Fhl2g Fhlal2g Fhlr2g2g Fhlr2gcb2g Fhl2gcb2g Unshielded Copper Aluminum High Voltage Cables for Hybrid and Battery Vehicles
Fhl2g Fhlal2g Fhlr2g2g Fhlr2gcb2g Fhl2gcb2g Unshielded Copper Aluminum High Voltage Cables for Hybrid and Battery Vehicles image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
we are able to calculate conductor heating as a function of current loads and operating ambient temperatures. Our derating simulations enable you to define your optimum conductor cross-sections – and thus reduce weight, packaging space and costs.
* Reliable Insulation Resistance
* Excellent Sealing Properties
* Talc-free Surfaces
* High Performance Silicone
* Weight Saving Potentials
|
CORES
|
CORE
|
OUTER SHEATH
|
RESISTANCE (d.c. 20 °C) (max.)
|
CABLE WEIGHT
|
||
|
NO.
|
SIZE
|
DIAMETER [mm]
|
DIAMETER [mm]
|
CONDUCTOR [mΩ/m]
|
SCREEN [mΩ/m]
|
approx. [g/m]
|
|
1 x
|
10 mm²
|
6
|
8.8
|
3.03
|
9.1
|
103
|
|
1 x
|
12 mm²
|
6.5
|
9.5
|
2.53
|
7.7
|
118
|
|
1 x
|
16 mm²
|
7.2
|
10.2
|
1.93
|
6.4
|
138
|
|
1 x
|
20 mm²
|
7.8
|
11
|
1.59
|
6.6
|
160
|
|
1 x
|
25 mm²
|
8.8
|
12.2
|
1.24
|
6.6
|
205
|
|
1 x
|
30 mm²
|
9.6
|
13.4
|
1.08
|
4
|
250
|
|
1 x
|
35 mm²
|
10.5
|
14.4
|
0.878
|
3
|
285
|
|
1 x
|
40 mm²
|
11.1
|
15
|
0.788
|
3
|
300
|
|
1 x
|
50 mm²
|
12.2
|
15.8
|
0.613
|
3
|
345
|
|
1 x
|
60 mm²
|
13.3
|
16.9
|
0.525
|
3
|
385
|
|
1 x
|
70 mm²
|
14.4
|
18.2
|
0.432
|
2.7
|
435
|
|
1 x
|
85 mm²
|
15.8
|
19.8
|
0.365
|
2.1
|
515
|
|
1 x
|
95 mm²
|
17.2
|
20.9
|
0.327
|
1.9
|
560
|
|
1 x
|
120 mm²
|
19
|
23.0
|
0.255
|
1.7
|
696
|
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China Fhl2g Fhlal2g Fhlr2g2g Fhlr2gcb2g Fhl2gcb2g Unshielded Copper Aluminum High Voltage Cables for Hybrid and Battery Vehicles manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
