Flame Resistance 2kv Sp (HD) Spb (HD) Spbs (HD) 12 AWG Marine Wire Cable

Flame Resistance 2kv Sp (HD) Spb (HD) Spbs (HD) 12 AWG Marine Wire Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Marine power cable

Insulation Material

Epr

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, VDE

Model

Marine Power Cable

Brand

Huadong

Product Name

Marine Power Cable

Rated Voltage

5kv 8kv 15kv

Size

8 6 5 4 3 1/0 2/0 AWG

Conductor

Stranded Copper

Insulation

Epr (Ethylene Propylene Rubber)

Sheath

Neoprene

Armor

Bronze Wire Braid

Standard

IEEE 1580/UL 1309

Sample

Avaiable

MOQ

100 Metres

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

100 Kilometer/Kilometers Per Month

Product Description

Flame Resistance 2kV SP(HD) SPB(HD) SPBS(HD) 12 awg marine wire cable
1. Conductor : Tinned Annealed Rope-Lay Stranded Copper
2. Conductor Shielding : Semi-Conductiing Tape And Compound
3. Insulation : Err(Ethylene Propylene Rubber)
4. Insulation Shield(Non-Metallic Material : Semi-Conducting Tape/Compound)
5. Insulation Shield(Metailic) : Tinned Copper Wire Braid
6. Jacket : Arctic Neoprene
7. Armor : Bronze Wire Braid
8. Outer Jaket : Arctic Neoprrene
9. Application : Suitable For Use In Commercial Marine Applications, Modu’S & Platforms,Onshore And Offshore Drilling Platforms,FPSO, Etc.
10. Feature : Flame retardant : Superior Flexibility,Flame&Cold Resistant,,Drilling Mud Resistant,Excellent Resistance To Oil, Abrasion, Petrochemical Fluids, Moisture & Sunlight

3 Core 8KV TEN Marine Power Cable Parameters
Nominal Area	Conductor Strand	Dai	Thickness of Insulation	Thickness of Jaket	Thickness of Sheath	TEN
Nominal Area	Conductor Strand	Dai	Thickness of Insulation	Thickness of Jaket	Thickness of Sheath	Nom.Dia Approx	Weight Approx
AWG or kcmil	No./mm	mm	mm/inch	mm/inch	mm/inch	mm/inch	kg/km
6	61 / 0.511	4.45	3.56 / 0.140	2.03 / 0.080	2.79 / 0.110	39.4 / 1.551	2230
4	105 / 0.511	6.55	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	45.4 / 1.787	3010
2	150 / 0.511	8.23	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	48.0 / 1.890	3500
1	209 / 0.511	9.17	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	51.3 / 2.020	4140
1/0	266 / 0.511	10.34	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	53.8 / 2.118	4690
2/0	342 / 0.511	11.71	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	56.4 / 2.220	5370
3/0	418 / 0.511	12.95	3.56 / 0.140	2.79 / 0.110	2.79 / 0.110	59.9 / 2.358	6150
4/0	532 / 0.511	14.61	3.56 / 0.140	2.79 / 0.110	3.56 / 0.140	63.5 / 2.500	7160
262	646 / 0.511	16.61	3.56 / 0.140	2.79 / 0.110	3.56 / 0.140	66.8 / 2.630	8160
313	777 / 0.511	18.29	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	71.9 / 2.831	9540
373	925 / 0.511	19.94	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	75.6 / 2.976	10800
444	1110 / 0.511	21.84	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	79.7 / 3.138	12330
535	1332 / 0.511	23.9	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	84.2 / 3.315	14130
646	1591 / 0.511	26.14	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	89.0 / 3.504	16210
777	1924 / 0.511	28.75	3.56 / 0.140	3.56 / 0.140	3.56 / 0.140	93.7 / 3.689	18700

Huadong Cable Shandong Co.,Ltd is an import and export trade company located in Jinan City, Shandong Province, China, which is a branch of Henan Huadong Cable Group. Our factory occupied 150,000 square meters.We specialize in 0.6-35KV power cables,overhead ABC cables, ACSR, AAAC,control cables, welding cables, rubber cables, mining cables ect. We can provide high quality cables meet GB, IEC, BS,ICEA, ASTM, DIN, VDE and JIS standards. What’s more, We can design cables according to your requirement.

We are China Flame Resistance 2kv Sp (HD) Spb (HD) Spbs (HD) 12 AWG Marine Wire Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
