H05VV-F 300/500V 3X1.5mm2 BS 6500 PVC Insulated and Sheathed Flexible Cables
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012
1,Uo/U is 300/500V 450/750V,,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105ºC, the allowable
temperature of other models should not exceed 70ºC.
Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power
plant, household electrical applance,insurment and telecommunication equipment.
copper cable electric cable wire
|
Voltage Level
(V)
|
Nominal section
(mm²)
|
Toplimit of overall diameter
(mm)
|
Maximum DC resistance
(20ºC)
|
Minimum insulation resistance
(70ºC)
|
Recommended value of carrying capacity
(A)
|
Reference weight
(KG,KM)
|
|
300/500V
|
2×0.5
|
5.9
|
3.9
|
0.012
|
10
|
37
|
|
2×0.75
|
6.3
|
26.0
|
0.01
|
13
|
47
|
|
|
3×0.5
|
6.3
|
39.0
|
0.012
|
8
|
44
|
|
|
3×0.75
|
6.7
|
26.0
|
0.01
|
10
|
58
|
|
|
2×0.75
|
7.2
|
26.0
|
0.011
|
13
|
58
|
|
|
450/750V
|
2×1.0
|
7.5
|
19.5
|
0.01
|
16
|
66
|
|
2×1.5
|
8.6
|
13.30
|
0.01
|
20
|
89
|
|
|
2×2.5
|
10.6
|
7.98
|
0.009
|
27
|
137
|
|
|
2×4
|
12.4
|
4.95
|
0.007
|
38
|
205
|
|
|
2×6
|
14.5
|
3.30
|
0.006
|
50
|
280
|
|
|
3×0.75
|
7.6
|
26.00
|
0.011
|
9
|
70
|
|
|
3×1.0
|
8.0
|
19.50
|
0.01
|
11
|
80
|
|
|
3×1.5
|
9.4
|
13.300
|
0.01
|
12
|
112
|
|
|
3×2.5
|
11.4
|
7.980
|
0.009
|
21
|
172
|
|
|
3×4
|
13.5
|
4.950
|
0.007
|
27
|
255
|
|
|
3×6
|
14.0
|
3.30
|
0.006
|
34
|
340
|
|
|
4×0.75
|
8.3
|
26.0
|
0.011
|
10
|
84
|
|
|
4×1.0
|
9.0
|
19.50
|
0.01
|
12
|
101
|
|
|
4×1.5
|
10.5
|
13.30
|
0.01
|
13
|
141
|
|
|
4×2.5
|
12.5
|
7.98
|
0.009
|
21
|
210
|
|
|
4×4
|
14.6
|
4.95
|
0.007
|
27
|
310
|
|
|
4×6
|
16.0
|
3.30
|
0.006
|
35
|
425
|
|
|
5×0.75
|
9.3
|
26.00
|
0.011
|
10
|
103
|
|
|
5×1.0
|
9.8
|
19.50
|
0.01
|
12
|
119
|
|
|
5×1.5
|
11.6
|
13.30
|
0.01
|
13
|
172
|
|
|
5×2.5
|
13.9
|
7.98
|
0.009
|
22
|
257
|
|
|
5×4
|
16.5
|
4.95
|
0.007
|
27
|
386
|
|
|
5×6
|
17.3
|
3.30
|
0.006
|
35
|
518
|
| Spec | Cross section mm2 | Dia | insulation thicknese | sheath thickness | outer Dia | weightH05vv |
| H05vvf | 2*1.5 | 2*30/0.25 | 0.7 | 0.8 | 7.8 | 90 |
| H05vvf | 2*2.5 | 2*50/0.25 | 0.8 | 1 | 9.5 | 115 |
| H05vvf | 2*4 | 2*56/0.3 | 0.8 | 1.2 | 11.4 | 215 |
| H05vvf | 2*6 | 2*84/0.3 | 0.8 | 1.3 | 12.8 | 290 |
| H05vvf | 3*1.5 | 3*30/0.25 | 0.7 | 0.8 | 8.5 | 115 |
We are China H05VV-F 300/500V 3X1.5mm2 BS 6500 PVC Insulated and Sheathed Flexible Cables manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
