H05ss-K Atc Silicone Rubber Insulated 300/500 V Rated Cable

H05ss-K Atc Silicone Rubber Insulated 300/500 V Rated Cable image

Get Latest Price Request a quote

Product Details

Model NO.

H05SS-K

Application

Heating, Electrical Appliances

Conductor Material

Tinned Copper

Sheath Material

Silicone Rubber

Insulation Material

Silicone Rubber

Material Shape

Round Wire

Certification

VDE

Brand

Huadong

Rated Voltage

300/500V

Cores

Single Core

Size

0.75mm to 2.5mm

Temperature Range

-55 to 180c

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

H05SS-K) – ATC Silicone Rubber Insulated 300/500 V Rated Cable

Application

For wiring at high ambient temperature zones like boiler house, etc.

Electric motor industry.

Air- Conditioning technology.

Furnace construction.

Thermal and heating elements.

Product Construction

Conductor : Annealed Tinned Copper Conductor (Opt: APC) as per EN 60228, Class 5

Insulation : Elastomeric Compound Type EI 2 (Silicone Rubber)

Sheath : Elastomeric Compound Type EM 9 (Silicone Rubber)

Insulation Colour : Black (or) As per customer order

Technical Data

Specification : BS EN 50525-2-41 (0.75 Sq.mm to 2.5 Sq.mm – Class-5)

Test Voltage : 2000V

Operating Temperature : -55°C to 180°C

Rated Voltage : 300/500V

Max. Temperature of short circuit : 350°C

Min. Insulation Resistance Constant at 27°C : 3670 MΩ.km

Features

High Temperature-resistant Halogen free Cold Resistant Flame Retardant Weather Resistant

Size	Conductor Construction No.of Stands x Stand dia Nos x mm (Nom.)	Nominal Insulation Thickness	Thickness of Sheath (Nom.)	Overall Diameter		Max.Conductor Resistance at 20°ºC	Weight (Approx.)
Size		Nominal Insulation Thickness	Thickness of Sheath (Nom.)	Lower Limit	Upper Limit	Max.Conductor Resistance at 20°ºC	Weight (Approx.)
mm	mm	mm	mm	mm	mm	Ω/km	Kg/Km
0.75	24×0.20	0.6	0.8	3.7	4.7	26.7	25
1	32×0.20	0.6	0.9	4.1	5.1	20.0	30
1.5	30×0.25	0.8	1.0	4.9	6.1	13.7	42
2.5	50×0.25	0.9	1.1	5.7	7.1	8.21	60
