0.8	3.9	4.8	4.95	48.0	25	42
6	75×0.30	0.8	4.4	5.3	3.30	68.0	33	54
10	73×0.40	1.0	5.7	6.8	1.91	113	45	73
16	119×0.40	1.0	6.7	8.1	1.21	174	61	98
25	182×0.40	1.2	8.4	10.2	0.780	282	83	129
35	252×0.40	1.2	9.7	11.7	0.554	378	103	158
50	364×0.40	1.4	11.5	13.9	0.386	543	120	198

H05VV-F

300/500V

Code	:	H05VV-F, RVV
Standard	:	IEC 227, VDE 0281, BS 6500
Construction	:	1- Flexible Copper Conductor
		2- PVC insulation. 3- PVC Filling. 4- PVC Outer Sheath
Application	:	For household appliances under medium mechanical stress-also in damp and wet areas
Technical Data	:	Max. operating temperature 70ºC
		Short circuit temperature 160ºC

Nominal Cross Section	Number and Dia.	Thickness of insulation	Thickness of Sheath	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
No	No. ×mm	mm	Mm	min	max	Ù/km	Kg/km	Air A
2×0.75	22×0.20	0.6	0.8	5.7	7.2	26.0	57.1	8
2×1	30×0.20	0.6	0.8	5.9	7.5	19.5	64.0	12
2×1.5	27×0.25	0.7	0.8	6.8	8.6	13.3	91.0	18
2×2.5	45×0.25	0.8	1.0	8.4	10.6	7.98	135	26
2×4	50×0.30	0.8	1.1	9.7	12.1	4.95	189	32
2×6	75×0.30	0.8	1.1	11.8	13.1	3.30	274	42
2×10	73×0.40	0.9	1.2	14.6	15.8	1.91	422	70
3×0.75	22×0.20	0.6	0.8	6.0	7.6	26.0	68.1	8
3×1	30×0.20	0.6	0.8	6.3	8.0	19.5	77.1	12
3×1.5	27×0.25	0.7	0.9	7.4	9.4	13.3	109	18
3×2.5	45×0.25	0.8	1.0	9.2	11.4	7.98	169	26
3×4	50×0.30	0.8	1.1	10.5	13.1	4.95	238	32
3×6	75×0.30	0.8	1.1	12.5	14.2	3.30	343	42
3×10	73×0.40	0.9	1.2	15.8	17.2	1.91	538	70
4×0.75	22×0.20	0.6	0.8	6.6	8.3	26.0	85.2	8
4×1	30×0.20	0.6	0.8	7.1	9.0	19.5	98.0	12
4×1.5	27×0.25	0.7	0.8	8.4	10.5	13.3	145	18
4×2.5	45×0.25	0.8	1.1	11.0	12.5	7.98	213	26
4×4	50×0.30	0.8	1.2	11.5	14.3	4.95	306	32
4×6	75×0.30	0.8	1.3	13.6	15.2	3.30	427	42
4×10	73×0.40	0.9	1.4	17.2	18.3	1.91	674	70
4×16	119×0.40	0.9	1.5	19.4	20.8	1.21	972	80
5×0.75	22×0.20	0.6	0.8	7.4	9.3	26.0	101	8
5×1	30×0.20	0.6	0.9	7.8	9.8	19.5	125	12
5×1.5	27×0.25	0.7	1.1	9.3	11.6	13.3	176	18
5×2.5	45×0.25	0.8	1.2	11.2	13.9	7.98	261	26
5×4	50×0.30	0.8	1.3	13.0	16.1	4.95	375	32
5×6	75×0.30	0.8	1.4	15.6	16.8	3.30	524	42
5×10	73×0.40	0.9	1.5	18.2	20.3	1.91	831	70
5×16	119×0.40	0.9	1.6	22.3	23.2	1.21	1170	80

H05VVH2-F

300/500V

Code	:	H05VVH2-F
Standard	:	TS 9760, IEC 227, VDE 0281,BS 6500
Construction	:	1- Flexible Copper Conductor
		2- PVC insulation
		3- PVC outer sheath
Application	:	In dry. damp and wet locations as flexible connecting cables for light mechanical stresses.
		It is used for hand tools and house hold appliances with flat shape.
Technical Data	:	Max. operating temperature 70ºC
		Short circuit temperature 160ºC

