Fg16r16 Cu Conductors Rubber G16 Insulated PVC Sheathed 1X25 mm2 Power Cable

Fg16r16 Cu Conductors Rubber G16 Insulated PVC Sheathed 1X25 mm2 Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

FG16R16

Current

DC & AC

Insulation Material

Rubber

Sheath Material

PVC

Material Shape

Round

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

Fg16r16

Brand

Huadong

Product Name

Fg16r16 Rubber Cable

Rated Voltage

0.6/1kv

Cores

Single Core

Temperature

-40 to 90 Centigrade

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

FG16R16 Cu conductors rubber G16 insulated PVC sheathed 1×25 mm2 Power cable

Cable Application

Reference Guidance CEI 20-67: Cable suitable for energy supply in industry, building sites and construction industry. For fixed wiring indoors and outdoors, even wet; for direct and indirect underground wiring. Suitable for installation at open air, on walls, metal structures, cable trays, pipes, wiring holders and similar devices. Suitable for bundle installations in environtments at risk of fire.

Technical Characteristics

CPR class: Cca – s3,d1,a3

Test voltage: 4 kV

Rated voltage: 0,6/1 kV

Bending radius (min): single-core – 6D

Min. laying temperature: -15°C

Max. conductor temperature: 90°C

Max. short-circuit temperature: 250°C

Cable Construction:

Conductors: Cu, class 5 according to EN 60228

Insulation: Rubber compound G16 quality

Sheath: PVC compound R16 quality, gray

Cable Parameter:

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.what is our payment term?
Our payment term is usually T/T 30% advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time?
The lead time usually is 10 – 30 working days.

3.what is the package of the cable?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.

4.Could we provide the free sample for customer?
Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China Fg16r16 Cu Conductors Rubber G16 Insulated PVC Sheathed 1X25 mm2 Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
