Product Details

Model NO.

H07RN-F

Application

Mine

Conductor Material

Copper

Sheath Material

Pcp

Insulation Material

Rubber

Material Shape

Round Wire

Range of Application

Mine

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

QIFAN

Color of Insulation

as Per Requirements

Armour

Screen

Leadtime

15days

Transport Package

Drums or Customized

Specification

as per requirements

Trademark

Qifan

Origin

China

HS Code

8544492100

Production Capacity

1000000000 Meters Per Year

Product Description

H07RN-F Cable

Application

These cables are designed to provide high ffexibility and have the capacity to withstand weather, oils/greases, mechanical and thermal stresses. Applications include handling equipment, mobile power supplies, worksites, stage and audio visual equipment, port areas and dams. Also for use in drainage and water treatment, cold environments and severe industrial environments.

Standards

BS7919, CENELEC HD22.4 S4

Conductor

Class 5 ffexible plain copper to BS EN 60228:2005 (previously BS6360)

Insulation

EPR (Ethylene Propylene Rubber) Type EI4 to BS7655

Sheath

PCP (Polychloroprene) Type EM2 to BS7655

Sheath Colour

Black

Voltage Rating

450/750V

Temperature Rating

Conductor operating temperature -30°C to +60°C (85°C max)

Minimum Bending Radius

Up to 25mm2: 6 x overall diameter
Above 25mm2: 8 x overall diameter

Core Identiffcation

2 Cores: Blue, Brown
3 Cores: Green/Yellow, Blue, Brown
4 Cores: Green/Yellow, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
6 Cores and above: Black with White numerals, Green/Yellow

Demensions
