H07BN4-F 450/750V Torsion Resistant Cable
These cables with increased tolerance to torsion application, improved behaviour against abrasion and extended temperature, UV and ozone resistant are specially designed for wind turbines and to be used for the loop.
CONSTRUCTION
Insulation: Cold and heat resistant EPR. Special cross-linked EI7 rubber for high temperatures can be offered upon request.
Sheath: Ozone, UV-resistant, oil and cold-resistant special compound based on CM (chlorinated polyethylene)/CR (chloroprene rubber). Special cross-linked EM7 rubber can be offered upon request.
HD 22.12
Operating Temperatures:-40ºC~+90ºC
Minimum Bending Radius:6×OD
Maximum Permissible Tensile Load:15 N/mm²
Torsion Application :+/-150°/m
Short-circuit Temperature:250ºC
Flame Retardant:EN 50265-1/EN 50265-2-1/IEC 60332-1
Oil Resistant:Yes
Ozone Resistant:Yes
UV Resistant:Yes
|
Construction
|
Nominal Overall Diameter
|
Nominal Weight
|
|
No. of cores×mm²
|
mm
|
kg/km
|
|
1×25
|
13.5
|
371
|
|
1×35
|
15
|
482
|
|
1×50
|
17.3
|
667
|
|
1×70
|
19.3
|
888
|
|
1×95
|
22.7
|
1160
|
|
1×(G)10
|
28.6
|
175
|
|
1×(G)16
|
28.6
|
245
|
|
1×(G)25
|
28.6
|
365
|
|
1×(G)35
|
28.6
|
470
|
|
1×(G)50
|
17.9
|
662
|
|
1×(G)70
|
28.6
|
880
|
|
1×(G)120
|
24.7
|
1430
|
|
1×(G)150
|
27.1
|
1740
|
|
1×(G)185
|
29.5
|
2160
|
|
1×(G)240
|
32.8
|
2730
|
|
1×300
|
36
|
3480
|
|
1×400
|
40.2
|
4510
|
|
10G1.5
|
19
|
470
|
|
12G1.5
|
19.3
|
500
|
|
12G2.5
|
22.6
|
670
|
|
18G1.5
|
22.6
|
725
|
|
18G2.5
|
26.5
|
980
|
|
2×1.5
|
28.6
|
110
|
|
2×2.5
|
28.6
|
160
|
|
2×4
|
12.9
|
235
|
|
2×6
|
14.1
|
275
|
|
2×10
|
19.4
|
530
|
|
2×16
|
21.9
|
730
|
|
2×25
|
26.2
|
1060
|
|
24G1.5
|
26.4
|
980
|
|
24G2.5
|
31.4
|
1390
|
|
3×25
|
28.6
|
1345
|
|
3×35
|
32.2
|
1760
|
|
3×50
|
37.3
|
2390
|
|
3×70
|
43
|
3110
|
|
3×95
|
47.2
|
4170
|
|
3×(G)1.5
|
10.1
|
130
|
|
3×(G)2.5
|
12
|
195
|
|
3×(G)4
|
13.9
|
285
|
|
3×(G)6
|
15.6
|
340
|
|
3×(G)10
|
21.1
|
650
|
|
3×(G)16
|
23.9
|
910
|
|
3×120
|
51.7
|
5060
|
|
3×150
|
57
|
6190
|
|
4G1.5
|
11.2
|
160
|
|
4G2.5
|
13.6
|
240
|
|
4G4
|
15.5
|
350
|
|
4G6
|
17.1
|
440
|
|
4G10
|
23.5
|
810
|
|
4G16
|
25.9
|
1150
|
|
4G25
|
31
|
1700
|
|
4G35
|
35.3
|
2170
|
|
4G50
|
40.5
|
3030
|
|
4G70
|
46.4
|
3990
|
|
4G95
|
52.2
|
5360
|
|
4G120
|
56.5
|
6480
|
|
5G1.5
|
12.2
|
230
|
|
5G2.5
|
14.7
|
295
|
|
5G4
|
17.1
|
430
|
|
5G6
|
19
|
540
|
|
5G10
|
25
|
1020
|
|
5G16
|
28.7
|
1350
|
|
5G25
|
35
|
2080
|
|
5G35
|
38.4
|
2650
|
|
5G50
|
43.9
|
3750
|
|
5G70
|
50.5
|
4950
|
|
5G95
|
57.8
|
6700
|
|
6G1.5
|
14.7
|
295
|
|
6G2.5
|
16.9
|
390
|
|
7G1.5
|
16.5
|
350
|
|
7G2.5
|
18.5
|
460
|
|
8×1.5
|
17
|
400
|
