H03RN-F H05RN-F H07RN-F 3X1.5 3X2.5 3X3.5mm2 HEPR Flexible Flat Rubber Submersible Pump Cable
H07/05RN-F Rubber Cable Feature:
2. Insulation: EPR(Ethylene Propylene Rubber)
3. Sheath: PCP(Polychioroprene)
4. Cores: 1 2 3 4 5 Cores or Others
5. Voltage: 450/750V,300/500V
6. Temperature Rating: conductor operation temperature -40°C to +60°C(90°C max)
7. Minimum Bending Radius: Up to 25mm2,6xoverall diameter;
8. Above to 25mm2: 8x overall diameter
H07/05RN-F Rubber Cable Application
These cables are designed to provide high flexibility and have the capacity to withstand weather, oil/grease, mechanical
and thermal stresses. Applications include handling equipment, mobile power supplies, worksites, stage and audio visual
equipment, port areas and dams. Also for use in drainage and water treatment, cold environments and severe industrial
environments.
|
NO. OF
CORES
|
NOMINAL CROSS
SECTIONAL AREA
|
NOMINAL
THICKNESS OF INSULATION
|
NOMINAL OVERALL
DIAMETER
|
NOMINAL
WEIGHT
|
|
mm²
|
mm
|
mm
|
kg/km
|
|
|
1
|
1.5
|
0.8
|
5.8
|
52
|
|
1
|
2.5
|
0.9
|
6.5
|
67
|
|
1
|
4
|
1
|
7.4
|
92
|
|
1
|
6
|
1
|
8.1
|
119
|
|
1
|
10
|
1.2
|
9.8
|
185
|
|
1
|
16
|
1.2
|
11.35
|
258
|
|
1
|
25
|
1.4
|
13.3
|
375
|
|
1
|
35
|
1.4
|
14.6
|
485
|
|
1
|
50
|
1.6
|
17.2
|
669
|
|
1
|
70
|
1.6
|
19.35
|
892
|
|
1
|
95
|
1.8
|
22.2
|
1160
|
|
1
|
120
|
1.8
|
24.3
|
1436
|
|
1
|
150
|
2
|
25.9
|
1748
|
|
1
|
185
|
2.2
|
29.7
|
2142
|
|
1
|
240
|
2.4
|
31.5
|
2698
|
|
1
|
300
|
2.6
|
36.5
|
3348
|
|
1
|
400
|
2.8
|
40.4
|
4293
|
|
1
|
500
|
3
|
42.6
|
5262
|
|
1
|
630
|
3
|
47.2
|
6790
|
|
2
|
1
|
0.8
|
8.1
|
94
|
|
2
|
1.5
|
0.8
|
9
|
120
|
|
2
|
2.5
|
0.9
|
10.7
|
173
|
|
2
|
4
|
1
|
12.3
|
239
|
|
2
|
6
|
1
|
13.8
|
313
|
|
2
|
10
|
1.2
|
18.6
|
563
|
|
2
|
16
|
1.2
|
21.7
|
830
|
|
2
|
25
|
1.4
|
25.8
|
1211
|
|
3
|
1
|
0.8
|
8.74
|
117
|
|
3
|
1.5
|
0.8
|
9.68
|
147
|
|
3
|
2.5
|
0.9
|
11.48
|
223
|
|
3
|
4
|
1
|
13.2
|
297
|
|
3
|
6
|
1
|
14.78
|
390
|
|
3
|
10
|
1.2
|
19.9
|
705
|
|
3
|
16
|
1.2
|
23.31
|
1031
|
|
3
|
25
|
1.4
|
27.7
|
1512
|
|
3
|
35
|
1.4
|
30.2
|
1907
|
|
3
|
50
|
1.6
|
35.8
|
2651
|
|
3
|
70
|
1.6
|
40.1
|
3484
|
|
3
|
95
|
1.8
|
46.4
|
4594
|
|
4
|
1
|
0.8
|
9.63
|
142
|
|
4
|
1.5
|
0.8
|
10.63
|
180
|
|
4
|
2.5
|
0.9
|
12.6
|
260
|
|
4
|
4
|
1
|
14.6
|
336
|
|
4
|
6
|
1
|
16.4
|
449
|
|
4
|
10
|
1.2
|
21.8
|
833
|
|
4
|
16
|
1.2
|
25.4
|
1138
|
|
4
|
25
|
1.4
|
30.7
|
1714
|
|
4
|
35
|
1.4
|
33.4
|
2204
|
|
4
|
50
|
1.6
|
39.6
|
3029
|
|
4
|
70
|
1.6
|
44.9
|
4121
|
|
4
|
95
|
1.8
|
51.9
|
5361
|
|
4
|
120
|
1.8
|
61.3
|
7400
|
|
5
|
1.5
|
0.8
|
11.8
|
206
|
|
5
|
2.5
|
0.9
|
14
|
297
|
|
5
|
4
|
1
|
16.2
|
422
|
|
5
|
6
|
1
|
18.2
|
567
|
|
5
|
10
|
1.2
|
24
|
1010
|
|
5
|
16
|
1.2
|
28.2
|
1400
|
|
5
|
25
|
1.4
|
33.9
|
2096
|
|
5
|
35
|
1.4
|
37.2
|
2700
|
|
5
|
50
|
1.6
|
44
|
3730
|
|
5
|
70
|
1.6
|
54
|
4945
|
|
5
|
95
|
1.8
|
63
|
6430
|
|
7
|
1.5
|
0.8
|
15.13
|
315
|
|
7
|
2.5
|
0.9
|
17.6
|
445
|
|
12
|
1.5
|
0.8
|
18.2
|
493
|
|
12
|
2.5
|
0.9
|
21.4
|
702
|
|
19
|
1.5
|
0.8
|
22.1
|
710
|
