H05RNH2-F Light Chain lumination Flat Rubber Cable
Application:
This cable is used in dry, humid and wet locations, as well as outdoors as a clamping cable for standardised lamp holders for the illumination of spaces and gardens.
Construction:
1 ….. fine-stranded tinned copper
2 ….. ethylene propylene rubber (NR) or
styrene-butadiene rubber (SBR) insulation
3 ….. polychloroprene (CR) inner sheath
4 ….. polychloroprene (CR) outer sheath, green
| Nominal voltage Uo/U | [V] | 300 / 500 volt | |
| Test voltage | [V]AC | 2000 | |
| Temperature range | in motion | -25°C till +50°C | |
| Operating temperature | short circuit | °C | 200 |
| Short circuit time | max. | [sec] | 5 |
| Bending radius | min. | x diameter | 6 |
| Flammability | standard | EN 60332-1-2 |
| Nominal cross section | figure | construction | measures | appr. |
| mm2 | kg/km | (appr. value) mm | appr. mm | kg/km |
| 2 x 1,5 | 30 | 30 x 0,26 | 6,0 x 14,0 | 130 |
| 2 x 2,5 | 50 | 50 x 0,26 | 6,5 x 14,5 | 145 |
