Flexible CPR LVD Multi-Core H07rn-F 3G10 Rubber Power Cable

Flexible CPR LVD Multi-Core H07rn-F 3G10 Rubber Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

H07RN-F

Current

DC & AC

Insulation Material

Cross-Linked Synthetic Elastomer Type Ei 4

Sheath Material

Cross-Linked Synthetic Elastomer Type Em 2

Material Shape

Round Wire

Wire Core Material

Bare Annealed Copper Stranded

Certification

ISO, CCC, CE

Model

H07rn-F

Brand

Tianhuan

Standards

En 50525-2-21

Conductor Flexibility

Flexible Class 5

Rated Voltage Uo/U (Um)

450/750 V

Cable Flexibility

Flexible

Flame Retardant

IEC 60332-1-2

Max. Conductor Temperature in Service

85 °c

Operating Temperature, Range

-25 -55 °c

Mechanical Resistance to Impacts

AG3

Short-Circuit Max. Conductor Temperature

250 °c

Transport Package

Hollow Reel, Steel-Wood Composite Cable Reel

Specification

1.5mm2-500mm2

Trademark

Tianhuan

Origin

Hebei

Packaging & Delivery

Package Size

30.00cm * 30.00cm * 15.00cm

Package Gross Weight

20.000kg

Product Description

Model Number :H07RN-F

Brand Name : Tianhuan

Conductor material:Bare annealed copper stranded

Insulation:Cross-linked synthetic elastomer type EI 4

Outer sheath:Cross-linked synthetic elastomer type EM 2

Rated Voltage: Ac:450/750V

Color : Black

Core:1,2,3,4,5,6,etc.

Wire Size: 1mm²-500mm²

Rated Temperature: -40~ 90 ºC

specification	Insulation	Outer sheath	Conductor cross-section	Maximum outer diameter	Minimum outer diameter	Max. linear resistance, phase conductor	Permissible current rating in open air	Voltage drop, single phase	Minimum dynamic operating bending radius	Minimum static operating bending radius
1×10	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	10 mm²	11.9 mm	9.5 mm	1.91 Ohm/km	77 A	3.4 V/A.km	71.4 mm	35.7 mm
1×16	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	16 mm²	13.4 mm	10.8 mm	1.21 Ohm/km	102 A	2.2 V/A.km	80.4 mm	40.2 mm
1×25	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	25 mm²	15.8 mm	12.7 mm	0.78 Ohm/km	136 A	1.4 V/A.km	94.8 mm	47.4 mm
more detail welcome to contact us
2×1.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	1.5 mm²	11.0 mm	8.5 mm	13.3 Ohm/km	23 A	27.0 V/A.km	66.0 mm	33 mm
2×2.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	2.5 mm²	13.1 mm	10.2 mm	7.98 Ohm/km	32 A	16.2 V/A.km	-mm	-mm
2×4	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	4 mm²	15.1 mm	11.8 mm	4.95 Ohm/km	43 A	10.1 V/A.km	90.6 mm	45.3 mm
more detail welcome to contact us
3×1.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	1.5 mm²	11.9 mm	9.2 mm	13.3 Ohm/km	23 A	27.0 V/A.km	71.4 mm	35.7 mm
3×2.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	2.5 mm²	14.0 mm	10.9 mm	7.98 Ohm/km	32 A	16.2 V/A.km	84.0mm	42 mm
3×4	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	4 mm²	16.2 mm	12.7 mm	4.95 Ohm/km	43 A	10.1 V/A.km	97.2 mm	-mm
more detail welcome to contact us
4×1.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	1.5 mm²	13.1 mm	10.2 mm	13.3 Ohm/km	21 A	23.3 V/A.km	78.6 mm	39.3 mm
4×2.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	2.5 mm²	15.5 mm	12.5 mm	7.98 Ohm/km	29 A	14.0 V/A.km	93.0mm	46.5 mm
4×4	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	4 mm²	18.0 mm	14.0 mm	4.95 Ohm/km	38 A	8.71 V/A.km	108.0 mm	54 mm
more detail welcome to contact us
5×1.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	1.5 mm²	14.1 mm	11.2 mm	13.3 Ohm/km	21 A	23.6 V/A.km	86.4 mm	43.2 mm
5×2.5	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	2.5 mm²	17.0 mm	13.3 mm	7.98 Ohm/km	29 A	14.0 V/A.km	102.0mm	51 mm
5×6	Cross-linked synthetic elastomer type EI 4	Cross-linked synthetic elastomer type EM 2	6 mm²	22.2 mm	17.5 mm	3.3 Ohm/km	50 A	5.84 V/A.km	133.2 mm	66.6 mm
more detail welcome to contact us

Our company, Tianhuan Cable Group Co., Ltd., has successfully approved LVD legislation and CPR legislation of CE certifications,as well as holding product certificates from TUV and CCC. Furthermore, we have also passed a series of management system certifications by ISO.

Tianhuan Cable Group Co., Ltd., founded in 2000, is a professional cable and wire manufacturer located in Ningjin County, Hebei Province, China.
With a registered capital of 302,000,000 CNY (approx $431,142,000), floor area of 110,000 m² and construction area of 86,000 m², the company contributes to the construction of power networks in China and even other countries around the world with it’s strong strength.
Over the years, the company has cooperated with the State Grid, China Railway and other government units, and has won the top 100 enterprises in China’s cable industry.
Tianhuan Cable Group adheres to reform and innovation, and its cable products not only sell well in 28 provinces and municipalities across the country, but also have a good market across the world. The factory and products have been well received by customers at home and abroad.

A)Are you trading company or manufacturer?

we are manufacturer. if you did not find your needed in this page. Just contact us and welcome to visit us.

B)How about the delivery time?

Usualy it is 5-10 days if the goods are in stock, or it is 15-20 days if the goods are not in stock,it depends on your quantity.

C)What’s the package of products?

The package is usually wooden drums ,steel-wooden drums or according to requirement .

D)What is your MOQ for the cable and wire ?

Please contact us for more details, MOQ depends on the sort of cable.

E)Can I get a discount?

It depends on your quantity, we can make a discount and afford the freight. so contact us.

We are China Flexible CPR LVD Multi-Core H07rn-F 3G10 Rubber Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
