Galvanized Steel Tape Esp 3#2 AWG 5kv 3kv Oil Pump Submersible Cable

Galvanized Steel Tape Esp 3#2 AWG 5kv 3kv Oil Pump Submersible Cable image

Get Latest Price Request a quote

Product Details

Model NO.

ESP

Insulation Material

Epr

Sheath Material

Epr

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

Esp

Brand

Rneda

Size

10mm2 13mm2 16mm2 20mm2 33mm2 42mm2

Rated Voltage

1.8/3kv or 3.6/6kv

Armour

Steel Tape

Insulation

PP, Epr

Sheath

NBR, Lead

Working Temperature

200

Cable Type

Flat or Round

Transport Package

Wooden Drum

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

1000km Per Month

Product Description

High Performance ESP Cable 3 core high temperature submersible oil pump ESP Cable

Specifications

power supply of Electric submersible pumps system with the rating voltage below 6 kV,oil resistance & anti-corrosive resistance
EPR insulated and lead sheathed, galvanized steel tape interlocked armoring, cable for submersible oil pump

Application:

It is applied to power supply of ESP(Electric submersible pumps) system with the rating voltage less than 3kV or 6 kV, and has an outstanding capability of oil resistance and anti-corrosive resistance. The operating temperature of the conductor is 120°C,150°C,180°C,204°C,232°C,etc.

Standard: IEEE1018 API RP 11S6 GB/T16750 JB5332

Configuration:

Conductor — Solid or stranded tinned copper
Insulation — EPDM/EPR
Sheath — Alloy lead
Barrier — Oil resistant or braid tape Layer(Separator)
Armor — Galvanized or stainless steel interlocked armor

3kV Type

AWG No.	Cross-section (Approximation) mm2	Conductor No./diameter mm	Insulation Thickness mm	Sheath Thickness mm	Overall Dimensions mm×mm	Reference weight kg/km
1	3×42.4	1/7.35	1.9	1.0	16×45	3544
2	3×33.6	1/6.54	1.9	1.0	15×43	3116
4	3×21.1	1/5.19	1.9	1.0	14×38	2442
5	3×16.8	1/4.62	1.9	1.0	13×36	2211
6	3×13.3	1/4.12	1.9	1.0	12×34	1989
7	3×10.6	1/3.60	1.9	1.0	11×32	1767

5KV Type

AWG No.	Cross-section (Approximation) mm2	Conductor No./diameter mm	Insulation Thickness mm	Sheath Thickness mm	Overall Dimensions mm×mm	Reference weight kg/km
1	3×42.4	1/7.35	2.3	1.0	16×47	3850
2	3×33.6	1/6.54	2.3	1.0	15×45	3320
4	3×21.1	1/5.19	2.3	1.0	14×40	2730
5	3×16.8	1/4.62	2.3	1.0	13×38	2410
6	3×13.3	1/4.12	2.3	1.0	12×36	2100
7	3×10.6	1/3.60	2.3	1.0	11×34	1790

AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Submersible oil pump power cable is used for submersible oil motor power supply. inculde round and flat, also could be buildup by all the power cable types together with different stainless steel pipe/tube sizes.