Num. of Cores and Nominal Cross Section	Number and Dia.	Thickness of insulation		Approx. OD	Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
No×mm²	No. ×mm	min	max	max.mm	Ù/km	Kg/km	Pip A	Air A
2 × 0.75	22 × 0.20	0.6	0.8	4.00 × 6.40	26.0	37.0	–	13
2 × 1	30 × 0.20	0.6	0.8	4.10 × 6.60	19.5	61.1	12	16
2 × 1.5	27 × 0.25	0.7	0.8	4.60 × 7.60	13.3	85.0	16	20
2 × 2.5	45 × 0.25	0.8	1.0	5.70 × 9.40	7.98	128	21	27
2 × 4	50 × 0.30	0.8	1.1	6.40 × 10.6	4.95	185	27	36
3 × 0.75	22 × 0.20	0.6	0.8	4.00 × 8.80	26.0	65.0	–	13
3 × 1	30 × 0.20	0.6	0.8	4.10 × 9.10	19.5	77.0	12	16
3 × 1.5	27 × 0.25	0.7	0.9	4.70 × 10.50	13.3	104	16	20
3 × 2.5	45 × 0.25	0.8	1.1	5.90 × 13.30	7.98	159	21	27
3 × 4	50 × 0.30	0.8	1.2	6.60 × 15.60	4.95	228	27	36

H05V2-K

300/500V

Code	:	H05V2-K
Standard	:	TS 9758, IEC 227, VDE 0281, BS 6004
Construction	:	1- Flexible Copper Conductor
		2- PVC insulation
Application	:	For protected installation in equipment and lighting fitting.
		Also for in conduit. on and under plaster.
Technical Data	:	Max. operating temperature 90 ºC
		Short circuit temperature 160 ºC

Nominal Cross Section	Number and Dia.	Thickness of insulation	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
mm²	No. ×mm	mm	min	max	Ù/km	Kg/km	Pip A	Air A
0.5	15 × 0.20	0.6	2.1	2.5	39.0	10.0	–	–
0.75	22 × 0.20	0.6	2.2	2.7	26.0	12.0	–	16
1	30 × 0.20	0.6	2.4	2.8	19.5	15.0	12	20

H07V2-K

450/750V

Code	:	H07V2-K
Standard	:	TS 9758, IEC 227, VDE 0281, BS 6004
Construction	:	1- Flexible Copper Conductor
		2- PVC insulation
Application	:	For protected installation in equipment and lighting fitting.
		Also for in conduit. on and under plaster.
Technical Data	:	Max. operating temperature 90 ºC
		Short circuit temperature 160 ºC

Nominal Cross Section	Number and Dia.	Thickness of insulation	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
mm²	No. ×mm	mm	min	max	Ù/km	Kg/km	Pip A	Air A
1.5	27 × 0.25	0.7	2.8	3.4	13.3	21.0	15	24
2.5	45 × 0.25	0.8	3.4	4.1	7.98	32.0	20	32
4	50 × 0.30	0.8	3.9	4.8	4.95	48.0	25	42
6	75 × 0.30	0.8	4.4	5.3	3.30	68.0	33	54
10	73 × 0.40	1.0	5.7	6.8	1.91	113	45	73
16	119 × 0.40	1.0	6.7	8.1	1.21	174	61	98
25	182 × 0.40	1.2	8.4	10.2	0.780	282	83	129
35	252 × 0.40	1.2	9.7	11.7	0.554	378	103	158
50	364 × 0.40	1.4	11.5	13.9	0.386	543	132	198

H05V2V2-F

300/500V

Code	:	H05V2V2-F
Standard	:	TS 9760, IEC 227, VDE 0281, BS 6500
Construction	:	1- Flexible Copper Conductor
		2- PVC insulation
		3- PVC outer sheath
Application	:	In dry. damp and wet locations as flexible connecting cables for light mechanical
		stresses. It is used for hand tools. heat tools and house hold appliances with flat shape.
Technical Data	:	Max. operating temperature 90ºC
		Short circuit temperature 160 ºC

Num. of Cores and Nominal Cross Section	Number and Dia.	Thickness of insulation	Thickness of Sheath	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC




