Good Price TUV Tinned Copper Solar PV Wire 6mm

Good Price TUV Tinned Copper Solar PV Wire 6mm image

Get Latest Price Request a quote

Product Details

Model NO.

2.5mm 4mm 6mm 10mm 16mm etc

Insulating Material

XLPE

Conductor Type

Stranded

Brand

Rne Da

Certification

TUV

Wire Core Material

Tinned Wire

Products Name

Solar Cable

Voltage Rating

1500V

Conductor

Tinned Copper Wire

Insulation

XLPE

Sheathed

XLPE

Temperature Rating

120c

Thermal Endurance Properties

25years

Size

2.5mm2 4.0mm2 6.0mm2 10mm2

Sheathed Color

Black and Red

Transport Package

Soft Packing

Specification

2.5mm2 4.0mm2 6.0mm2 10mm2 16mm2

Trademark

RNE DA

Origin

Hebei Province, China

HS Code

8544492100

Production Capacity

1000km/Week

Product Description

TUV Certification UV Resistance EN50618 Solar PV Cable 4mm 6mm 10mm

1 Application

TUV Approved Heat Resistant XLPE Insulated PV Cable for Solar Energy is used in a fixed installation, internal connection of solar panels. This product has excellent UV-resistant performance and is TUV approved.

2 Product Description (TUV and UL certificate)

1 .Standard: 2 PFG 1169 08.2007 and UL 4703

2 . Conductor Material: Stranded tinned copper
3. Insulation Material: XLPE
4. Sheath Material:XLPE
5. standard: TUV 2Pfg 1169 08.07

6. Rated voltage: AC Uo/U0.6~1.0KV, DC1.8KV

8.Ambient temperature: -40~+90C

9. The expected period of use: 25years

10. Flame rated IEC60332-1-2

3 Characteristic of solar cable:
1. Double insulation, electron beam cross-linked

2. Excellent resistance to UV, water, ozone, fluids, salt, general Weathering

3. Excellent resistance to abrasion

4. Halogen-free, flame retardant, low toxicity

5. Excellent flexibility and stripping performance

6. High current carrying capacity

7. TUV and UL approved

4 Datasheet of Solar cable:

Sectional area (mm2)	0.5	0.75	1	1.5	2.5	4	6	10	16
Copper (Ω/km)	36	24.5	18.1	12.1	7.41	4.61	3.08	1.83	1.15
Tinned copper (Ω/km)	36.7	24.8	18.2	12.2	7.56	4.7	3.11	1.84	1.16
Sectional area (mm2)	25	35	50	70	95	120	150	185	240
Copper (Ω/km)	0.727	0.524	0.387	0.268	0.193	0.153	0.124	0.0991	0.0754
Tinned copper (Ω/km)	0.734	0.529	0.391	0.27	0.195	0.154	0.126	0.1	0.0762

5 Packing of sloar cable:

Company information

HeBei huatong wires&cables Group Co.,ltd.

which founded in1993,covers 21,000 square meters.With 400 sets of manufacturing machines and 200 pieces of equipment available for testing and inspecting,the company’s annual mannufacturi-ng capacity has reached 800 minllionUS dollars.

The enterprise has adapted international a-dvanced mannagement standards by fully implementing the accreditation of ISO9001Quality con-trol system, ISO1004 Envrionment management system,and ISO45001 Occupational health and safety management system.

Huatong’s products which consist of 15 series of cables and tens of thousands of specifications are widely used in different key national projects and industries .Our products are well liked by domestic and international customers that they have been exported to various countries and areas including the US,Netherlands, Italy,Russia,UK,Australia,Ethiopia,Ghaha,congo,Middle East ,and Southeast Asia.

Largest UL and CUL Cable Manufacturer

Top 10 Cable manufactuer in China.
Largest Rubber cable manufacturer in China.
Leading ESP cable manufacturer.
Professional OEM manufacturer.
With UL,TUV,KEMA,CE,BV,PSB,SABS,MSHA,GL,NKK,KR,DNV,CCS certifications.
With TUV TYPE TESTING REPORT.

With ISO9001,ISO14001,ISO45001 syetem certifications.
ISO 17025 standard and CNAS approval laboratory.

2000+ employees, 2 factory in China .

First class level production equipment , test equipment , strict quality control
