Good Price Sans Standard 640/1100 V Yellow Jacket EPDM/Epr Type61A Type61 Ecc Type41 Flexible Trailing Cable

Good Price Sans Standard 640/1100 V Yellow Jacket EPDM/Epr Type61A Type61 Ecc Type41 Flexible Trailing Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Mining cable

Current

AC Cable

Insulation Material

Epr/EPDM

Sheath Material

CPE/Cr

Material Shape

Round Wire

Wire Core Material

Tinned Wire

Certification

ISO, CCC, CE, RoHS, VDE

Model

Type61A Type61 Ecc

Brand

Hebei Huatong Cables

Product Name

Mining Cable/Trailing Cable

Certificate

CE, ISO9001, ISO14001, Oashs18001, UL

Standard

Sans 1520-1

Sheath

CPE/Cr

Rated Voltage

640/1100V

Insulation

EPDM/Epr

Cross Section

10-240mm2

Number of Cores

3+3

Price

Direct Factory Price

Transport Package

Standard Export Drums

Specification

SANS1520-1

Trademark

Hebei Huatong Cables

Origin

Hebei, China

HS Code

8544492100

Production Capacity

1000000meter Per Month

Product Description

Type61 640/1100V Rubber Power Cable Tinned Copper Conductor Epr Insulation CPE Sheath Mining Cable

LARGEST CABLE MANUFACTUER IN NORTH CHINA

ANNUAL EXPORT VOLUME EXCEED 1000MILLION USD

WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS

CNAS APPROVAL LABROTARY

Applications:

Submersible pumps , on board wiring for machines .

Single , double ,triple drilling rigs ,loaders , low haulage dumpers , loaders , large drilling rigs.

Other industrial applications

Specifications:

Conductors Flexible class 5,inned annealed copper wires

Separator A suitable tape separator between the conductor and insulation.

Insulation Ethylene propylene thermosetting compound

Core of cable Three tinned copper braid screened power cores and two unscreened pilot core and one tinned earth

conductor laid up in the right hand lay around rubber dummy centre

Outer sheath Extra heavy duty yellow CPE sheath,Yellow.

Features

Excellent flexibility

Min. ambient temperature -25 oC , max. conductor temperature 90oC

Marking for easy identification

UV ,sunlight , ozone ,oil, resistant

Technical data

Physical Properties
Power cores
Conductor sizes (mm²)	16	25	35	50	70	95	120	150
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.51	0.51	0.51	0.51	0.51
Approx. conductor diameter ( mm)	5.3	6.8	8.5	10.3	11.9	13.5	15.5	17.3
Maximum screen wire diameter (mm)	0.31	0.31	0.31	0.31	0.31	0.31	0.31	0.31
Braided screen filling factor (%)	80	80	80	80	80	80	80	80
Approx. summarized screen cross-section for power cores (weighing method) (mm²)	22	25	27	32	37	43	47	52
Pilot cores
Conductor sizes ( mm²)	10	10	16	16	16	16	16	16
Maximum wire diameter ( mm)	0.41	0.41	0.41	0.41	0.41	0.41	0.41	0.41
Approx. conductor diameter ( mm)	4.2	4.2	5.3	5.3	5.3	5.3	5.3	5.3
Lay Ratio (maximum) (x PCD)	8	8	8	8	8	8	8	8
Cable diameter
Approx. (mm)	31	38	43	47	52	58	63	70
Cable mass (approx.) (kg/m)	1.8	3.1	3.6	4.5	5.6	7.0	8.4	10.2
Minimum bending radius (mm)	200	240	260	290	320	350	390	430
Maximum recommended tension (kN)	0.7	1.1	1.6	2.3	3.2	4.3	5.4	6.8

Company profile

Huatong extremely focuses on doing R&D high-tech, new-type, advanced products, till now, we have obtained UL, CSA, TUV, CE, PSB, SABS, BV, KEMA certifications and ISO9001, ISO14001, ISO45001 system certifications. CNAS accredited national level laboratory.

Company name : Hebei Huatong Wires and Cables Group Co., Ltd

Establishment : 1993

Registered capital : CNY430.82 Million, equal to: US$62 Million

Plant size : 420,000SQM

Employees : 2000+

Production capacity: US$1000Million

Sub-factories : in South Africa, Tanzania, Kazakhstan, Cameroon, etc.

Main products : ESP cable, mining cable, power cable up to 46KV, control cable, lift cable, shipboard cable, housing wire, and many other special cables.

Address : No.111 Huatong Avenue Fengnan Industrlal Zone Tangshan,Hebei Province, China

1. 30 years production experience and 22 years export experience .

2.Products certification :CUL UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

We are China Good Price Sans Standard 640/1100 V Yellow Jacket EPDM/Epr Type61A Type61 Ecc Type41 Flexible Trailing Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