No ×mm²	mm	mm		min	max	Ù/km	Kg/km	Air A
2 × 0.75	22 × 0.20	0.6	0.8	5.7	7.2	26.0	57.0	8
2 × 1	30 × 0.20	0.6	0.8	5.9	7.5	19.5	64.1	12
2 × 1.5	27 × 0.25	0.7	0.8	6.8	8.6	13.3	91.0	18
2 × 2.5	45 × 0.25	0.8	1.0	8.4	10.6	7.98	135	26
2 × 4	50 × 0.30	0.8	1.1	9.7	12.1	4.95	189	32
2 × 6	75 × 0.30	0.8	1.1	11.8	13.1	3.30	274	42
2 × 10	73 × 0.40	0.9	1.2	14.6	15.8	1.91	422	70
3 × 0.75	22 × 0.20	0.6	0.8	6.0	7.6	26.0	68.1	8
3 × 1	30 × 0.20	0.6	0.8	6.3	8.0	19.5	77.0	12
3 × 1.5	27 × 0.25	0.7	0.9	7.4	9.4	13.3	109	18
3 × 2.5	45 × 0.25	0.8	1.1	9.2	11.4	7.98	169	26
3 × 4	50 × 0.30	0.8	1.2	10.5	13.1	4.95	238	32
3 × 6	75 × 0.30	0.8	1.1	12.5	14.2	3.30	343	42
3 × 10	73 × 0.40	0.9	1.2	15.8	17.2	1.91	538	70
4 × 0.75	22 × 0.20	0.6	0.8	6.6	8.3	26.0	85.0	8
4 × 1	30 × 0.20	0.6	0.8	7.1	9.0	19.5	98.0	12
4 × 1.5	27 × 0.25	0.7	0.8	8.4	10.5	13.3	145	18
4 × 2.5	45 × 0.25	0.8	1.1	11	12.5	7.98	213	26
4 × 4	50 × 0.30	0.8	1.2	11.5	14.3	4.95	306	32
4 × 6	75 × 0.30	0.8	1.3	13.6	15.2	3.30	427	42
4 × 10	73 × 0.40	0.9	1.4	17.2	18.3	1.91	674	70
4 × 16	119 × 0.40	0.9	1.5	19.4	20.8	1.21	972	80
5 × 0.75	22 × 0.20	0.6	0.8	7.4	9.3	26.0	101	8
5 × 1	30 × 0.20	0.6	0.9	7.8	9.8	19.5	125	12
5 × 1.5	27 × 0.25	0.7	1.0	9.3	11.6	13.3	176	18
5 × 2.5	45 × 0.25	0.8	1.1	11.2	13.9	7.98	261	26
5 × 4	50 × 0.30	0.8	1.3	13.0	16.1	4.95	375	32
5 × 6	75 × 0.30	0.8	1.4	15.6	16.8	3.30	524	42
5 × 10	73 × 0.40	0.9	1.5	18.2	20.3	1.91	831	70

NVV

300/500V

Code	:	NVV
Standard	:	TS 9759 HD 21,4 S2, VDE 0250-204, BS 6004
Construction	:	1- Solid or Stranded Copper Conductor
		2- PVC insulation 3- PVC Filling 4- PVC outer sheath
Application	:	Fixed wiring in dry and damp premises, in conduits. on or under plaster and on
		insulators over plaster, switching.
Technical Data	:	Max. operating temperature 70ºC Short circuit temperature 160ºC

