UL Certificated Electric THHN Cable Wire
Applications:
THHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders, and branch circuits in commercial or industrial applications as specified in the National Electrical Code. Voltage for all applications is 600 volts.
When used as Type THHN, the conductor is suitable for use in dry locations at temperatures not to exceed 90°C.
When used as type THWN, the conductor is suitable for use at temperatures not to exceed 90°C in dry locations, 75°C in wet locations, or 75°C when exposed to oil or coolant.
When used as type THWN-2, the conductor is suitable for use in wet and dry locations at temperatures not to exceed 90°C or not to exceed 75°C when exposed to oil or coolant. Conductor temperatures not to exceed 105°C in dry locations when rated AWM and used as an appliance wiring material. The voltage rating for all applications is 600 volts.
Specifications:
- THHN or THWN-2 comply with:
- ASTM – B3, B8 (7,19, 37, 61 Strands), B 787 (19 Wire Combination Unilay Strand) Technical Compliance
- UL 83 – Thermoplastic-Insulated Wires and Cables
- CSA C22.2 No. 75-03
- UL 1063 (MTW) – Machine-Tool Wires and Cables (stranded cables only)
- UL 758 (AWM)
- ICEA S-95-658/NEMA WC 70
Cable Construction:
- Conductor: Soft annealed bare copper, Class B stranding per ASTM B8
- Insulation: Tough, heat and moisture-resistant Polyvinyl chloride (PVC) insulation over which a nylon jacket is applied
- Color: option
For more information, please contact Hebei Huatong Wires & Cables Group Co., Ltd.
Cable Parameter
|
AWG OR KCMIL |
STRAND | NOMINAL INSULATION THICKNESS INCH/MM |
NOMINAL JACKET THICKNESS INCH/MM |
NOMINAL OVERALL DIAMETER INCH/MM |
CABLE WEIGHT LBS/KFT KG/KM |
||||
| 14 | 1 | 0.015 | 0.38 | 0.004 | 0.10 | 0.11 | 2.79 | 15 | 22 |
| 12 | 1 | 0.015 | 0.38 | 0.004 | 0.10 | 0.12 | 3.05 | 23 | 34 |
| 10 | 1 | 0.020 | 0.51 | 0.004 | 0.10 | 0.15 | 3.81 | 37 | 54 |
| 14 | 19 | 0.015 | 0.38 | 0.004 | 0.10 | 0.11 | 2.79 | 16 | 24 |
| 12 | 19 | 0.015 | 0.38 | 0.004 | 0.10 | 0.13 | 3.30 | 24 | 36 |
| 10 | 19 | 0.020 | 0.51 | 0.004 | 0.10 | 0.17 | 4.32 | 39 | 58 |
| 8 | 19 | 0.030 | 0.76 | 0.005 | 0.13 | 0.22 | 5.59 | 63 | 94 |
| 6 | 19 | 0.030 | 0.76 | 0.005 | 0.13 | 0.26 | 6.60 | 98 | 145 |
| 4 | 19 | 0.040 | 1.01 | 0.006 | 0.15 | 0.33 | 8.38 | 157 | 234 |
| 3 | 19 | 0.040 | 1.01 | 0.006 | 0.15 | 0.36 | 9.14 | 193 | 287 |
| 2 | 19 | 0.040 | 1.01 | 0.006 | 0.15 | 0.39 | 9.91 | 240 | 357 |
| 1 | 19 | 0.050 | 1.27 | 0.007 | 0.18 | 0.43 | 10.92 | 300 | 446 |
| 1/0 | 19 | 0.050 | 1.27 | 0.007 | 0.18 | 0.47 | 11.94 | 376 | 560 |
| 2/0 | 19 | 0.050 | 1.27 | 0.007 | 0.18 | 0.52 | 13.21 | 467 | 695 |
| 3/0 | 19 | 0.050 | 1.27 | 0.007 | 0.18 | 0.57 | 14.48 | 581 | 864 |
| 4/0 | 19 | 0.050 | 1.27 | 0.007 | 0.18 | 0.64 | 16.26 | 724 | 1077 |
| 250 | 37 | 0.060 | 1.52 | 0.008 | 0.20 | 0.69 | 17.53 | 855 | 1272 |
| 300 | 37 | 0.060 | 1.52 | 0.008 | 0.20 | 0.76 | 19.30 | 1022 | 1521 |
| 350 | 37 | 0.060 | 1.52 | 0.008 | 0.20 | 0.79 | 20.07 | 1191 | 1772 |
| 400 | 37 | 0.060 | 1.52 | 0.008 | 0.20 | 0.85 | 21.59 | 1345 | 2001 |
| 500 | 37 | 0.060 | 1.52 | 0.008 | 0.20 | 0.94 | 23.88 | 1668 | 2482 |
| 600 | 61 | 0.070 | 1.78 | 0.009 | 0.23 | 1.10 | 27.94 | 1994 | 2967 |
| 750 | 61 | 0.070 | 1.78 | 0.009 | 0.23 | 1.16 | 29.46 | 2465 | 3668 |
