Fr-N1 X1g1 1 X1g1-Ar Low Voltage Aluminium/Copper Halogen-Free Fire Retardant Power Cable
Fr-N1 X1g1 1 X1g1-Ar Low Voltage Aluminium/Copper Halogen-Free Fire Retardant Power Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Applications
FR-N1 X1G1 is a low voltage fire resistant cable suitable for hotels, hospitals, underground railways, airports etc. to protect people and technical building equipment in the event of a fire if circuit integrity is not required. Not suitable for installations underground or in water.
FR-N1 X1G1-AR low voltage aluminium fire retardant power cable is recommended for use in public and industrial settings whenever reduced fumes, toxic and corrosive gases emissions are required in case of fire. May be used in industrial settings and in building risers. Can be used for static applications in the open air, in pipes, or in cable trays and trenches.
Construction
Conductor RM: Class 2 round stranded aluminium or Class 2 round stranded copper
Insulation XLPE (Cross-Linked Polyethylene)
Inner Sheath Halogen free tape or halogen free polymer compound
Outer Sheath Halogen-free polymer compound
Technical data
Voltage Rating Uo/U 0.6/1kV
Temperature Rating
Minimum laying temperature: -15ºC
Operating temperature: -20ºC to +60ºC
Maximum Conductor temperature: +90ºC
Short Circuit Temperature 250°C
Minimum Bending Radius
Single core: 15 x overall diameter
Multi-core: 12 x overall diameter
Cable Parameter
|
FR-N1 X1G1 Cable Parameter
|
|||
|
NO.OF CORES
|
NOMINAL CROSS SECTIONAL AREA
mm2 |
NOMINAL OVER ALL DIAMETER
mm |
NOMINAL WEIGHT
kg/km |
|
1
|
25
|
10.4
|
300
|
|
1
|
35
|
11.3
|
390
|
|
1
|
50
|
12.7
|
510
|
|
1
|
70
|
14.5
|
720
|
|
1
|
95
|
16.5
|
975
|
|
1
|
120
|
18.1
|
1210
|
|
1
|
150
|
20
|
1485
|
|
1
|
185
|
22.1
|
1845
|
|
1
|
240
|
24.7
|
2385
|
|
1
|
300
|
275
|
3005
|
|
2
|
4
|
11
|
205
|
|
2
|
6
|
12.4
|
270
|
|
2
|
10
|
14.1
|
385
|
|
2
|
16
|
16.2
|
545
|
|
2
|
25
|
19.1
|
805
|
|
2
|
35
|
21
|
1035
|
|
3
|
4
|
11.6
|
245
|
|
3
|
6
|
13.1
|
325
|
|
3
|
10
|
14.9
|
475
|
|
3
|
16
|
17.1
|
685
|
|
3
|
25
|
20.3
|
1020
|
|
3
|
35
|
224
|
1335
|
|
3
|
50
|
28
|
1905
|
|
3
|
50/35
|
29.7
|
2203
|
|
3
|
70
|
32.1
|
2650
|
|
3
|
70/50
|
34.2
|
3105
|
|
3
|
95
|
36.2
|
3545
|
|
3
|
95/50
|
37.7
|
3950
|
|
3
|
120
|
39.8
|
4380
|
|
3
|
120/70
|
41.9
|
4995
|
|
3
|
150
|
20
|
1485
|
|
3
|
150/70
|
45.2
|
5905
|
|
3
|
185
|
48.6
|
6660
|
|
3
|
185/70
|
49.4
|
7150
|
|
3
|
240
|
54.2
|
8555
|
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China Fr-N1 X1g1 1 X1g1-Ar Low Voltage Aluminium/Copper Halogen-Free Fire Retardant Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