Num. of Cores and Nominal Cross Section	Number and Dia.	Thickness of insulation	Thickness of Sheath	Mean overall diameter		Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
No ×mm²	mm	mm	mm	min	max	Ù/km	Kg/km	Air A
2 × 1.5	1.35	0.7	1.2	8.4	10.0	12.1	108	22
2 × 2.5	1.73	0.8	1.2	9.6	11.5	7.41	148	30
2 × 4	2.19	0.8	1.2	10.5	12.5	4.61	194	40
2 × 6	2.68	0.8	1.2	11.5	13.5	3.08	250	51
2 × 10	7 × 1.32	1.0	1.4	14.5	16.5	1.83	427	70
2 × 16	7 × 1.66	1.0	1.4	16.5	20.0	1.15	604	94
3 × 1.5	1.35	0.7	1.2	8.8	10.5	12.1	128	22
3 × 2.5	1.73	0.8	1.2	10.0	12.0	7.41	179	30
3 × 4	2.19	0.8	1.2	11.0	13.0	4.61	239	40
3 × 6	2.68	0.8	1.2	12.5	14.5	3.08	319	51
3 × 10	7 × 1.32	1.0	1.4	15.5	17.5	1.83	535	70
3 × 16	7 × 1.66	1.0	1.4	18.0	21.5	1.15	769	94
4 × 1.5	1.35	0.7	1.2	9.6	11.5	12.1	154	18.5
4 × 2.5	1.73	0.8	1.2	11.0	13.0	7.41	219	25
4 × 4	2.19	0.8	1.2	12.0	14.5	4.61	301	34
4 × 6	2.68	0.8	1.2	14.0	16.0	3.08	399	43
4 × 10	7 × 1.32	1.0	1.4	16.5	19.0	1.83	669	60
4 × 16	7 × 1.66	1.0	1.4	20.0	23.5	1.15	970	80
5 × 1.5	1.35	0.7	1.2	10.0	12.0	12.1	181	15.5
5 × 2.5	1.73	0.8	1.2	12.0	14.5	7.41	262	22
5 × 4	2.19	0.8	1.2	13.5	16.0	4.61	364	31
5 × 6	2.68	0.8	1.2	15.0	17.5	3.08	483	40
5 × 10	7 × 1.32	1.0	1.4	18.0	21.0	1.83	828	56.5

FLAT CABLES

300/500V

Code	:	Flat Cables
Standard	:	TS 9760, IEC 227, VDE 0281, BS 6500
Construction	:	1- Solid Copper Conductor
		2- PVC insulation
		3- PVC outer sheath
Application	:	Preferably for installation indoors, in cable ducts and in industrial plants or switching
		stations, under ground installation, with additional protection where mechanical damage
		is unexpected.
Technical Data	:	Max. operating temperature 70ºC
		Short circuit temperature 160ºC

Num. of Cores and Nominal Cross Section	Number and Dia.	Thickness of insulation	Thickness of Sheath	Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
No. ×mm²	No. ×mm	mm	mm	Ù/km	Kg/km	Pipe A	Air A
2 × 1	1.1	0.6	0.8	18.1	50.0	–	19
2 × 1.5	1.35	0.7	0.8	12.1	66.0	32	20
2 × 2.5	1.73	0.8	1.0	7.41	104	42	20
2 × 4	2.19	0.8	1.1	4.61	143	54	20
3 × 1	1.1	0.6	0.8	18.1	73.0	–	20
3 × 1.5	1.35	0.7	0.9	12.1	101	26	20
3 × 2.5	1.73	0.8	1.1	7.41	158	34	20
3 × 4	2.19	0.8	1.2	4.61	216	44	20

FLAT TWIN&THREE CORE

300/500V

Code	:	FLAT TWIN& THREE CORE CABLES
Standard	:	BS6004
Construction	:	1- Stranded Copper Conductor
		2- PVC insulation
		3- PVC outer sheath
Application	:	These Cables are used in dry or damp locations for fixed installation.
		Suitable for installation in walls or embedded in plaster.
Technical Data	:	Max. operating temperature 70ºC

Num. of Cores and Nominal Cross Section	Number and Dia.	Thickness of insulation	Thickness of Sheath	Conductor DC resistance at 20ºC	Approx. Total Weight	Max. Current Carrying Capacity at 30ºC
No ×mm²	No. ×mm	mm	mm	Ù/km	Kg/km	Pipe A	Air A
2 × 1.5	7 × 0.51	0.7	0.9	12.1	76..0	32	20
2 × 2.5	7 × 0.66	0.8	1.0	7.41	110	42	27
2 × 4	7 × 0.83	0.8	1.0	4.61	148	54	37
3 × 1.5	7 × 0.51	0.7	0.9	12.1	102	26	18
3 × 2.5	7 × 0.66	0.8	1.0	7.41	152	34	25
3 × 4	7 × 0.83	0.8	1.1	4.61	224	44	34

We are China H07V-U H07V-K H07V-R 450/750V 2.5mm2 4mm2 6mm2 10mm2 16mm² Single Core Copper Wire PVC Electrical Wire Flexible Wire and Cable Building Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.

Get Latest Price Request a quote
